| 1. |
86505984
|
[1] |
BOLT,Hex, 7/16" - 14 x 2 1/4", Gr 5
|
GI
|
| 2. |
280980
|
[1] |
NUT,7/16"-14, GC
|
NH
|
| 3. |
80702
|
[1] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
|
| 4. |
8289
|
[1] |
WASHER
|
FLX
1/2" id 13/16" od 3/32"
|
| 5. |
129274
|
[1] |
TEE,9/16" - 18 JIC x 9/16" - 18 JIC x 9/16" - 18 JIC
|
BHB
|
| 6. |
128817
|
[2] |
HYD CONNECTOR,3/4" - 16 ORB x 9/16" - 18 JIC
|
NH
|
| 7. |
86509028
|
[1] |
HYD CONNECTOR,3/4" - 16 JIC x 9/16" - 18 ORB
|
NH
|
| 8. |
21640
|
[1] |
O-RING,1.44" ID x 1.68" OD x 0.12"
|
FLX
1 7/16" id 1 43/64" od 3/64" thick
|
| 9. |
86511870
|
[1] |
TEE,3/4" - 16 JIC x 3/4" - 16 JIC x 3/4" - 16 JIC
|
ZED
|
| 10. |
22156
|
[1] |
HYDRAULIC OIL FILTER
|
FLX
and seal kit
|
| 11. |
22446
|
[1] |
HYDRAULIC OIL FILTER
|
FLX
complete assembly
|
| 12. |
22447
|
[1] |
VALVE
|
FLX
1 1/4" gpm p. comp deltrol pressure compensated
|
| 13. |
22448
|
[1] |
FITTING
|
FLX
hydraulic - straight adapter 3/8" morb x 3/8" morb
|
| 14. |
22449
|
[1] |
FITTING
|
FLX
hydraulic swivel adapter 3/8" mb 3/8" fjx
|
| 15. |
22692
|
[1] |
HYDRAULIC HOSE
|
FLX
1/2" x 89" fl, 1/2" mpt x 1/2" fjic
|
| 16. |
22693
|
[1] |
HYDRAULIC HOSE
|
FLX
1/4" x 78 1/2" fl, 3/8" fjic x 3/8" fjic
|
| 17. |
CC-105
|
[1] |
HOSE CLAMP
|
FLX
for 2 hoses
|
