| 1. |
700108543
|
[2] |
SUPPORT
|
CAS
HINGE - pivot
|
| 2. |
121-115
|
[12] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 3. |
231-5145
|
[12] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 4. |
700108537
|
[1] |
BOX
|
CAS
- twine Superseded by part number: 700136636
|
| 5. |
413-636
|
[4] |
BOLT,Hex, 3/8" - 16 x 2-1/4", Gr 5
|
CAS
Superseded by part number: 88546, 72187212
|
| 6. |
496-11041
|
[5] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 7. |
231-5146
|
[17] |
FLANGE NUT,3/8"-16
|
CAS
Superseded by part number: 72187068, 247780
|
| 8. |
409-7612
|
[13] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
3/8-16 X 3/4 HWHMS Superseded by part number: 72187187, 255918
|
| 9. |
700707858
|
[2] |
SNAP RING
|
CAS
RING - retainer
|
| 10. |
700108570
|
[1] |
ROD
|
CAS
- hinge
|
| 11. |
700108566
|
[1] |
TOOL BOX
|
CAS
BOX - tool
|
| 12. |
700108569
|
[1] |
LID
|
CAS
- tool box
|
| 13. |
700119381
|
[1] |
PANEL
|
CAS
- center, left
|
| 14. |
700112262
|
[1] |
SUPPORT
|
CAS
- pivot, left
|
| 15. |
700112254
|
[1] |
DOOR
|
CAS
- front, lower
|
| 16. |
7894967
|
[4] |
HANDLE
|
CAS
- latch
|
| 17. |
496-21034
|
[6] |
WASHER,11/32" x 11/16" x 0.89", HDN
|
CAS
Superseded by part number: 86637953
|
| 18. |
7758212
|
[4] |
SPRING
|
CAS
- compression
|
| 19. |
7894975
|
[4] |
CLIP
|
CAS
- latch
|
| 20. |
700112264
|
[1] |
SUPPORT
|
CAS
- pivot, upper
|
| 21. |
700119386
|
[1] |
SHIELD
|
CAS
- front Superseded by part number: 700136642
|
| 22. |
700119398
|
[1] |
ANGLE
|
CAS
- left
|
| 23. |
700119387
|
[1] |
ANGLE
|
CAS
Superseded by part number: 700136643
|
| 24. |
700112272
|
[1] |
ANGLE
|
HFI
|
| 25. |
154273C1
|
[2] |
BOLT,Hex Serr, 3/8" - 16 x 1", Spcl
|
IH
3/8-16 X 1 HFSS Superseded by part number: 9706726
|
| 26. |
492-11031
|
[2] |
LOCK WASHER,5/16"
|
CAS
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 27. |
425-105
|
[2] |
NUT,5/16"-18, G5
|
CAS
Superseded by part number: 9635082, 72187221
|
| 28. |
413-512
|
[1] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
|
CAS
C Hex, 5/16"-18 x 3/4", G5, Full Thd Superseded by part number: 72187196, 87872
|
| 29. |
700112261
|
[2] |
BUSHING
|
CAS
|
| 30. |
700112255
|
[1] |
DOOR
|
CAS
- upper rear, left
|
| 31. |
113-12
|
[2] |
BOLT,Hex, 1/4" - 20 x 2-1/2", Gr 5
|
CAS
1/4-20 X 2-1/2 C Superseded by part number: 87845
|
| 32. |
496-11028
|
[2] |
WASHER,9/32" x 5/8" x .065, HDN
|
CAS
1/4 HARDENED PLAIN WASHER Superseded by part number: 86632587
|
| 33. |
231-1444
|
[2] |
NUT,1/4"-20, GB
|
CAS
NUT, LOCK, 1/4"-20, GB Superseded by part number: 86625061
|
| 34. |
700711131
|
[1] |
GUIDE
|
CAS
- twine Superseded by part number: 84298727
|
| 35. |
51200861
|
[1] |
U-BOLT
|
BRR
5/16-18 U-BOLT
|
| 36. |
6549869
|
[1] |
SUPPORT
|
L
CLAMP - tension
|
| 37. |
700119383
|
[1] |
SUPPORT
|
CAS
- tension, twine
|
| 38. |
58925
|
[2] |
SPRING
|
CAS
- compression
|
| 39. |
700112266
|
[1] |
PANEL
|
HFI
- lower rear, left
|
| 40. |
230-4215
|
[2] |
NUT,5/16"-18, GA
|
CAS
5/16-18 HCLN
|
| 41. |
700108541
|
[1] |
LID
|
CAS
- twine box
|
| 42. |
6605315
|
[4] |
HUB
|
CAS
SPACER
|
