| 1. |
87716
|
[4] |
BOLT,1/4"-20 x 1-1/4", Cl 5
|
PA
|
| 2. |
80702
|
[5] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
|
| 3. |
88542
|
[12] |
BOLT,Hex, 1/4"-20 x 1/2", Gr 5
|
NH
|
| 4. |
280129
|
[16] |
NUT,1/4"-20
|
NH
|
| 5. |
80680
|
[4] |
LOCK WASHER,3/8 0.381 CST ZND
|
NH
|
| 6. |
9628503
|
[4] |
NUT,3/8"-16, G5
|
NH
|
| 7. |
5271
|
[10] |
WASHER,0.44" ID x 1.75" OD x 0.08" Thk
|
FLX
7/16" id 1 3/4" 5/64"
|
| 8. |
425473A1
|
[1] |
SEAL
|
FLX
sponge 3/4" wide x 1/2" thick x 83" long
|
| 8. |
86992936
|
[1] |
SEAL
|
SAS
sponge 3/4" x 1/2" thick order in multiples of 20, Serial Range: -Y9S015091
|
| 8. |
84181721
|
[1] |
SEAL
|
SAS
3/4" Wide x 1" Thick, Bulk 25' Roll, Start Serial: Y9S015091
|
| 9. |
425467A1
|
[1] |
SEAL
|
FLX
sponge trim round 82"
|
| 9. |
86992288
|
[1] |
RUBBER SEAL
|
SAS
sponge trim round
|
| 10. |
280681
|
[10] |
LOCK WASHER,3/8", Stainless
|
GI
|
| 11. |
51200057
|
[4] |
GROMMET
|
FLX
3/4" od x 7/16" id x 1/4" thick
|
| 12. |
8919
|
[10] |
SCREW,Pan Hd, 1/4" - 20 x 3/4", Sl Sq Drive, Stainless
|
FLX
1/4"-20 x 3/4" - stainless steel
|
| 13. |
131-634
|
[3] |
SPRING NUT,J, Ret, 3/8"-16
|
CAS
Superseded by part number: 86624056
|
| 14. |
GI-227
|
[1] |
SHAFT
|
FLX
bottom damper
|
| 15. |
GI-401
|
[1] |
SHAFT
|
FLX
top damper
|
| 16. |
GI-591
|
[1] |
INSERT
|
FLX
plenum
|
| 17. |
GI-593
|
[2] |
BAFFLE
|
FLX
panel
|
| 18. |
GI-595
|
[2] |
BAFFLE
|
FLX
panel, 3 slots
|
| 19. |
GI-596
|
[2] |
BAFFLE
|
FLX
panel notched end
|
| 20. |
88902
|
[3] |
NUT,3/8"-16
|
NH
|
