| 1. |
218-5230
|
[2] |
ELBOW,90 Degree, 3/4"-16, 37 Degree x 3/4"-16, 37 Degree Fem Sw
|
CAS
Superseded by part number: 72187024, 248974
|
| 2. |
700716081
|
[1] |
HOSE
|
CAS
- hydraulic
|
| 3. |
51200289
|
[2] |
FITTING
|
CAS
CONNECTOR (Includes item 31)
|
| 4. |
218-5059
|
[2] |
HYD CONNECTOR,3/4"-16, 37 Degree x 3/4"-16, O-Ring
|
CAS
CONNECTOR, HYD., (Incl. item 32) 3/4"-16, 37º x 3/4"-16, O-Ring Superseded by part number: 128818
|
| 5. |
700717995
|
[1] |
VALVE
|
CAS
ASSEMBLY - shutoff
|
| 6. |
700147502
|
[1] |
LINK
|
HFI
STRAP WA
|
| 7. |
413-528
|
[2] |
BOLT,Hex, 5/16" - 18 x 1-3/4", Gr 5
|
CAS
Superseded by part number: 9707515, 72187200
|
| 8. |
232-5315
|
[2] |
FLANGE NUT,Flg, 5/16"-18
|
CAS
5/16-18 HFTLN GR/G
|
| 9. |
700132513
|
[1] |
BUSHING
|
HFI
|
| 10. |
700132512
|
[1] |
BUSHING
|
HFI
|
| 11. |
700132511
|
[1] |
LATCH
|
HFI
|
| 12. |
413-832
|
[1] |
BOLT,Hex, 1/2" - 13 x 2", Gr 5
|
CAS
Superseded by part number: 9706716
|
| 13. |
700711557
|
[3] |
WASHER
|
CAS
1/2 HARDENED WIDE PLAIN WASHER
|
| 14. |
231-5348
|
[2] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
1/2-13 HFTLN GR/G Superseded by part number: 86521610
|
| 15. |
413-836
|
[1] |
BOLT,Hex, 1/2" - 13 x 2-1/4", Gr 5
|
CAS
Superseded by part number: 87975
|
| 16. |
873026
|
[2] |
BOLT
|
CAS
5/16-18 X 4-1/2 C Superseded by part number: 9849585
|
| 17. |
231-5145
|
[2] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 18. |
700716083
|
[1] |
HYDRAULIC HOSE,0.63" ID x 29.53", SAE 100R2 Type AT, SAE J517, SAE J516, SAE J343
|
CAS
HOSE - hydraulic
|
| 19. |
700716073
|
[1] |
HOSE
|
CAS
- hydraulic
|
| 20. |
218-5057
|
[2] |
HYD CONNECTOR,9/16" - 18 JIC x 9/16" - 18 ORB
|
CAS
CONNECTOR (Incl. item 30) Superseded by part number: 76350
|
| 21. |
700718317
|
[1] |
VALVE
|
CAS
ASSEMBLY - bale tension Superseded by part number: 700726843
|
| 22. |
700716491
|
[1] |
HOSE
|
CAS
- hydraulic
|
| 23. |
700716086
|
[1] |
HOSE
|
CAS
- hydraulic
|
| 24. |
218-5243
|
[3] |
TEE,9/16" - 18 Male JIC x 9/16" - 18 Male JIC x 9/16" - 18 Male ORB
|
CAS
Straight run (Includes item 30) 9/16"-18, 37º x 9/16"-18, O-Ring Run Superseded by part number: 86513020
|
| 25. |
700716082
|
[1] |
HYDRAULIC HOSE,0.38" ID x 33.47", SAE 100R17, SAE J517, SAE J516, SAE J343
|
CAS
HOSE - hydraulic
|
| 26. |
700716069
|
[2] |
CYLINDER
|
CAS
ASSEMBLY - hydraulic
|
| 27. |
700714806
|
[1] |
HYDRAULIC HOSE,0.25" ID x 39.37", SAE J517, SAE J516, SAE J343
|
CAS
HOSE - hydraulic
|
| 28. |
700714814
|
[1] |
HYDRAULIC HOSE,0.25" ID x 61.02", SAE J517, SAE J516, SAE J343
|
CAS
HOSE - hydraulic
|
| 29. |
218-5105
|
[2] |
ELBOW,90 Degree Elbow, 9/16" - 18 Male JIC x 9/16" - 18 Male ORB
|
CAS
(Includes item 30) 90º, 9/16"-18, 37º x 9/16"-18, O-Ring Superseded by part number: 76344, 72186128
|
| 30. |
738468
|
[1] |
O-RING
|
IH
(Without mesh wrap)
|
| . . |
237-6008
|
[2] |
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
|
CAS
8-1, 90 Duro, .644" ID x .087" Thk (with mesh wrap) Superseded by part number: 128825
|
| 31. |
237-6010
|
[1] |
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
|
CAS
10-1, 90 Duro, .755" ID x .097" Thk Superseded by part number: 72186125, 167269
|
| 33. |
432-1624
|
[2] |
COTTER PIN,1/4" x 1 1/2"
|
CAS
Pin, Split (Cotter), 1/4" x 1-1/2" Superseded by part number: 80753
|
| 34. |
700715833
|
[1] |
CYLINDER
|
CAS
ASSEMBLY - hydraulic (Without mesh wrap)
|
| . . |
700717928
|
[1] |
CYLINDER
|
CAS
ASSEMBLY - hydraulic (With mesh wrap)
|
| 35. |
700710292
|
[2] |
PIN
|
CAS
- clevis, special
|
| 36. |
700120629
|
[1] |
SPACER
|
HFI
|
| 37. |
700716085
|
[1] |
HOSE
|
CAS
- hydraulic
|
| 38. |
218-5280
|
[2] |
ELBOW,90 Degree, 3/4"-16, 37 Degree x 9/16"-18, O-Ring
|
CAS
90 DEGREE ELBOW (Includes item 30) (Without mesh wrap) Superseded by part number: 86512938
|
| . . |
218-5106
|
[2] |
90 ELBOW,90 Degree Elbow, 3/4" - 16 Male JIC x 3/4" - 16 Male ORB
|
CAS
(Includes item 30) (With mesh wrap) 90º, 3/4"-16, 37º x 3/4"-16, O-Ring Superseded by part number: 72186176, 128830
|
