凯斯零件查询(AS1502) - CONCORD AIR SYSTEM (1/81-12/01) (52) - MODEL AS1502 DRIVE TRAIN ASSEMBLY Case Agriculture

作者：广数供应链运营团队
浏览数：
时间：2025-01-24 22:02:27
Parts Contact me WhatsApp

工程机械零件图册查询

专业 覆盖挖掘机、装载机、推土机全系配件
立即查询
Caterpillar 卡特彼勒 Komatsu 小松 SANY 三一重工 XCMG 徐工 Hitachi 日立建机 Volvo 沃尔沃 Liebherr 利勃海尔 John Deere 约翰迪尔 Zoomlion 中联重科 Doosan 斗山 Hyundai 现代 JCB 杰西博 Kobelco 神钢 LiuGong 柳工 Case 凯斯 Kubota 久保田 Terex 特雷克斯 Yanmar 洋马 Bobcat 山猫 Sandvik 山特维克 Metso 美卓 Manitou 曼尼通 Wacker Neuson 威克诺森 Shantui 山推 SDLG 临工 Lonking 龙工 Sunward 山河智能 Lovol 雷沃 XGMA 厦工 Kato 加藤 Tadano 多田野 Sumitomo 住友 Takeuchi 竹内 Bell 贝尔 Hidromek 海德罗梅克 Atlas Copco 阿特拉斯·科普柯 Wirtgen 维特根 Vögele 福格勒 Hamm 悍马 Bomag 宝马格 Ammann 安迈 Dynapac 戴纳派克 Genie 吉尼 JLG 捷尔杰 Skyjack 斯凯杰科 Haulotte 欧历胜 Palfinger 帕尔菲格 Hiab 希尔博 Sennebogen 森尼伯根 Yuchai 玉柴 Caterpillar 卡特彼勒 Komatsu 小松 SANY 三一重工 XCMG 徐工 Hitachi 日立建机 Volvo 沃尔沃 Liebherr 利勃海尔 John Deere 约翰迪尔 Zoomlion 中联重科 Doosan 斗山 Hyundai 现代 JCB 杰西博 Kobelco 神钢 LiuGong 柳工 Case 凯斯 Kubota 久保田 Terex 特雷克斯 Yanmar 洋马 Bobcat 山猫 Sandvik 山特维克 Metso 美卓 Manitou 曼尼通 Wacker Neuson 威克诺森 Shantui 山推 SDLG 临工 Lonking 龙工 Sunward 山河智能 Lovol 雷沃 XGMA 厦工 Kato 加藤 Tadano 多田野 Sumitomo 住友 Takeuchi 竹内 Bell 贝尔 Hidromek 海德罗梅克 Atlas Copco 阿特拉斯·科普柯 Wirtgen 维特根 Vögele 福格勒 Hamm 悍马 Bomag 宝马格 Ammann 安迈 Dynapac 戴纳派克 Genie 吉尼 JLG 捷尔杰 Skyjack 斯凯杰科 Haulotte 欧历胜 Palfinger 帕尔菲格 Hiab 希尔博 Sennebogen 森尼伯根 Yuchai 玉柴
Pos. Part No Qty Parts name Comments
1. 1013712 [1]   HUB ASSY.   CON HUB & SPROCKET ASSEMBLY (Refer to page 46-47)
2. 1012555 [1]   CHAIN (AG)   CAS CHAIN, #60 - 32 links Superseded by part number: 611362R91X
. . 1012557 [1]   LINK   CAS CONNECTING LINK, #60
3. 1012975 [3]   KEY   CAS 1/4" x 1/4" x 1 1/4" Superseded by part number: 86628576
4. 1012976 [2]   DRIVE SPROCKET   L SPROCKET, 10 tooth
5. 1012933 [1]   BAR   CON SHAFT, Serial Range: wheel-clutch
6. 1013285 [1]   CLUTCH   CON ASSEMBLY Superseded by part number: 86982786, 225115C1, 1021090
7. 1013045 [1]   BOLT   CON shoulder, 5/16" x 1/2"
8. 1011575 [1]   NUT,5/16"-18, G5   CAS hex, 5/16" Superseded by part number: 9635082
9. 1013225 [1]   PIN   CAS lynch
10. 1013559 [1]   SHAFT, Serial Range: clutch-gearbox
11. 1012930 [1]   PIN   CAS ROLL PIN, 5/16" dia. x 2" Superseded by part number: 87040910
12. 1012977 [1]   SPROCKET ASSY.   CON SPROCKET, gearbox, 26 tooth
13. 1013082 [1]   KEY
14. 1012556 [1]   CHAIN (AG)   CAS CHAIN, #60 - 48 links
15. 100908 [1]   GEARBOX ASSY   CAS GEARBOX (See breakdown page 56) Superseded by part number: 0100908
16. 1011599 [8]   BOLT   CON BOLT, hex, 3/8" x 3/4", Gr. 5 Superseded by part number: 86500692
17. 1013043 [4]   WASHER   CAS flat
18. 1013042 [1]   TUBE,1.017" ID, 1.5" OD   CAS COUPLER, gear box to cup
19. 1013218 [1]   PIN   L Shear
20. 1013044 [1]   SET SCREW   CAS 1/4" x 1/4"
21. 1013221 [1]   STRIP   CAS CLIP, shearpin hold
22. 1013243 [1]   BOLT   CON BOLT Superseded by part number: 88542
23. 100979 [1]   SELECTOR   CON Superseded by part number: 87361, 87361, A100979
24. 1013297 [1]   LOCK WASHER   CAS LOCK WASHER, 1/4" Superseded by part number: 80682
25. 1012986 [4]   BEARING ASSY,25.4mm ID   L BEARING, flange
26. 1012978 [4]   SEAL   L WASHER, rubber
27. 1011583 [20]   WASHER   CAS flat Superseded by part number: 80664
28. 280136 [18]   NUT,3/8"-16, G8   WIN hex, 5/8"
29. 1012559 [4]   HOUSING ASSY.   CON BEARING, pillow block Superseded by part number: 1021943, 86050277, 50591, 665721R1, 280497
30. 1011600 [8]   BOLT,Hex, 3/8" - 16 x 1", Gr 5   CAS BOLT, hex, 3/8" x 1" Superseded by part number: 88206
31. 1011601 [2]   BOLT   CON BOLT, hex, 3/8" x 1 1/4" Superseded by part number: 88011
32. 1012996 [2]   TUBE,1.03" ID, 1.5" OD   CAS COUPLER, cup to shaft
33. 1011725 [6]   BOLT   CON BOLT, hex, 3/8" x 2" Superseded by part number: 88436
34. 231-4246 [6]   LOCK NUT,3/8"-16, GB   CAS NUT, LOCK, 3/8"-16, GB Superseded by part number: 87039402
35. 1013920 [2]   SHAFT   CAS roll drive
36. 1012995 [1]   BAR   CON SHAFT, Serial Range: cup-cup
37. 1012608 [2]   ROLL   L DRIVE ASSEMBLY
38. 1013301 [1]   JOINT   CAS UNIVERSAL JOINT
39. 1013292 [1]   CRANK   CON ASSEMBLY Superseded by part number: 1032470
40. 1013310 [2]   DEFLECTOR   CAS ASSEMBLY (Includes 41, 42, 43, 44, 45)
41. 1012955 [1]   DEFLECTOR   CAS PLATE ASSEMBLY, deflector
42. 1013128 [1]   DEFLECTOR   L RUBBER, deflector
43. 1013127 [1]   STRIP   CAS PLATE, hold
44. 1011595 [8]   BOLT,Hex, 1/4" - 20 x 3/4", Gr 5, Full Thd   CON BOLT, hex, 1/4" x 3/4", Gr. 5 Superseded by part number: 9707580
45. 1013240 [8]   LOCK NUT,1/4"-20, GB   CON LOCKNUT, 1/4" Superseded by part number: 86625061
46. 1011828 [8]   WASHER   CAS
47. 1011586 [4]   LOCK WASHER   CAS LOCK WASHER, 3/8" Superseded by part number: 80680
48. 1013924 [1]   COLLAR   CON Superseded by part number: 1013418
49. 1013395 [1]   BOLT   CON BOLT Superseded by part number: 280699
50. 1016218 [2]   COVER ASSY   CAS COVER AND WIPER ASSEMBLY (Includes 51, 52, 53, 54, 55)
51. 1016215 [2]   COVER   CAS ASSEMBLY Superseded by part number: 1016218
52. 1013129 [2]   WINDSHIELD WIPER   CAS WIPER, rubber Superseded by part number: 1030985
53. 1013126 [2]   ANGLE   CON hole
54. 1013244 [8]   SCREW   CON Superseded by part number: 1032095
55. 1011588 [8]   NUT,#10-24   CON Superseded by part number: 87304
56. 1013283 [1]   DOOR ASSY.   CAS CLEANOUT DOOR ASSEMBLY (Includes 57, 58, 59, 60, 61, 62)
57. 1013176 [1]   COVER   L DOOR
58. 1013177 [1]   SUPPORT   CAS STRIP, narrow
59. 1013178 [1]   STRIP   CAS wide
60. 1013284 [1]   ANGLE   CAS LATCH ANGLE ASSEMBLY
63. 1015082 [2]   DOOR ASSY.   CON METERING DOOR ASSEMBLY (Includes 78 & 81)
64. 1015678 [2]   PLATE   CON FLOW CONTROL ASSEMBLY Superseded by part number: 1032088
65. 1015419 [2]   TIE-ROD   CON ROD ASSEMBLY Superseded by part number: 87305, 1013859
66. 1014236 [1]   DUST COVER
67. 1013922 [1]   BRACKET   CON counter
68. 1012475 [1]   COUNTER   CON - acre
69. 1013926 [2]   SCREW   CON
70. 280597 [2]   NUT,#5-40   GI
71. 1016221 [2]   GASKET   CON Superseded by part number: 1018874
72. 1016223 [2]   GASKET   CON GASKET
73. 1016222 [2]   GASKET   CON
74. 1016224 [2]   GASKET   CON
75. 1016213 [2]   TOGGLE   CAS ASSEMBLY
76. 1013281 [1]   TOOL   CAS WRENCH
77. 1013097 [2]   GUSSET   CON BOLT
78. 86636814 [4]   LUBE NIPPLE,1/4"-28 x .52" lg   GI NIPPLE, LUBE, 1/4"-28 x .52" lg Superseded by part number: 88775
79. 1013895 [2]   THUMB SCREW   CAS THUMBSCREW
80. 1011591 [2]   NUT,Jam, 1/2"-13, G5   CON hex, 1/2" jam Superseded by part number: 86632558
81. 1013346 [2]   PINION   CAS meter door
