| 1. |
88444
|
[2] |
BOLT,Hex, 3/8" - 16 x 2 3/4", Gr 5
|
NH
|
| 2. |
88206
|
[4] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
NH
|
| 3. |
87689
|
[1] |
BOLT,1/2"-13 x 1.813" OAL, Gr 5
|
NH
|
| 4. |
281010
|
[14] |
LOCK NUT,7/8"-14, GC
|
BAS
|
| 5. |
88902
|
[4] |
NUT,3/8"-16
|
NH
|
| 6. |
86992215
|
[1] |
LOCK NUT,1/2"-13, GC
|
GFD
|
| 7. |
80664
|
[8] |
WASHER,0.38" ID x 0.88" OD x 0.08" Thk
|
NH
|
| 8. |
9707515
|
[1] |
BOLT,Hex, 5/16 - 18" x 1 3/4", Gr 5
|
NH
|
| 9. |
6155
|
[1] |
OIL COOLER
|
FLX
steel 12" x 15"
|
| 10. |
7938
|
[2] |
U-BOLT
|
FLX
ur 5/16"-18 x 1 3/8" w x 1 5/8" d
|
| 11. |
8474
|
[1] |
U-BOLT
|
FLX
us 5/16" x 3 1/16" w x 4 3/4" d 1" thread
|
| 12. |
322896
|
[3] |
HYD CONNECTOR,1-1/16" - 12 ORB x 1-1/16" - 12 JIC
|
BHB
|
| 13. |
425429A1
|
[1] |
VALVE
|
FLX
pressure regulating orb
|
| 14. |
1336645C1
|
[1] |
VALVE
|
CAS
body press regulating
|
| 15. |
21426
|
[1] |
CARTRIDGE
|
FLX
hyd valve pressure reg
|
| 16. |
22060
|
[2] |
FITTING
|
FLX
hydraulic - straight adapter 3/4" morb x 3/4" fjic
|
| 17. |
22112
|
[2] |
HYDRAULIC HOSE
|
FLX
3/4" x 46" fl, 3/4" fjic x 3/4" fjic
|
| 18. |
218-1046
|
[2] |
ELBOW,90 Degree, 1 1/16"-12, 37 Degree x 1"-11 1/2, NPTF
|
CAS
|
| 19. |
218-656
|
[1] |
4 WAY CONNECTION,1 1/16"-12, 37 Degree
|
CAS
|
| 20. |
100333
|
[2] |
ELBOW,90 Degree, 1 1/16"-12, 37 Degree x 3/4"-16, O-Ring
|
GI
|
| 21. |
22784
|
[3] |
HYDRAULIC HOSE,0.75" ID x 28.00", SAE J517, SAE J516, SAE J846, SAE J1273
|
FLX
3/4" x 28" fl, 3/4" fjic x 3/4" fjic
|
| 22. |
22788
|
[1] |
VALVE PRESSURE RELIE
|
FLX
2250 psi
|
| 23. |
22790
|
[1] |
CARTRIDGE
|
FLX
hyd valve relief 2250
|
| 24. |
51200875
|
[1] |
HYDRAULIC HOSE
|
FLX
3/4" x 46" fl, 3/4" fjic x 3/4" fjic
|
| 25. |
265978
|
[1] |
TEE,1-1/16" - 12 JIC x 1-1/16" - 12 JIC x 1-1/16" - 12 JIC
|
WIN
|
| 26. |
GK-206
|
[1] |
BRACKET
|
FLX
mount, pressure regulator valve
|
| 27. |
GK-225
|
[1] |
BRACKET
|
FLX
mount, oil cooler
|
| 28. |
GK-226
|
[2] |
SPACER
|
FLX
2" long
|
| 29. |
GK-232
|
[1] |
BRACKET
|
FLX
mount, pressure regulator valve
|
