| 1. |
700718182
|
[1] |
CYLINDER
|
CAS
ASSEMBLY - hydraulic
|
| 2. |
413-1252
|
[1] |
BOLT,Hex, 3/4" - 10 x 3-1/4", Gr 5
|
CAS
3/4-10 X 3-1/4 C Superseded by part number: 88747
|
| 3. |
425-1012
|
[2] |
NUT,3/4"-10, G5
|
CAS
3/4-10 H Superseded by part number: 280954
|
| 4. |
738468
|
[1] |
O-RING
|
IH
|
| 5. |
237-6010
|
[1] |
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
|
CAS
10-1, 90 Duro, .755" ID x .097" Thk Superseded by part number: 72186125, 167269
|
| 6. |
237-6008
|
[1] |
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
|
CAS
8-1, 90 Duro, .644" ID x .087" Thk Superseded by part number: 128825
|
| 7. |
700718199
|
[1] |
HYDRAULIC HOSE,0.63" ID x 58.07", SAE 100R2, SAE J517, SAE J343, SAE J516
|
CAS
HOSE - hydraulic
|
| 8. |
7072135
|
[1] |
HYDRAULIC HOSE,0.50" ID x 58.00", SAE 100R2
|
IH
HOSE - hydraulic
|
| 9. |
700129086
|
[2] |
CLAMP
|
HFI
|
| 10. |
700718082
|
[4] |
CAP
|
CAS
- dust
|
| 11. |
1-7141
|
[4] |
FITTING
|
CAS
COUPLER - quick disconnect Superseded by part number: 1272770C2
|
| 12. |
700716257
|
[2] |
HYDRAULIC HOSE,0.38" ID x 129.92", SAE J516, SAE J343
|
CAS
HOSE - hydraulic
|
| 13. |
700129085
|
[2] |
CLAMP
|
CAS
|
| 14. |
433-620
|
[2] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5
|
CAS
BOLT, CARRIAGE, Short NK, 3/8"-16 x 1 1/4", G5 Superseded by part number: 86508773
|
| 15. |
232-5316
|
[6] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 16. |
700135810
|
[1] |
NUT
|
HFI
- cylinder stop Superseded by part number: 700162184
|
| 17. |
700135809
|
[1] |
STOP
|
HFI
- cylinder
|
| 18. |
700716080
|
[1] |
TUBE
|
CAS
LINE - hydraulic, left outer
|
| 19. |
700716079
|
[1] |
TUBE
|
CAS
LINE - hydraulic, left inner
|
| 20. |
700716646
|
[1] |
STOP
|
CAS
|
| 21. |
413-1056
|
[1] |
BOLT,Hex, 5/8" - 11 x 3-1/2", Gr 5
|
CAS
Superseded by part number: 280119
|
| 22. |
425-1010
|
[2] |
NUT,5/8"-11, G5
|
CAS
Superseded by part number: 280374
|
| 23. |
515-23159
|
[2] |
CLAMP,5/8", Insul, 3/8" Bolt
|
CAS
Superseded by part number: 86594406
|
| 24. |
515-25127
|
[2] |
CLAMP,1/2", Insul, 1/2" Bolt
|
CAS
Superseded by part number: 86632595
|
| 25. |
700711134
|
[2] |
SCREW
|
CAS
3/8-16 X 1-3/4 HFS GR8
|
| 26. |
568395R1
|
[2] |
SPACER,5/8" Tube x 5/8"
|
IH
Superseded by part number: 567987R1
|
| 27. |
700126495
|
[2] |
CLAMP
|
HFI
|
| 28. |
413-628
|
[2] |
BOLT,Hex, 3/8" - 16 x 1-3/4", Gr 5
|
CAS
Superseded by part number: 72187210, 9706689
|
| 29. |
S95446
|
[2] |
CLAMP,1 5/16", Insul, 1/2" Bolt
|
CAS
|
| 30. |
218-5351
|
[2] |
HYD CONNECTOR,3/4"-16, 37 Degree x 9/16"-18, O-Ring
|
CAS
CONNECTOR - straight (Includes item 4) Superseded by part number: 86509028
|
| 31. |
700718237
|
[1] |
MANIFOLD
|
CAS
VALVE ASSEMBLY - flow control
|
| 32. |
51200289
|
[1] |
FITTING
|
CAS
CONNECTOR - straight (Includes item 5)
|
| 33. |
413-556
|
[2] |
BOLT,Hex, 5/16" - 18 x 3-1/2", Gr 5
|
CAS
5/16-18 X 3-1/2 C Superseded by part number: 86507008
|
| 34. |
496-21034
|
[1] |
WASHER,11/32" x 11/16" x 0.89", HDN
|
CAS
Superseded by part number: 86637953
|
| 35. |
232-5315
|
[2] |
FLANGE NUT,Flg, 5/16"-18
|
CAS
5/16-18 HFTLN GR/G
|
| 36. |
218-5057
|
[2] |
HYD CONNECTOR,9/16" - 18 JIC x 9/16" - 18 ORB
|
CAS
CONNECTOR - straight (Incl. item 4) Superseded by part number: 76350
|
| 37. |
8027427
|
[1] |
GROMMET
|
CAS
|
| 38. |
218-5059
|
[1] |
HYD CONNECTOR,3/4"-16, 37 Degree x 3/4"-16, O-Ring
|
CAS
CONNECTOR, HYD., , Straight (Incl. item 4) 3/4"-16, 37º x 3/4"-16, O-Ring Superseded by part number: 128818
|
| 39. |
700714813
|
[1] |
HYDRAULIC HOSE,0.25" ID x 52.17", SAE J517, SAE J516, SAE J343
|
CAS
HOSE - hydraulic
|
| 40. |
700714806
|
[1] |
HYDRAULIC HOSE,0.25" ID x 39.37", SAE J517, SAE J516, SAE J343
|
CAS
HOSE - hydraulic
|
| 41. |
218-5105
|
[2] |
ELBOW,90 Degree Elbow, 9/16" - 18 Male JIC x 9/16" - 18 Male ORB
|
CAS
(Includes item 4) 90º, 9/16"-18, 37º x 9/16"-18, O-Ring Superseded by part number: 76344, 72186128
|
