| 1. |
87398
|
[2] |
COTTER PIN,3/16" OD x 1-1/4" OAL
|
NH
|
| 2. |
87670
|
[2] |
BOLT,1/2" - 13 x 1-1/4", Full Thd, Gr 5
|
NH
|
| 3. |
86992215
|
[2] |
LOCK NUT,1/2"-13, GC
|
GFD
|
| 4. |
81541
|
[4] |
WASHER,0.5" ID x 1.25" OD x 0.08" Thk
|
NH
|
| 5. |
80700
|
[4] |
WASHER,0.56" ID x 1.38" OD x 0.11" Thk
|
NH
|
| 6. |
9637417
|
[2] |
BOLT,Hex, 1/2" - 13 x 3 1/2", Gr 5
|
NH
|
| 7. |
51200891
|
[2] |
FLANGE NUT
|
FLX
serrated flange 1/2"-13 G2
|
| 8. |
51200883
|
[1] |
HYDRAULIC HOSE,1.25" ID x 50.00", SAE 100R4, SAE 100R1, ASTM B633 Class 2 Type 2
|
FLX
1 1/4" x 50" fl, 1 1/4" fjic x 1 1/4" fjic
|
| 9. |
218-5394
|
[1] |
ELBOW,90 Degree, 1 5/16"-12 O-Ring x 3/4" NPSM Fem
|
CAS
|
| 10. |
1958267C1
|
[1] |
COUPLING,Assembly, Pump, 1 3/8" Spline, 21 Tooth
|
CAS
1 3/8"
|
| 11. |
1958268C1
|
[1] |
COUPLING
|
CAS
1 3/4"
|
| 12. |
136-251
|
[1] |
HAIR PIN COTTER,Int, 7/16" x .177"
|
CAS
|
| 13. |
84530
|
[1] |
ELBOW,90 Degree, 1 5/8"-12, 37 Degree x 1 5/8"-12, O-Ring
|
PA
|
| 14. |
293243A1
|
[1] |
PUMP
|
CAS
PTO 5.84 in3/rev Superseded by part number: 87619629
|
| 14. |
293243A1R
|
[1] |
REMAN-HYD PUMP
|
MKT
Remanufactured Hydraulic PTO Pump Superseded by part number: 87619629R
|
| 14. |
293243A1C
|
[1] |
CORE-HYDRAULIC PUMP
|
MKT
Return Number
|
| . . |
87619629R
|
[1] |
REMAN-HYD PUMP
|
SAS
2230 (7/08-), Reman For New P/N 293243A1
|
| . . |
87619629C
|
[1] |
CORE-HYDRAULIC PUMP
|
SAS
Return Number
|
| 14. |
Q53
|
[1] |
KEY,1/4" Sq x 1", Par
|
IH
|
| 14. |
280963
|
[1] |
NUT,Nut, 1/2-20 GR 5 ZND
|
NH
|
| 14. |
310572A1
|
[1] |
SEAL KIT
|
CAS
shaft pto pump
|
| 15. |
86624068
|
[2] |
HEADED PIN,7/16" x 1 1/4", G2
|
FOR
|
| 16. |
86624085
|
[1] |
HEADED PIN,15.88mm OD x 69.85mm L
|
FOR
|
| 17. |
GK-233
|
[1] |
PLATE
|
FLX
pump mounting
|
| 18. |
GK-234
|
[1] |
BRACKET
|
FLX
adjusting
|
| 19. |
GK-235
|
[1] |
STRAP
|
FLX
retaining
|
| 20. |
GK-236
|
[1] |
STRAP
|
FLX
assembly
|
