| 0. |
13345V2
|
[1] |
KIT
|
FLX
electrical connector
|
| 1. |
425264A1
|
[2] |
ELEC CONNECTOR,14 Pin
|
FLX
metal 14c receptacle
|
| 2. |
425290A1
|
[2] |
PLUG
|
FLX
connector, elec metal 14c
|
| 3. |
225227C1
|
[2] |
ELEC CONNECTOR,Female, 9 Pin
|
CAS
Plastic 9c Plug Superseded by part number: 87706950
|
| 4. |
245329C1
|
[2] |
CONNECTOR, ELEC
|
CAS
CONNECTOR elec metal 23c plug Superseded by part number: 9801130
|
| 5. |
225224C1
|
[2] |
ELEC CONNECTOR,Female, 5 Pin
|
IH
plastic 5c plug Superseded by part number: 87706919
|
| 6. |
795231
|
[2] |
TERMINAL CONNECTOR,Female, 16 SAE
|
NH
plastic 3c plug Superseded by part number: 87706509
|
| 7. |
225222C1
|
[2] |
ELEC CONNECTOR,Male, 5 Pin
|
IH
plastic 5c receptacle fl Superseded by part number: 87706918
|
| 8. |
86500036
|
[20] |
TERMINAL,Female, Nickel, 0.75 - 2mm
|
PA
16-18awg
|
| 9. |
225348C1
|
[20] |
ELEC. TERMINAL PIN,Male, 0.75 - 2.00 mm2
|
CAS
pin 16-18awg Superseded by part number: 87695607
|
| 10. |
225404C1
|
[20] |
POWER SOCKET,Nickel, 1.0 - 2.0mm
|
CAS
socket 14-16awg
|
| 11. |
225406C1
|
[20] |
ELEC. TERMINAL PIN,Male, 1 - 2 mm2
|
CAS
pin 14-16awg Superseded by part number: 87694144
|
| 12. |
84068583
|
[10] |
PLUG,12 - 16 Ga, White
|
ZED
connector cavity white plastic Superseded by part number: 87695652
|
| 13. |
225226C1
|
[2] |
CONNECTOR, ELEC
|
CAS
CONNECTOR elec plastic 9c receptacle Superseded by part number: 75310819
|
| 14. |
51200869
|
[5] |
TOOL
|
FLX
extraction Deutsch size 16
|
| 15. |
425266A1
|
[1] |
TOOL
|
FLX
hand crimp - Deutsch
|
| 20. |
245715C1
|
[5] |
ELEC CONNECTOR,4 Pin
|
IH
plastic 4c plug
|
| 21. |
87692855
|
[5] |
CONTACT HOUSING,Male, 2 Cavities
|
BN
plastic 2c plug
|
| 22. |
87644909
|
[5] |
WIRE CONNECTOR,Female, 3 Pins
|
BN
plastic 3c plug
|
| 23. |
87692877
|
[5] |
MULTIPOLE CONNECTOR,Male, 2 Cavities
|
BN
plastic 2c receptacle
|
| 24. |
245485C1
|
[5] |
ELEC CONNECTOR,Male, 3 Pin
|
IH
plastic 3c receptacle Superseded by part number: 87692858
|
| 25. |
245716C1
|
[5] |
ELEC CONNECTOR,Male, 4 Pin
|
IH
plastic 4c receptacle Superseded by part number: 87692881
|
| 26. |
872290R1
|
[5] |
ELEC CONNECTOR,Male
|
IH
Plastic 2c Receptacle Superseded by part number: 87697530
|
| 27. |
225123C1
|
[10] |
TERMINAL CONNECTOR,Tin, 0.8mm
|
IH
socket 18-20awg
|
| 28. |
225122C1
|
[10] |
TERMINAL CONNECTOR,Tin, 1.0 - 2.0mm
|
IH
socket 14-16awg
|
| 29. |
225119C1
|
[10] |
TERMINAL
|
IH
14-16awg Superseded by part number: 87692882
|
| 30. |
225120C1
|
[10] |
TERMINAL CONNECTOR,Tin, 0.8mm
|
IH
18-20awg
|
| 31. |
1120922C1
|
[10] |
ELEC CONNECTOR,Male, 1 - 2 mm2
|
IH
blade 14-16awg Superseded by part number: 87693724
|
| 32. |
225124C1
|
[20] |
SEAL,2 - 2.9 mm2
|
IH
seal grn 2.8-2 omm Superseded by part number: 84286327
|
| 33. |
225125C1
|
[10] |
SEAL
|
IH
Connector Grey 3.49 - 2.81 mm Superseded by part number: 87680710
|
| 34. |
1964525C1
|
[5] |
TOOL
|
CAS
extraction - Packard, weather pack
|
| 35. |
425267A1
|
[1] |
TOOL
|
FLX
hand crimp - Packard, weather pack
|
| 40. |
425057A1
|
[2] |
ELEC CONNECTOR,4 Pin
|
FLX
plastic 4c plug
|
| 41. |
10565
|
[2] |
ELEC CONNECTOR,4 Pin
|
FLX
plastic 4c receptacle
|
| 42. |
700718605
|
[10] |
TERMINAL
|
CAS
pin 20-24awg
|
| 43. |
225109C1
|
[30] |
POWER SOCKET,Gold, 0.8 - 1.0mm
|
IH
socket 16-18awg
|
| 44. |
1964524C1
|
[2] |
TOOL KIT
|
CAS
Removal
|
| 45. |
ZJI2
|
[1] |
TOOL
|
CAS
hand crimp - amp type III+
|
| 50. |
51200018
|
[1] |
PLIERS
|
FLX
cutter/stripper
|
| 51. |
425268A1
|
[1] |
TOOL BOX
|
FLX
complete Superseded by part number: HP2271
|
| 52. |
221731A1
|
[6] |
ELEC CONNECTOR,Female, 24 Pin
|
CAS
plastic 24c plug Superseded by part number: 87680639
|
| 53. |
225171C1
|
[6] |
ELEC CONNECTOR,Female, 16 Pin
|
IH
plastic 16c plug Superseded by part number: 87686681
|
| 54. |
87675194
|
[1] |
MULTIPOLE CONNECTOR,Female, 3 Pole
|
SAS
plastic 3c plug
|
| 55. |
425260A1
|
[1] |
CONTACT HOUSING
|
FLX
socket 20-24awg
|
| 56. |
445518
|
[1] |
TERMINAL CONNECTOR,Tin, 5.00 - 8.00mm
|
ZED
socket 8-10awg Superseded by part number: 87680653
|
| 57. |
425265A1
|
[1] |
CONTACT HOUSING
|
FLX
socket 14-18awg
|
| 58. |
425097A1
|
[1] |
HANDBOOK
|
FLX
reference card, connector service kit
|
