| 1. |
1016276
|
[1] |
HARNESS
|
CON
WIRING HARNESS, tractor
|
| 2. |
1016352
|
[15] |
CLAMP
|
CAS
harness
|
| 3. |
100862
|
[15] |
GASKET
|
CAS
SCREW Superseded by part number: 87470518
|
| 4. |
1016277
|
[1] |
HARNESS
|
CON
WIRING HARNESS, tillage system
|
| 5. |
1016279
|
[1] |
HARNESS
|
CON
WIRING HARNESS, air system 1502
|
| . . |
1016278
|
[1] |
ASSEMBLY
|
CON
WIRING HARNESS, air system 1002
|
| 6. |
1016121
|
[2] |
SENSOR
|
CAS
bin level Superseded by part number: 1027706
|
| 7. |
1014728
|
[8] |
SCREW
|
CAS
#10 x .75, full thread
|
| 8. |
1016237
|
[8] |
WASHER
|
CAS
flat Superseded by part number: 9824326
|
| 9. |
1013389
|
[8] |
THRUST WASHER
|
CON
LOCKWASHER, star Superseded by part number: 280254
|
| 10. |
1011588
|
[8] |
NUT,#10-24
|
CON
hex, #10 Superseded by part number: 87304
|
| 11. |
1016280
|
[1] |
HARNESS
|
CON
WIRING HARNESS, tach & engine
|
| 12. |
1016300
|
[1] |
SENSOR
|
L
PICK-UP, magnetic Superseded by part number: 1025814, BN2401945
|
| 13. |
1016068
|
[1] |
METER
|
L
TACHOMETER
|
| 14. |
1016281
|
[1] |
HARNESS
|
CAS
WIRING HARNESS, ignition & oil pressure
|
| 15. |
1016194
|
[1] |
IGNITION SWITCH
|
L
SWITCH, starter & ignition
|
| 16. |
1016193
|
[1] |
PANEL, INSTRUMENTS
|
CON
INSTRUMENT PANEL
|
| 17. |
1016234
|
[3] |
CLAMP
|
CAS
harness
|
| 18. |
1014125
|
[4] |
LOCK WASHER
|
CAS
LOCKWASHER Superseded by part number: 92-11031
|
| 19. |
1011575
|
[4] |
NUT,5/16"-18, G5
|
CAS
hex Superseded by part number: 9635082
|
| 20. |
1016235
|
[2] |
GROMMET
|
CAS
|
| 21. |
1016247
|
[2] |
CHANNEL
|
CAS
wire protector, 32" long
|
| 22. |
1016249
|
[1] |
CHANNEL
|
CAS
harness protector, 96" long
|
| 24. |
1016466
|
[1] |
ELECTRICAL WIRE
|
CAS
WIRE, tachometer ground
|
| 25. |
1016492
|
[2] |
LOCK NUT
|
CON
NUT, jam Superseded by part number: 219758
|
