| 0. |
GI-475A
|
[1] |
CLUTCH
|
FLX
assembly, actuator housing
|
| 1. |
51200032
|
[1] |
SOLENOID
|
FLX
assembly, clutch
|
| 2. |
GI-480
|
[1] |
SPACER
|
FLX
latch arm - pvc
|
| 3. |
80702
|
[5] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
|
| 4. |
425031A1
|
[1] |
TENSION SPRING
|
FLX
1/64" wr 15/64" od x 7/8" long
|
| 5. |
425032A1
|
[1] |
SCREW
|
FLX
cap #10-32 x 1 1/4" fh sq
|
| 6. |
173-259
|
[1] |
SCREW,Sl Rnd Hd, #10 - 32 x 2"
|
CAS
|
| 7. |
9628503
|
[2] |
NUT,3/8"-16, G5
|
NH
|
| 8. |
87825
|
[1] |
NUT,#10-32
|
NH
|
| 9. |
272535
|
[1] |
CLAMP,1/8", Insul, 1/4" Bolt
|
NH
Superseded by part number: 80272535
|
| 10. |
87016560
|
[2] |
JAM NUT,Jam, 3/8"-16, G5
|
GFD
|
| 11. |
88612
|
[1] |
WASHER,0.22mm ID x 0.5mm OD x 0.05mm Thk
|
GI
Superseded by part number: 9824326
|
| 12. |
21757
|
[1] |
ROLL PIN
|
FLX
3 mm x 14 mm
|
| 13. |
GI-481
|
[1] |
LATCH
|
FLX
arm clutch housing
|
| 14. |
7525
|
[1] |
SCREW,#10 - 32 x 1"
|
FLX
mch #10-32 x 1" fh sq
|
| 15. |
20332
|
[7] |
LOCK NUT,#10-32, GB
|
BEL
|
| 16. |
7532
|
[3] |
SCREW,Pan Hd, M3 x 5mm
|
FLX
mch M3 x 5 mm ph slt
|
| 17. |
8675
|
[1] |
PAD
|
FLX
protective, adhesive back, 1 5/8" Diameter x 1/16" thick, UHMW
|
| 18. |
84147800
|
[1] |
PIN
|
SAS
latch arm
|
| 19. |
231-14406
|
[1] |
LOCK NUT,#6-32, GB
|
CAS
|
| 20. |
GI-476
|
[1] |
BRACKET
|
FLX
solenoid mount
|
| 21. |
GI-477
|
[1] |
MOUNTING PLATE
|
FLX
clutch housing
|
| 22. |
GI-478
|
[1] |
COVER
|
FLX
plate clutch housing
|
| 23. |
GI-479
|
[1] |
SPACER
|
FLX
, Serial Range: mount-cover
|
| 24. |
9635082
|
[4] |
NUT,5/16" - 18, Gr 5
|
NH
|
| 25. |
GH-183
|
[1] |
ADAPTER
|
FLX
meter shaft
|
| 27. |
6383
|
[1] |
PIN
|
FLX
quick - 5/16" x 1 3/4" usable
|
| 28. |
GR-111
|
[1] |
TUBE,1.312" OD x 4.312" L
|
FLX
connector meter drive
|
| 29. |
9707515
|
[2] |
BOLT,Hex, 5/16 - 18" x 1 3/4", Gr 5
|
NH
|
| 30. |
GH-224
|
[1] |
SHAFT
|
FLX
output, c/w stator ring
|
| 31. |
7170
|
[1] |
O-RING
|
FLX
2 1/16" id x 2 3/8" id x .139" wide
|
| 32. |
GH-884
|
[1] |
SPROCKET
|
FLX
control cw
|
| 32. |
87429000
|
[1] |
SPROCKET
|
SAS
control ccw
|
| 33. |
86624168
|
[1] |
WASHER,1.03" ID x 1.5" OD x 0.03" Thk
|
FOR
|
| 35. |
7301
|
[1] |
TORSION SPRING
|
FLX
CW .092" Wire x 1.45" ID x 1" long
|
| 35. |
51200048
|
[1] |
TORSION SPRING
|
FLX
ccw 3/32" x 1 27/64" x 1 1/64"
|
| 36. |
GH-223
|
[1] |
SPROCKET
|
FLX
assembly, driven
|
| 37. |
5271
|
[1] |
WASHER,0.44" ID x 1.75" OD x 0.08" Thk
|
FLX
7/16" id 1 3/4" 5/64"
|
| 38. |
80680
|
[1] |
LOCK WASHER,3/8 0.381 CST ZND
|
NH
|
| 39. |
86500692
|
[1] |
BOLT,Hex, 3/8" - 16 x 3/4", Gr 8, Full Thd
|
IMO
|
