| 1. |
7770
|
[2] |
NUT,Hex, 1/4 - 20, Cl 5
|
NH
|
| 2. |
80682
|
[2] |
LOCK WASHER,1/4"
|
PA
|
| 3. |
87404
|
[2] |
BOLT,Hex, 1/4" - 20 x 2", Gr 5
|
PA
|
| 4. |
80680
|
[1] |
LOCK WASHER,3/8 0.381 CST ZND
|
NH
|
| 5. |
1994568C1
|
[1] |
COUPLING, QUICK, FEM
|
CAS
1/2" fpt
|
| 5. |
85999239
|
[1] |
QUICK MALE COUPLING,3/8" x 3/4" - 16 ORB
|
PA
stl 3/8"
|
| 6. |
86592083
|
[1] |
DUST CAP
|
ZED
pioneer coupler - 1/2"
|
| 7. |
6082
|
[1] |
KNOB
|
FLX
valve 3/8"-16 stud
|
| 8. |
216791
|
[1] |
ELBOW,90 Degree, 3/4"-16, 37 Degree x 3/4"-16, 37 Degree
|
PA
|
| 9. |
87329794
|
[1] |
FITTING
|
SAS
3/4" mb x 1/2" mj
|
| 10. |
322896
|
[2] |
HYD CONNECTOR,1-1/16" - 12 ORB x 1-1/16" - 12 JIC
|
BHB
|
| 11. |
9412
|
[2] |
QUICK MALE COUPLING
|
FLX
1/2" Superseded by part number: 9801618
|
| 12. |
21651
|
[1] |
HYDRAULIC HOSE
|
FLX
3/4" x 170" fl, 3/4" mpt x 3/4" fjic
|
| 13. |
51200050
|
[1] |
HYDRAULIC HOSE,0.50" ID x 168.00", SAE 100R17, SAE J517, SAE J516, ASTM B633 Class 2 Type 2
|
FLX
1/2" x 168" fl, 1/2" mpt x 1/2" fjic
|
| 14. |
21668
|
[2] |
REDUCER FITTING,1/2" - 14 Male NPT x 3/4" - 14 Female NPT
|
FLX
hydraulic 1/2" mpt x 3/4" fpt
|
| 15. |
80015694
|
[1] |
TEE,1 1/16"-12 37 Degree
|
GI
|
| 16. |
262159
|
[2] |
CAP,3/4" - 16 Fem JIC
|
BHB
|
| 17. |
87648720
|
[1] |
REDUCER,3/4" - 16 JIC x 1-11/16" - 12 JIC
|
WIC
37º, 1 1/16"-12, Fem x 3/4"-16 Male
|
| 18. |
51200062
|
[1] |
HYDRAULIC HOSE
|
FLX
3/4" x 158" fl, 3/4" fjic x 3/4" mpt
|
| 19. |
87506270
|
[1] |
VALVE
|
SAS
two way selector
|
| 19. |
21905
|
[1] |
SEAL KIT
|
SAS
s75 selector valve
|
| 20. |
GD-500.07
|
[1] |
DECAL
|
FLX
attention hydraulic flow
|
| 21. |
GI-710
|
[1] |
PLATE
|
FLX
decal, fan auger control
|
| 22. |
GL-373
|
[2] |
COVER
|
FLX
hydraulic hose label - 1 1/2"
|
| 23. |
GL-375
|
[1] |
COVER
|
FLX
label 1" case drain hyd
|
| 24. |
GL-700.32
|
[1] |
DECAL
|
FLX
fan pressure
|
| 25. |
GL-700.33
|
[1] |
DECAL
|
FLX
fan return
|
| 26. |
GL-700.42
|
[1] |
DECAL
|
FLX
drain
|
