| 1. |
507586
|
[4] |
HOSE CLAMP,20.6mm - 44.4mm, Worm Gear
|
PA
|
| 2. |
280299
|
[8] |
WASHER,0.19" ID x 0.44" OD x 0.05" Thk
|
NH
|
| 3. |
412750A1
|
[8] |
SCREW,Sl, #8 - 32 x 3/4"
|
FLX
mch #8-32 x 3/4" ph sq-slt
|
| 4. |
88992
|
[1] |
CARRIAGE BOLT,Short Sq Nk, 5/16" - 18 x 1", Gr 5
|
GI
|
| 5. |
231-14408
|
[8] |
NUT,#8-32, GB
|
CAS
Superseded by part number: 87319809
|
| 6. |
5186
|
[2] |
SIGHTGLASS
|
FLX
lexan view, Years: -01-JUN-02
|
| 7. |
8633
|
[1] |
WASHER
|
FLX
7/16" id x 1" od x 5/64" thick, ss
|
| 8. |
9528
|
[2] |
HEX SOC SCREW,Sl Rnd Hd, #10 - 32 x 0.50", SST
|
FLX
machine #10-32 x 1/2" rh skt-slt ss
|
| 9. |
9586
|
[1] |
FLANGE NUT
|
FLX
flange 5/16" serrated
|
| 10. |
9587
|
[22] |
LOCK WASHER
|
FLX
#10 ss
|
| 11. |
9588
|
[2] |
SCREW,Sl Sq, #10 - 32 x 1.50"
|
FLX
mch #10-32 x 1 1/2" rh sq-slt ss
|
| 12. |
9589
|
[1] |
NUT
|
FLX
#10-32 ss
|
| 13. |
87508154
|
[1] |
SENSOR
|
SAS
Optical Bin Level
|
| 14. |
14868V2
|
[1] |
SENSOR
|
FLX
sonar bin level 0.3m cable
|
| 15. |
GI-667
|
[1] |
AIR HOSE,1.25" ID x 42.00"
|
FLX
Tank Pressurization 3rd Tank
|
| 15. |
GI-668
|
[1] |
AIR HOSE,1.25" ID x 52.00"
|
FLX
Pressure 3rd Tank
|
| 15. |
412786A1
|
[1] |
HOSE
|
FLX
1 1/4" pvc clear spiral 1/8" wall must be ordered in multiples of 100
|
| 17. |
GL-349
|
[1] |
BRACKET
|
FLX
mount, bin level sensor - ultrasonic
|
