| 1. |
1013988
|
[1] |
MOTOR, HYDRAULIC
|
CAS
(Volvo Model F-11-10)
|
| . . |
1013988R
|
[1] |
REMAN-HYD MOTOR
|
CAS
AS1002, AS1502
|
| . . |
1013988C
|
[1] |
CORE-MOTOR HYDRAULIC
|
CAS
Return Number
|
| . . |
312672A1
|
[1] |
SEAL KIT
|
CON
Seal Kit For 1013988
|
| 2. |
1016351
|
[1] |
PLATE, motor mounting
|
|
| 3. |
1011607
|
[2] |
BOLT
|
L
BOLT, hex, 1/2" x 1 1/2" Superseded by part number: 87689
|
| 4. |
231-1448
|
[2] |
NUT,1/2"-13, GB
|
CAS
hex, 1/2" (Lock) Superseded by part number: 87530607
|
| 5. |
1014349
|
[2] |
BOLT
|
CON
BOLT, hex, 5/8" x 1 1/2" Superseded by part number: 88062
|
| 6. |
231-14410
|
[2] |
NUT,5/8"-11, GB
|
CAS
NUT, LOCK, 5/8"-11, GB Superseded by part number: 86639566
|
| 7. |
1015124
|
[1] |
SHEAVE
|
CON
(Driver)
|
| 8. |
1015125
|
[1] |
HUB
|
CON
|
| 9. |
1015993
|
[1] |
SET OF BELTS,0.38" W
|
CON
Side (One matched pair) 0.38" W
|
| 10. |
1015116
|
[1] |
GUARD ASSEMBLY, belt
|
|
| 11. |
1011909
|
[2] |
BOLT
|
CON
BOLT, hex, 5/8" x 1 1/4" Superseded by part number: 280319
|
| 12. |
1011578
|
[2] |
NUT,5/8"-11, G5
|
CON
hex, 5/8" Superseded by part number: 280374
|
| 13. |
1011602
|
[2] |
BOLT
|
CON
BOLT, hex, 3/8" x 1 1/2" Superseded by part number: 88044
|
| 14. |
280136
|
[2] |
NUT,3/8"-16, G8
|
WIN
|
| 15. |
1014879
|
[1] |
BELT
|
CAS
GUARD, belt
|
| 16. |
1014868
|
[1] |
HUB
|
CAS
|
| 17. |
1014865
|
[1] |
SHEAVE
|
CAS
(Driven)
|
| 18. |
1014870
|
[1] |
KEY
|
CAS
square, 3/16" x 1 1/4"
|
| 19. |
1014982
|
[4] |
TUBE,0.406" ID, 0.625" OD
|
CON
BOSS, 5/8" OD x 13/32" ID x 1/2"
|
| 20. |
1014983
|
[4] |
BRACKET
|
CON
PLATE
|
| 21. |
1013239
|
[4] |
BOLT
|
L
BOLT, hex, 3/8" x 3" Superseded by part number: 280161
|
| 22. |
1011586
|
[4] |
LOCK WASHER
|
CAS
LOCKWASHER, 3/8" Superseded by part number: 80680
|
| 24. |
1012196
|
[2] |
END
|
CAS
TIE ROD END, LH
|
| . . |
1012197
|
[2] |
END
|
CAS
TIE ROD END, RH
|
| 25. |
1012200
|
[2] |
ROD
|
CON
TIE ROD
|
| 26. |
CON1013289
|
[2] |
NUT,Sq, Jam, 11/16"-18
|
CON
jam, RH
|
| 27. |
1015131
|
[2] |
ELBOW
|
CAS
ADAPTOR, 1-1/16", 37 degree flare Superseded by part number: 144120
|
| 28. |
1015130
|
[1] |
ELBOW
|
CAS
ADAPTER, 3/4", 37 degree flare Superseded by part number: 216791
|
| 29. |
1015025
|
[2] |
HYD TUBE,19.1 mm Diameter, 3048 mm Length
|
CON
TUBE ASSEMBLY, 3/4" tube (1502 Model)
|
| . . |
1015020
|
[2] |
TUBE ASSEMBLY, 3/4" tube (1002 Model)
|
|
| 30. |
1015026
|
[1] |
HYD TUBE,12.7 mm Diameter, 3048 mm Length
|
CON
TUBE ASSEMBLY, 1/2" tube (1502 Model)
|
| . . |
1015021
|
[1] |
TUBE ASSEMBLY, 1/2" tube (1002 Model)
|
COVER
|
| 31. |
1015017
|
[1] |
HOSE ASSY.
|
CAS
HOSE, 3/4" JIC-F-Swivel x 9/16" straight x 44"
|
| 32. |
1015015
|
[2] |
HOSE, 1-1/16" JIC-F-Swivel x 1/2" NPT x 34"
|
|
| 33. |
1015016
|
[2] |
HOSE ASSY.
|
CON
HOSE, 1/2" NPT-M x 1-1/16" SAE x 34"
|
| 34. |
1014894
|
[1] |
PLATFORM PLATE
|
|
| 35. |
1015019
|
[4] |
CLAMP
|
CAS
tube Superseded by part number: S97491
|
| 36. |
1015018
|
[2] |
CLAMP
|
CAS
tube Superseded by part number: S97489
|
| 37. |
1013023
|
[2] |
BOLT
|
CON
BOLT, hex, 5/8" x 2 1/2" Superseded by part number: 280233
|
| 38. |
1013004
|
[2] |
WASHER
|
CAS
flat Superseded by part number: 87365
|
| 39. |
1011813
|
[2] |
LOCK WASHER
|
CON
LOCKWASHER, 5/8" Superseded by part number: 86729275
|
| 41. |
1015000
|
[1] |
HYDRAULIC VALVE ASSEMBLY (Inlcudes Ref. 42-49)
|
DISC
|
| 42. |
1014995
|
[2] |
ELBOW
|
CAS
90 degree swivel, 1/2" NPT Superseded by part number: 87331082
|
| 43. |
1014993
|
[2] |
CROSS
|
CON
TEE, 1/2" NPT
|
| 44. |
1014992
|
[2] |
NIPPLE, 1/2" NPT
|
|
| 45. |
1014991
|
[1] |
VALVE, CHECK
|
CON
CHECK VALVE, 1/2" NPT
|
| 46. |
1014996
|
[2] |
REDUCER
|
CON
1/2" NPT - 3/8" NPT
|
| 47. |
1014997
|
[1] |
FITTING
|
CAS
CHECK VALVE, 3/8" NPT
|
| 48. |
1014998
|
[1] |
FLOW VALVE
|
|
| 49. |
1015002
|
[1] |
HOSE ASSY.
|
CON
HOSE, 1/2" NPT-M x 1/2" NPT-M swivel
|
