| 1. |
86505980
|
[4] |
BOLT,Hex, 3/8" - 16 x 4 1/2", Gr 5
|
WIN
|
| 2. |
20304
|
[4] |
BOLT,Hex, 3/8" - 16 x 5 1/2", Gr 5
|
WIN
|
| 3. |
281010
|
[4] |
LOCK NUT,7/8"-14, GC
|
BAS
|
| 4. |
88902
|
[4] |
NUT,3/8"-16
|
NH
|
| 5. |
88959
|
[4] |
BOLT,Hex, 3/8" - 16 x 3 1/2", Gr 5
|
NH
|
| 6. |
86624953
|
[4] |
BOLT
|
SAS
3/8"-16 x 9 1/2" GR5
|
| 7. |
51200882
|
[1] |
HYDRAULIC HOSE,1.25" ID x 64.00", SAE 100R4, SAE J517, SAE J516, SAE 100R17, ASTM B633 Class 2 Type 2
|
FLX
1 1/4" x 64" fl, 1 1/4" fjic x 1 1/4" fjic
|
| 8. |
115872A1
|
[1] |
RESERVOIR, HYDRAULIC
|
CAS
4.5 us gal Superseded by part number: 84252960
|
| 8. |
87439695
|
[1] |
RESERVOIR, HYDRAULIC
|
SAS
4.5 us gal Superseded by part number: 84252960
|
| 8. |
129575A1
|
[1] |
CAP
|
CAS
breather with dipstick
|
| 8. |
87435908
|
[1] |
SCREEN
|
RAC
reservoir
|
| 9. |
116093A1
|
[2] |
STRAP
|
CAS
oil reservoir tank
|
| 10. |
84530
|
[1] |
ELBOW,90 Degree, 1 5/8"-12, 37 Degree x 1 5/8"-12, O-Ring
|
PA
|
| 11. |
322894
|
[1] |
90 ELBOW,1-1/16" - 12 JIC x 1-1/16" - 12 ORB
|
BHB
|
| 12. |
86624101
|
[1] |
PLUG,Hex Hd, 1 5/8"-12 ORB
|
FOR
|
| 13. |
163410
|
[1] |
PLUG,1-1/16" - 12 ORB
|
NH
|
| 14. |
GK-208
|
[2] |
PLATE
|
FLX
bolt
|
| 15. |
GK-238
|
[1] |
BRACKET
|
FLX
mount, pto reservoir
|
