| 1. | 507586 | [8] |
HOSE CLAMP,20.6mm - 44.4mm, Worm Gear |
PA |
| 2. | 88346 | [2] |
BOLT,Hex, 5/16" - 18 x 2 1/2", Gr 5 |
BEL |
| 3. | 87557084 | [6] |
CABLE TIE,14" |
SASCABLE STRAP 14" with stainless locking clip Superseded by part number: 84530708 |
| 4. | 281010 | [2] |
LOCK NUT,7/8"-14, GC |
BAS |
| 5. | 88902 | [4] |
NUT,3/8"-16 |
NH |
| 6. | 80702 | [4] |
WASHER,0.44" ID x 1" OD x 0.08" Thk |
NH |
| 7. | 18606 | [1] |
WASHER,0.62" ID x 1.47" OD x 0.11" Thk |
FAR |
| 8. | 88992 | [2] |
CARRIAGE BOLT,Short Sq Nk, 5/16" - 18 x 1", Gr 5 |
GI |
| 9. | 88062 | [1] |
BOLT,Hex, 5/8" - 11 x 1 1/2", Gr 8 |
WIN |
| 10. | 85700693 | [1] |
NUT,5/8" - 11, Gr C |
NH |
| 11. | 7322 | [1] |
RUBBER WASHER |
FLX5/8" id x 1 1/2" x 1/4" |
| 12. | 8633 | [2] |
WASHER |
FLX7/16" id x 1" od x 5/64" thick, ss |
| 13. | 412911A1 | [4] |
WASHER |
FLXpoly 3/8" id |
| 14. | 9528 | [4] |
HEX SOC SCREW,Sl Rnd Hd, #10 - 32 x 0.50", SST |
FLXmachine #10-32 x 1/2" rh skt-slt ss |
| 15. | 9586 | [2] |
FLANGE NUT |
FLXflange 5/16" serrated |
| 16. | 9587 | [4] |
LOCK WASHER |
FLX#10 ss |
| 17. | 9588 | [4] |
SCREW,Sl Sq, #10 - 32 x 1.50" |
FLXmch #10-32 x 1 1/2" rh sq-slt ss |
| 18. | 9589 | [4] |
NUT |
FLX#10-32 ss |
| 19. | 87508154 | [1] |
SENSOR |
SASOptical Bin Level |
| 20. | 14868V2 | [2] |
SENSOR |
FLXsonar bin level 0.3m cable |
| 21. | 419966A1 | [2] |
HARNESS |
FLXbin level sensor 2.01 m |
| 22. | 21881 | [4] |
SPECIAL BOLT |
FLX3/8" x 1" GR2 undercut head |
| 23. | GH-495 | [2] |
SHIELD |
FLXproduct - front RH & rear LH |
| 24. | GH-496 | [2] |
SHIELD |
FLXproduct - front LH & rear RH |
| 25. | GI-329 | [4] |
HOSE,37.00" |
FLXTank Pressurization Superseded by part number: 412786A1 |
| 25. | 412786A1 | [4] |
HOSE |
FLX1 1/4" pvc clear spiral 1/8" wall must be ordered in multiples of 100 |
| 26. | GI-340 | [1] |
LADDER |
FLXrear tank - internal |
| 27. | GL-349 | [2] |
BRACKET |
FLXmount, bin level sensor - ultrasonic |
| 100. | NSS | [1] |
NOT SOLD SEPARAT |
CONSENSOR, sonar bin level aiming |
