凯斯零件查询(2230) - PRECISION AIR CART (1/02-12/08) (88.100.06) - THIRD TANK OPTION - METER MOUNT PLATE Case Agriculture

作者：广数供应链运营团队

浏览数：

时间：2025-01-24 22:45:43

Pos.	Part No	Qty	Parts name	Comments
1.	87414	[3]	LUBE NIPPLE,1/4" - 28	NH
2.	507586	[4]	HOSE CLAMP,20.6mm - 44.4mm, Worm Gear	PA
3.	88011	[3]	BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5	NH
4.	280161	[2]	BOLT,Hex, 3/8" - 16 x 3", Gr 5	NH
5.	88206	[1]	BOLT,Hex, 3/8" - 16 x 1", Gr 5	NH
6.	88576	[1]	BOLT,Hex, 1/2" - 13 x 5 1/2", Gr 5	NH
7.	280431	[2]	NUT,1/2"-13, G5	NH
8.	281010	[12]	LOCK NUT,7/8"-14, GC	BAS
9.	88902	[4]	NUT,3/8"-16	NH
10.	86992215	[1]	LOCK NUT,1/2"-13, GC	GFD
11.	80664	[2]	WASHER,0.38" ID x 0.88" OD x 0.08" Thk	NH
12.	80702	[1]	WASHER,0.44" ID x 1" OD x 0.08" Thk	NH
13.	80755	[3]	COTTER PIN,1/8" OD x 1" L	NH
14.	9707580	[12]	BOLT,Hex, 1/4" - 20 x 3/4", Gr 5, Full Thd	NH
15.	80682	[10]	LOCK WASHER,1/4"	PA
16.	280129	[2]	NUT,1/4"-20	NH
17.	87936	[2]	BOLT,Hex, 3/8" - 16 x 2 1/2", Gr 5	NH
18.	9635884	[10]	BOLT,Hex, 5/16" - 18 1", Full Thd, Gr 5	NH
19.	9628503	[4]	NUT,3/8"-16, G5	NH
20.	5868	[12]	WASHER,0.5" ID x 1" OD x 0.06" Thk	FLX 1/2" id 1" 16ga
21.	438-12024	[1]	LOCK PIN,5/16" x 1 1/2", Slotted	CAS
22.	87016560	[3]	JAM NUT,Jam, 3/8"-16, G5	GFD
23.	7187	[8]	PLUG	FLX manifold transition
24.	9148	[2]	LOCK NUT	FLX #10-32, stainless steel
25.	9475	[8]	TUBE	FLX manifold transition, velocity sensor
26.	425043A1	[1]	TUBE	FLX storage & cap, 17 3/16"
25.	425095A1	[8]	PLUG	FLX manifold transition - velocity sensor
27.	7777	[1]	SCREW,Pan Hd, #10 - 32 x 1"	FLX mch #10-32 x 1" ph Phillips ss
28.	425090A1	[1]	PLASTIC-BAG	FLX collector with clasp
29.	51200897	[5]	LINKAGE YOKE	FLX clevis 3/8" x 2 1/2" long
30.	9834	[3]	CLEVIS PIN	FLX 3/8" x 1 1/16"
31.	13637V2	[1]	SENSOR	SAS air flow
32.	21319	[2]	BOLT	FLX 5/16"-18 x 1" ss hx-skt
33.	22187	[2]	HOSE,1.25" ID x 20.00"	FLX 1 1/4" x 20" flex-haust type cw-gp
34.	CA-142	[1]	SPACER	FLX air velocity sensor
35.	GE-172	[1]	HANDLE	FLX crank
36.	GI-221	[1]	SPACER	FLX plate blank manifold
37.	GI-343	[1]	MOUNTING PLATE	FLX meter box
38.	GI-455	[1]	PANEL	FLX manifold, 3rd tank
39.	GI-465	[1]	ROCKSHAFT	FLX 3rd tank manifold lift
40.	GI-466	[1]	BRACKET	FLX mount, front LH
41.	GI-467	[1]	BRACKET	FLX mount, front RH
42.	GI-468	[2]	BRACKET	FLX mount, pivot rod
43.	GI-469	[1]	PIVOTING ARM	FLX manifold - 3rd tank
44.	GI-471	[2]	PIVOTING ARM	FLX front - 3rd tank
45.	GI-472	[1]	GUIDE	FLX arm, manifold - 3rd tank
46.	GI-675	[1]	ARM	FLX auxiliary rockshaft 3rd tank manifold
47.	GI-676	[1]	ARM	FLX control, handle
48.	GI-677	[1]	SUPPORT	FLX plate calibration tube
49.	GI-707	[1]	LIFT ARM	FLX lock, manifold
50.	GI-708	[1]	SPACER	FLX manifold lift
51.	GL-116	[1]	SPACER	FLX plate transition manifold rear
