| 1. |
9706729
|
[8] |
BOLT,Hex, 7/16" - 14 x 1", Gr 5, Full Thd
|
NH
|
| 2. |
88206
|
[6] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
NH
|
| 3. |
87670
|
[4] |
BOLT,1/2" - 13 x 1-1/4", Full Thd, Gr 5
|
NH
|
| 4. |
87689
|
[8] |
BOLT,1/2"-13 x 1.813" OAL, Gr 5
|
NH
|
| 5. |
280980
|
[28] |
NUT,7/16"-14, GC
|
NH
|
| 6. |
86992215
|
[12] |
LOCK NUT,1/2"-13, GC
|
GFD
|
| 7. |
80702
|
[54] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
|
| 8. |
80700
|
[16] |
WASHER,0.56" ID x 1.38" OD x 0.11" Thk
|
NH
|
| 9. |
87337
|
[4] |
BOLT,Hex, 3/4" - 10 x 3", Gr 5
|
NH
|
| 10. |
80680
|
[6] |
LOCK WASHER,3/8 0.381 CST ZND
|
NH
|
| 11. |
280375
|
[4] |
NUT,3/4"-10, GC
|
WIN
|
| 12. |
86632557
|
[8] |
JAM NUT,Jam, 3/4"-10, G5
|
GFD
|
| 13. |
9637916
|
[20] |
BOLT,Hex, 7/16" - 14 x 1 1/2", Gr 5
|
NH
|
| 14. |
6717
|
[4] |
BOLT,Hex, 3/4" - 10 x 5", Gr 5, Full Thd
|
FLX
|
| 15. |
88612
|
[5] |
WASHER,0.22mm ID x 0.5mm OD x 0.05mm Thk
|
GI
Superseded by part number: 9824326
|
| 16. |
20332
|
[5] |
LOCK NUT,#10-32, GB
|
BEL
|
| 17. |
7777
|
[5] |
SCREW,Pan Hd, #10 - 32 x 1"
|
FLX
mch #10-32 x 1" ph Phillips ss
|
| 18. |
311863A1
|
[2] |
REFLECTOR
|
CAS
reflector red 1 3/8" x 7 1/4"
|
| 19. |
311864A1
|
[6] |
REFLECTOR
|
CAS
Retroreflective Amber 1.375" x 7.25"
|
| 20. |
9977
|
[5] |
WASHER
|
FLX
1/64" id 5/8" 1/16" ss
|
| 21. |
9978
|
[5] |
SPACER
|
FLX
3/16" id x 3/8" od x 1/4"
|
| 22. |
51200060
|
[2] |
SEAL
|
FLX
wide tank interface
|
| 23. |
51200112
|
[1] |
COVER
|
FLX
upper abs front tank key
|
| 24. |
51200113
|
[1] |
COVER
|
FLX
lower abs front tank key
|
| 25. |
351904A1
|
[1] |
DECAL
|
FLX
adx 3360 LH
|
| 25. |
425570A1
|
[1] |
DECAL
|
FLX
adx3360 LH concord
|
| 26. |
351905A1
|
[1] |
DECAL
|
FLX
adx3360 RH
|
| 26. |
425571A1
|
[1] |
DECAL
|
FLX
adx3360 RH concord
|
| 27. |
GD-500.71
|
[1] |
WARNING DECAL
|
FLX
Do Not Ride
|
| 28. |
GD-500.79
|
[1] |
WARNING DECAL
|
FLX
Stop Fan
|
| 29. |
GL-294
|
[1] |
PLATE
|
FLX
decal tank safety
|
| 30. |
GL-700.08
|
[1] |
DECAL
|
FLX
attention before filling
|
| 31. |
GL-700.15
|
[2] |
DECAL
|
FLX
tank 1
|
| 32. |
GL-700.16
|
[2] |
DECAL
|
FLX
tank 2
|
| 33. |
GL-700.17
|
[2] |
DECAL
|
FLX
tank 3
|
| 34. |
GL-804
|
[2] |
RETAINER
|
FLX
lower key cover
|
| 35. |
GL-819
|
[1] |
SUPPORT
|
FLX
key
|
| 36. |
GL-130FR
|
[2] |
SUPPORT
|
FLX
tank side rail top
|
| 37. |
GL-131FR
|
[2] |
SUPPORT
|
FLX
tank end rail bottom
|
| 38. |
GL-140FR
|
[4] |
SUPPORT
|
FLX
tank rail
|
| 39. |
GL-153FR
|
[2] |
SUPPORT
|
FLX
tank side btm
|
| 40. |
GL-156FR
|
[2] |
SUPPORT
|
FLX
tank end top
|
| 41. |
GL-607FR
|
[4] |
STRAP
|
FLX
anchor tank seal
|
| 42. |
GM-621
|
[1] |
TANK
|
FLX
-97 bushel keyed ms40-10 Superseded by part number: 87417292
|
| 42. |
87420890
|
[1] |
TANK
|
SAS
116 bushel female Superseded by part number: 87417292
|
| 43. |
GM-622
|
[1] |
TANK
|
FLX
89 bushel center
|
| 44. |
GM-623
|
[1] |
TANK
|
FLX
154 bushel male
|
| 45. |
GM-480FR
|
[1] |
PLATE
|
FLX
decal 360bu LH, Years: -01-JUN-06
|
| 46. |
GM-481FR
|
[1] |
DECAL
|
FLX
plate right 360bu, Years: -01-JUN-06
|
| 100. |
GM-304K
|
[1] |
KIT
|
SAS
tank pull down
|
