| 1. |
GR-256A
|
[1] |
HYDRAULIC HOSE,0.75" ID x 96.00"
|
FLX
Fan pressure
|
| 2. |
GR-257A
|
[1] |
HYDRAULIC HOSE,0.75" ID x 96.00"
|
FLX
Fan return
|
| 3. |
87502347
|
[1] |
HYDRAULIC HOSE
|
SAS
3/4" x 360" fl
|
| 3. |
87502346
|
[1] |
HYDRAULIC HOSE,0.75" ID x 450.00", SAE 100R2 AT
|
SAS
|
| 4. |
232-1446
|
[10] |
NUT,3/8"-16, GC
|
CAS
|
| 5. |
1013043
|
[6] |
WASHER
|
CAS
3/8" SAE
|
| 6. |
1026712
|
[6] |
CLAMP
|
CON
5"
|
| 7. |
1026713
|
[6] |
CLAMP
|
CON
backing
|
| 8. |
1026714
|
[12] |
ISOLATOR
|
CON
neoprene 1/4" tk pln
|
| 9. |
1026677
|
[3] |
STUD
|
CON
3/8" x 3 1/4" nc gr d zp
|
| 10. |
1026745
|
[2] |
TUBE,0.75" Diameter, 108" Length
|
CON
assy 3/4" x 108"
|
| 11. |
280177
|
[2] |
BOLT,Hex, 3/8" - 16 x 5", Gr 5
|
WIN
|
| 12. |
87442733
|
[2] |
BRACKET
|
SAS
bar-angle
|
| 13. |
113-250
|
[3] |
BOLT,Hex, 3/8" - 16 x 2-1/2", Gr 5, Full Thd
|
CAS
|
| 14. |
1026123
|
[1] |
BAR
|
CAS
bolting
|
| 15. |
86977779
|
[2] |
HYD CONNECTOR,1-1/16" - 12 JIC x 3/4" - 14 NPT
|
FTR
|
| 16. |
132341
|
[1] |
HYD CONNECTOR,3/4" - 16 JIC x 1/2" - 14 NPT
|
PA
|
| 17. |
1026115
|
[2] |
HYDRAULIC HOSE
|
CON
3/4" x 90" fl
|
| 17. |
1024361
|
[2] |
HYDRAULIC HOSE
|
CON
3/4" x 180" fl
|
| 18. |
280284
|
[2] |
BOLT,Hex, 3/8" - 16 x 7", Gr 5
|
GI
|
| 19. |
1994568C1
|
[1] |
COUPLING, QUICK, FEM
|
CAS
1/2" fpt
|
| 20. |
86592083
|
[1] |
DUST CAP
|
ZED
pioneer coupler - 1/2"
|
| 21. |
6935
|
[2] |
COUPLING, QUICK, FEM
|
FLX
3/4"
|
| 22. |
6934
|
[2] |
PLUG
|
FLX
dust, pioneer coupler - 3/4"
|
| 23. |
351445A1
|
[2] |
HYD TUBE
|
FLX
hydraulic 3/4"
|
