| 1. |
1960244C1
|
[1] |
DRIVE PLATE
|
CAS
BRACKET - chute drive
|
| 2. |
434-616
|
[3] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
BOLT - round head square neck, 3/8 NC x 1 inch Superseded by part number: 80280503
|
| 3. |
21752R1
|
[3] |
WASHER
|
IH
- flat, 13/32 x 1-1/2 x 3/64 inch Superseded by part number: 495-81142
|
| 4. |
482256R1
|
[3] |
BEARING LOCK NUT,Flg, USR, 3/8"-16
|
IH
- hex lock, 3/8 inch NC Superseded by part number: 247780
|
| 5. |
1960245C1
|
[1] |
CABLE ASSY.
|
CAS
CABLE - drive
|
| 6. |
1960254C1
|
[1] |
BRACKET
|
CAS
- level wind
|
| 7. |
1960247C1
|
[1] |
STRAP
|
CAS
- friction
|
| 8. |
1960246C1
|
[1] |
U-BOLT
|
CAS
|
| 9. |
131-1180
|
[2] |
LOCK NUT,1/4"-20, GA
|
CAS
NUT, LOCK, 1/4"-20, GA Superseded by part number: 87034810
|
| 12. |
1960248C1
|
[1] |
MOTOR
|
CAS
ASSEMBLY - chute drive
|
| 13. |
280-1478
|
[3] |
SELF-TAP SCREW,HWH, 1/4-14 x 1/2"
|
CAS
SCREW - self-tapping, 1/4 NC x 1/2 inch Superseded by part number: 86625162
|
| 14. |
1960256C1
|
[1] |
PLUG
|
CAS
ADAPTER - wire harness
|
| 15. |
1960250C1
|
[1] |
ELECTRICAL WIRE
|
CAS
HARNESS - electrical, chute drive
|
| 16. |
1960249C1
|
[1] |
SWITCH
|
CAS
- chute drive
|
| 17. |
1960251C1
|
[2] |
CLIP
|
CAS
- retaining
|
| 18. |
289862C1
|
[2] |
CABLE TIE,3/16" x 7"
|
IH
STRAP - retaining Superseded by part number: 529070
|
| 19. |
102575A1
|
[1] |
WASHER
|
CAS
- wheel stop
|
| 20. |
495-21050
|
[1] |
WASHER,7/16"
|
CAS
- flat, 1/2 x 1-1/4 x 5/64 inch Superseded by part number: 81541
|
| 21. |
1976315C1
|
[1] |
BREAKER
|
CAS
- circuit
|
| 22. |
1976232C1
|
[1] |
ELECTRICAL WIRE
|
CAS
WIRE - adapter
|
