700108490
|
[1] |
GEARBOX ASSY
|
CAS
GEARBOX COMPLETE
|
| 1. |
7751605
|
[1] |
BREATHER
|
CAS
PLUG - vent Superseded by part number: 219-433
|
| 2. |
803783
|
[1] |
REDUCER
|
CAS
BUSHING - reducer Superseded by part number: 221-93
|
| 3. |
700703798
|
[1] |
BEARING CUP,110 mm OD x 22.5 mm
|
CAS
- left cap
|
| 4. |
700703813
|
[3] |
ADJUSTING PLATE
|
CAS
SHIM - left cap, .010
|
| . . |
700703814
|
[2] |
SHIM
|
CAS
- left cap, .012
|
| . . |
700703815
|
[3] |
SHIM
|
CAS
- left cap, .015
|
| 5. |
700108495
|
[1] |
CAP
|
HFI
- left
|
| 6. |
700108491
|
[1] |
DRIVE
|
HFI
GEARBOX ASSEMBLY (Includes right cover plate)
|
| 7. |
8746638
|
[1] |
PLUG
|
CAS
- drain, magnet
|
| 8. |
700703794
|
[1] |
BEARING CUP,120 mm OD x 23.444 mm
|
CAS
- front Superseded by part number: 510592
|
| 9. |
700703795
|
[1] |
ROLLER BEARING,63.5 mm ID x 30.162 mm
|
CAS
BEARING CONE - front
|
| 10. |
700703803
|
[1] |
WASHER
|
CAS
- stake
|
| 11. |
700703806
|
[1] |
NUT
|
CAS
- stake
|
| 12. |
077016
|
[1] |
ZERK
|
|
| 13. |
700108494
|
[1] |
CAP
|
CAS
- front
|
| 14. |
700703804
|
[1] |
SEAL
|
CAS
ZEAL - front
|
| 15. |
700703810
|
[1] |
SHIM
|
CAS
- front, .010
|
| . . |
700703811
|
[1] |
SHIM
|
CAS
- front, .012
|
| . . |
700703812
|
[1] |
SHIM
|
CAS
- front, .015
|
| 16. |
700703796
|
[1] |
BEARING CUP,152.4 mm OD x 31.75 mm
|
CAS
- front, inner
|
| 17. |
700703797
|
[1] |
ROLLER BEARING,68.26mm ID x 46.04mm W
|
CAS
BEARING CONE - front, inner
|
| 18. |
700703821
|
[1] |
BEVEL GEAR
|
HFI
GEAR AND PINION SET
|
| 19. |
700703822
|
[3] |
SHIM
|
CAS
- right cap, .010
|
| . . |
700703823
|
[2] |
SHIM
|
CAS
- right cap, .012
|
| . . |
700703824
|
[3] |
SHIM
|
CAS
- right cap, .015
|
| 20. |
700108496
|
[1] |
CAP
|
HFI
- right, plate
|
| 21. |
700703805
|
[1] |
SEAL
|
CAS
- right cap
|
| 22. |
762286
|
[4] |
PIN
|
CAS
- dowel Superseded by part number: 81844
|
| 23. |
700703800
|
[1] |
BEARING CUP,155 mm OD x 28 mm
|
HFI
- right
|
| 24. |
700703802
|
[1] |
CONE
|
CAS
BEARING CONE - right
|
| 25. |
7884315
|
[12] |
BOLT,Hex, 1/2" - 13 x 1 1/2", Gr 8
|
CAS
1/2-13 X 1-1/2 C - grade 8 Superseded by part number: 326-824
|
| 26. |
700108497
|
[1] |
RING
|
HFI
HUB - ring gear
|
| 27. |
700703799
|
[1] |
ROLLER BEARING,65 mm ID x 28 mm
|
CAS
BEARING CONE - left cap
|
| . . |
701235
|
[6] |
BOLT,1/2" - 13 x 1 1/2", Gr 5
|
CAS
1/2-13 X 1-1/2 C
|
| . . |
703603
|
[10] |
SCREW
|
CAS
3/8-16 X 1-1/2 C
|
| . . |
702035
|
[4] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5, Full Thd
|
CAS
3/8-16 X 1-1/4 C
|
| . . |
703579
|
[4] |
BOLT,Hex, 5/16" - 18 x 1", Gr 5, Full Thd
|
CAS
5/16-18 X 1 C
|
