| 1. |
214-1444
|
[136] |
HOSE CLAMP,58.6mm - 82.5mm
|
CAS
Superseded by part number: 86050197
|
| 2. |
7770
|
[24] |
NUT,Hex, 1/4 - 20, Cl 5
|
NH
|
| 3. |
80681
|
[2] |
LOCK NUT,5/16"
|
NH
Superseded by part number: 83990583
|
| 4. |
9635082
|
[4] |
NUT,5/16" - 18, Gr 5
|
NH
|
| 5. |
95-21031
|
[36] |
WASHER,1/4"
|
CAS
Superseded by part number: 80701
|
| 6. |
80664
|
[4] |
WASHER,0.38" ID x 0.88" OD x 0.08" Thk
|
NH
|
| 7. |
80702
|
[16] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
|
| 8. |
280299
|
[16] |
WASHER,0.19" ID x 0.44" OD x 0.05" Thk
|
NH
|
| 9. |
80755
|
[3] |
COTTER PIN,1/8" OD x 1" L
|
NH
|
| 10. |
87653
|
[6] |
NUT,#8-32
|
WIN
Superseded by part number: 86977693
|
| 11. |
412750A1
|
[3] |
SCREW,Sl, #8 - 32 x 3/4"
|
FLX
mch #8-32 x 3/4" ph sq-slt
|
| 12. |
9707580
|
[46] |
BOLT,Hex, 1/4" - 20 x 3/4", Gr 5, Full Thd
|
NH
|
| 13. |
80682
|
[28] |
LOCK WASHER,1/4"
|
PA
|
| 14. |
280129
|
[18] |
NUT,1/4"-20
|
NH
|
| 15. |
86507008
|
[2] |
BOLT,Hex, 5/16" - 18 x 3 1/2", Gr 5
|
IMO
|
| 16. |
88964
|
[2] |
BOLT,Hex, 5/16" - 18 x 4", Gr 5
|
PA
|
| 17. |
86632557
|
[4] |
JAM NUT,Jam, 3/4"-10, G5
|
GFD
|
| 18. |
4731
|
[16] |
CAP
|
FLX
vinyl 2 1/2" id x 1" long
|
| 19. |
GD-388
|
[9] |
CHAIN
|
SAS
safety, inlet shield - 9"
|
| 20. |
7187
|
[24] |
PLUG
|
FLX
manifold transition
|
| 21. |
8275
|
[2] |
PIN,3/4" - 10 x 9.75"
|
FLX
pin locator, center manifold
|
| 22. |
8293
|
[3] |
CAP
|
FLX
storage tube
|
| 23. |
9148
|
[6] |
LOCK NUT
|
FLX
#10-32, stainless steel
|
| 24. |
9475
|
[24] |
TUBE
|
FLX
manifold transition, velocity sensor
|
| 25. |
425095A1
|
[24] |
PLUG
|
FLX
manifold transition - velocity sensor
|
| 26. |
425043A1
|
[3] |
TUBE
|
FLX
storage & cap, 17 3/16"
|
| 27. |
7777
|
[6] |
SCREW,Pan Hd, #10 - 32 x 1"
|
FLX
mch #10-32 x 1" ph Phillips ss
|
| 28. |
9586
|
[8] |
FLANGE NUT
|
FLX
flange 5/16" serrated
|
| 29. |
21319
|
[8] |
BOLT
|
FLX
5/16"-18 x 1" ss hx-skt
|
| 30. |
22409
|
[1] |
DECAL
|
FLX
center manifold cleanout
|
| 31. |
22577
|
[12] |
BOLT
|
FLX
1/4"-20 x 1 1/4", G5, all thread
|
| 32. |
13637V2
|
[3] |
SENSOR
|
SAS
air flow
|
| 33. |
CA-142
|
[3] |
SPACER
|
FLX
air velocity sensor
|
| 34. |
GD-602
|
[16] |
HOSE,2.50" ID x 2.25"
|
FLX
|
| 35. |
GH-522A
|
[8] |
VALVE
|
FLX
single/double shoot, Years: -31-MAR-03 Superseded by part number: 448080A1
|
| 35. |
448080A1
|
[8] |
VALVE
|
SAS
single / double shoot, Start Year: 01-APR-03
|
| 36. |
GL-116
|
[3] |
SPACER
|
FLX
plate transition manifold rear
|
| 37. |
GL-440
|
[1] |
MANIFOLD
|
FLX
double shoot - center
|
| 38. |
GL-441
|
[1] |
MANIFOLD
|
FLX
triple shoot - center
|
| 39. |
GL-442
|
[3] |
PANEL
|
FLX
mount, transition manifold
|
| 40. |
GL-443
|
[3] |
MANIFOLD
|
FLX
outlet
|
| 41. |
GL-444
|
[2] |
CARRIER
|
FLX
center manifold
|
| 42. |
GL-452
|
[8] |
HOSE,2.50" ID x 6.44"
|
FLX
|
| 43. |
GL-460
|
[6] |
SPACER
|
FLX
tube mount
|
| 44. |
GL-700.06
|
[2] |
DECAL
|
FLX
triple shoot valve a
|
| 45. |
GL-700.21
|
[1] |
CAUTION DECAL
|
FLX
keep hands
|
| 46. |
GL-700.22
|
[2] |
DECAL
|
FLX
two outlet valve a
|
| 47. |
GL-454A
|
[8] |
VALVE
|
FLX
assembly, triple shoot
|
