| 1. |
87016424
|
[1] |
DIA KIT, HARVESTER
|
PA
Crop Saver Wheel, Includes: Installation Instructions
|
| 2. |
86625972
|
[1] |
TUBE
|
NH
|
| 3. |
86625973
|
[1] |
TUBE
|
NH
|
| 4. |
86636578
|
[2] |
SECURING STRAP
|
NH
Clamp
|
| 5. |
86625978
|
[2] |
SUPPORT ASSY.
|
NH
Superseded by part number: 86625970
|
| 6. |
86625979
|
[2] |
CHANNEL
|
NH
|
| 7. |
796772
|
[2] |
MOUNTING PLATE
|
NH
|
| 8. |
850056
|
[4] |
U-BOLT
|
NH
G5, 3/8"-16 x 3-1/2"
|
| 9. |
86636984
|
[2] |
LATCH
|
NH
|
| 10. |
9845426
|
[2] |
WHEEL
|
NH
Wheel
|
| 11. |
86636995
|
[2] |
BAR
|
NH
|
| 12. |
86636747
|
[2] |
DISC
|
NH
Superseded by part number: 47486219
|
| 13. |
86625976
|
[2] |
RING ASSY.
|
NH
|
| 14. |
136376
|
[2] |
SEAL,31.75mm ID x 50.42mm OD x 6.75mm Thk
|
NH
|
| 15. |
D29266
|
[4] |
ROLLER BEARING,1" ID x 0.58"
|
CAS
Superseded by part number: 132710
|
| 16. |
572564R1
|
[4] |
BEARING CUP
|
IH
Superseded by part number: 132709
|
| 17. |
200734
|
[2] |
HUB CAP
|
NH
Plated
|
| 18. |
603373
|
[4] |
JAM NUT,Slotted, 1" - 14, Gr 2
|
NH
Jam, G2, 1"-14 Superseded by part number: 143183
|
| 19. |
26301
|
[2] |
WASHER
|
NH
1-1/2" OD, Special
|
| 20. |
86634544
|
[2] |
SEALING RING COLLAR
|
NH
|
| 21. |
9842022
|
[2] |
BAR
|
NH
|
| 22. |
433-528
|
[12] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 1 3/4", Gr 5
|
CAS
Superseded by part number: 86508771
|
| 23. |
232-4145
|
[12] |
LOCK NUT,5/16"-18, GC
|
FLX
Superseded by part number: 280736
|
| 24. |
26402
|
[6] |
WASHER,25.8mm ID x 38.1mm OD x 1.7mm Thk
|
NH
(.060" Thk, 1-1/2" OD)
|
| 25. |
432-1220
|
[2] |
COTTER PIN,3/16" x 1 1/4"
|
CAS
Superseded by part number: 87398
|
| 26. |
432-1224
|
[2] |
COTTER PIN,3/16" x 1-1/2"
|
CAS
Superseded by part number: 80754
|
| 27. |
413-860
|
[4] |
BOLT,Hex, 1/2" - 13 x 3-3/4", Gr 5
|
CAS
Superseded by part number: 86505992
|
| 28. |
65319
|
[12] |
WASHER,13.1mm ID x 25.4mm OD x 3.68mm Thk
|
NH
|
| 29. |
232-4148
|
[8] |
NUT,1/2"-13, GC
|
CAS
Superseded by part number: 86992215
|
| 30. |
285072
|
[8] |
WASHER,10.3mm ID x 22.2mm OD x 2.7mm Thk
|
NH
(3/8")
|
| 31. |
232-4146
|
[8] |
NUT,3/8"-16, GC
|
CAS
Superseded by part number: 88902
|
| 32. |
413-828
|
[4] |
BOLT,Hex, 1/2" - 13 x 1-3/4", Gr 5
|
CAS
Superseded by part number: 9707516, 72187217
|
| 33. |
122432
|
[4] |
WASHER,17mm ID x 41mm OD x 6mm Thk
|
NH
5/8", Hardened Superseded by part number: 84058945
|
| 34. |
409-7816
|
[4] |
BOLT,Hex Flg, 1/2" - 13 x 1", Spcl
|
CAS
Superseded by part number: 30944
|
| 35. |
231-5148
|
[4] |
FLANGE NUT,Flg, USR, 1/2"-13
|
CAS
Superseded by part number: 72187069, 86512371
|
| 36. |
231-4144
|
[4] |
NUT,1/4"-20, GB
|
CAS
Superseded by part number: 280129
|
| 37. |
413-420
|
[4] |
BOLT,Hex, 1/4" - 20 x 1-1/4", Gr 5
|
CAS
Superseded by part number: 87716, 72187191
|
| 38. |
495-11028
|
[6] |
WASHER,1/4", SAE
|
CAS
Superseded by part number: 87361, 72187256
|
