| 1. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Housing, 74
|
| 2. |
CSE666271
|
[1] |
AUGER
|
DUB
74"
|
| 3. |
CSE666378
|
[1] |
FAN
|
PA
|
| 4. |
BER659509
|
[1] |
PLATE
|
PA
Shear
|
| 5. |
BER654007
|
[1] |
SPROCKET
|
PA
60A38
|
| 6. |
BER4300001
|
[2] |
BEARING
|
PA
w/ locking collar, 1 -1/4"
|
| 7. |
BER659505
|
[2] |
DRIVE BUSHING
|
PA
|
| 8. |
BER654174
|
[1] |
KEY
|
PA
3/8" x 3/8" x 2 -3/4"
|
| 9. |
BER661554
|
[1] |
WASHER
|
PA
|
| 10. |
CSE669724
|
[1] |
GUARD
|
PA
Chain
|
| 11. |
BER669586
|
[2] |
SHOE
|
PA
SKID SHOE
|
| 12. |
BER654009
|
[1] |
CHAIN
|
DUB
60HD x 78 links, Includes: Ref. 58
|
| 12A. |
BER654839
|
[1] |
LINK CHAIN
|
PA
|
| 13. |
BER1000012
|
[6] |
LOCK NUT
|
DUB
Locknut, Nylon Insert, 5/8"
|
| 14. |
BER668093
|
[1] |
IDLER
|
DUB
Idler
|
| 15. |
BER3300022
|
[1] |
SPROCKET
|
DUB
Idler
|
| 16. |
BER667777
|
[1] |
IDLER
|
DUB
Idler
|
| 17. |
CSE669356
|
[1] |
SUPPORT
|
PA
Drive Shaft
|
| 18. |
CSE669722
|
[1] |
PLATE
|
PA
SPACER PLATE
|
| 19. |
BER666583
|
[1] |
HOSE CLAMP
|
PA
|
| 20. |
CSE669597
|
[1] |
PLATE
|
PA
ACCESS PLATE
|
| 21. |
BER669716
|
[1] |
HITCH
|
PA
HITCH, Female
|
| 22. |
BER663485
|
[1] |
GEARBOX
|
PA
|
| 23. |
BER665396
|
[1] |
SUPPORT
|
PA
Reduction Box
|
| 24. |
BER659830
|
[1] |
PTO
|
PA
Half, Female
|
| 25. |
BER669720
|
[1] |
DRIVE SHAFT
|
PA
DRIVE SHAFT
|
| 26. |
BER669595
|
[1] |
PLATE
|
PA
SHEAR PLATE
|
| 27. |
BER4300072
|
[1] |
BUSHING
|
NH
|
| 28. |
BER669136
|
[1] |
CUTTING EDGE
|
PA
CUTTING EDGE
|
| 29. |
BER665406
|
[1] |
GUARD
|
PA
Driveline
|
| 30. |
BER665335
|
[1] |
GEARBOX
|
DUB
Reduction Superseded by part number: BER4500148
|
| 31. |
BER661406
|
[1] |
BRACKET
|
PA
|
| 32. |
BER665446
|
[1] |
SUPPORT
|
PA
Driveline
|
| 33. |
86628576
|
[1] |
KEY
|
NH
1/4" x 1/4" x 1 -1/4"
|
| 34. |
BER0500017
|
[1] |
BOLT
|
DUB
Allen, 3/8" x 3/8"
|
| 35. |
PL
|
[1] |
PROCURE LOCALLY
|
BAS
Bolt, Hex, 3/8" x 2" GR5
|
| 36. |
BER1200004
|
[15] |
LOCK WASHER
|
DUB
3/8"
|
| 37. |
BER665547
|
[2] |
BOLT
|
DUB
Hex, 5/16" x 1 3-4" GR5 & Stover Nut 5/16"
|
| 39. |
BER0100040
|
[4] |
BOLT
|
DUB
Hex, 3/8" x 1 -1/2" GR5
|
| 40. |
BER0900003
|
[14] |
NUT
|
DUB
Hex, 3/8"
|
| 41. |
BER0100070
|
[8] |
BOLT
|
DUB
Hex, 1/2" x 1 -1/2" GR5
|
| 42. |
BER1200006
|
[16] |
WASHER, LOCK
|
DUB
1/2"
|
| 43. |
BER0900006
|
[16] |
NUT
|
DUB
Hex, 1/2"
|
| 44. |
BER0100038
|
[3] |
BOLT
|
DUB
Hex, 3/8" x 1" GR5
|
| 45. |
BER654106
|
[2] |
FITTING
|
PA
Grease
|
| 47. |
BER1400008
|
[4] |
WASHER
|
DUB
Washer, Flat, 11/16"
|
| 48. |
BER1200007
|
[9] |
WASHER
|
DUB
Washer, Lock, 5/8"
|
| 51. |
BER1800004
|
[1] |
COTTER PIN
|
PA
3mm x 65mm
|
| 54. |
BER0200012
|
[3] |
BOLT
|
DUB
M10 x 1.5 x 15mm, GR8
|
| 55. |
BER1200018
|
[5] |
WASHER
|
DUB
Lock, 10mm
|
| 56. |
BER0200084
|
[2] |
BOLT
|
DUB
M12 x 1.75 x 20mm, GR8
|
| 57. |
BER1200019
|
[2] |
WASHER
|
DUB
Lock, 12mm
|
| 58. |
BER0200011
|
[2] |
BOLT
|
DUB
M10 x 1.5 x 15mm, GR8
|
| 61. |
BER1100003
|
[10] |
NUT
|
DUB
Stover, 3/8"
|
| 63. |
BER0100019
|
[1] |
BOLT
|
DUB
Hex, 5/16" x 1" GR5
|
| 64. |
BER658467
|
[2] |
WASHER
|
PA
Nylon 11/32" hole
|
| 65. |
BER1000005
|
[1] |
LOCK NUT
|
DUB
Nylon Insert 5/16"
|
| 66. |
BER1000006
|
[1] |
LOCK NUT
|
DUB
Nylon Insert 3/8"
|
