| 1. |
87692774
|
[1] |
CONVERSION KIT
|
NH
Twine Conversion, Includes: Ref. 22 - 93 & Instructions
|
| 21. |
86618572
|
[6] |
GUIDE
|
NH
Twine, Spring Steel Superseded by part number: 86637283
|
| 21. |
86637283
|
[2] |
GUIDE
|
NH
Twine, Formed Style
|
| 22. |
87025227
|
[1] |
BRACKET
|
PA
RH
|
| 23. |
86629572
|
[1] |
ANGLE
|
NH
Superseded by part number: 87023414
|
| 24. |
86629733
|
[1] |
CABLE
|
NH
|
| 25. |
696365
|
[3] |
SPACER
|
NH
|
| 26. |
689987
|
[3] |
ANGLE
|
NH
|
| 27. |
86632714
|
[1] |
SHIELD
|
NH
|
| 28. |
87015063
|
[1] |
BRACKET
|
PA
|
| 29. |
0C
|
[1] |
ORDER COMPONENTS
|
NH
Spinner Plate, RH
|
| 30. |
86543545
|
[2] |
GUIDE
|
NH
|
| 31. |
28114
|
[2] |
U-BOLT
|
NH
#10-24 x 1-15/16"
|
| 33. |
689986
|
[2] |
ANGLE
|
NH
|
| 34. |
9619090
|
[1] |
CAP COVER
|
NH
|
| 35. |
510932
|
[3] |
PULLEY,50.01mm OD
|
NH
|
| 36. |
9612212
|
[1] |
INDICATOR
|
NH
Pointer
|
| 37. |
217208
|
[1] |
SPRING
|
PA
Extension
|
| 38. |
86629573
|
[1] |
ANGLE
|
NH
|
| 39. |
86705178
|
[1] |
BRACKET
|
NH
Superseded by part number: 87023419
|
| 40. |
86000448
|
[2] |
LATCH
|
NH
Rubber
|
| 41. |
9617869
|
[2] |
BUMPER,28.4mm W x 31.8mm L x 4.8mm Thk
|
NH
|
| 42. |
87036863
|
[1] |
TWINE BOX
|
PA
LH, Red Superseded by part number: 87036864
|
| 42. |
87036864
|
[1] |
TWINE BOX
|
PA
LH, Dk. Gray
|
| 43. |
86551339
|
[4] |
DIVIDER
|
NH
|
| 44. |
87597244
|
[1] |
ANGLE
|
NH
|
| 45. |
9820171
|
[2] |
BRACKET
|
NH
|
| 46. |
29840
|
[4] |
SPRING,Compression, 11.91mm OD x 25.4mm L
|
NH
15/32" OD, 1" Free Length
|
| 47. |
165109
|
[3] |
DECAL
|
NH
Lube Fitting
|
| 48. |
87036861
|
[1] |
TWINE BOX
|
PA
RH, Red Superseded by part number: 87036862
|
| 48. |
87036862
|
[1] |
TWINE BOX
|
PA
RH, Dk. Gray
|
| 49. |
43138
|
[1] |
BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8
|
NH
|
| 50. |
120104
|
[4] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 51. |
43128
|
[3] |
BOLT,M8 x 1.25 x 30mm, Cl 8.8
|
NH
|
| 52. |
300389
|
[4] |
BOLT,M12 x 1.75 x 35mm, Cl 8.8
|
NH
Superseded by part number: 628-12035
|
| 55. |
9804256
|
[4] |
BOLT,Hex, M6 x 1 x 20mm, Full Thd, Cl 8.8
|
NH
|
| 56. |
86511478
|
[6] |
BOLT,Hex Serr, M8 x 1.25 x 16mm
|
ZED
|
| 57. |
86050286
|
[4] |
FLANGE BOLT,M10 x 20mm, Cl 8.8
|
NH
|
| 61. |
9706703
|
[8] |
CARRIAGE BOLT,Sht Sq Nk, M6 x 1 x 20mm, Cl 8.8, Full Thd
|
NH
|
| 62. |
412327
|
[4] |
CARRIAGE BOLT,Short Sq Nk, M6 x 1 x 40mm, Full Thd, Cl 8.8
|
NH
|
| 63. |
86512446
|
[1] |
CARRIAGE BOLT,M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 65. |
281020
|
[1] |
SELF-TAP SCREW,Pan HD, #8 - 18 x 3/4"
|
NH
|
| 70. |
280299
|
[1] |
WASHER,0.19" ID x 0.44" OD x 0.05" Thk
|
NH
|
| 71. |
80701
|
[12] |
WASHER,0.31" ID x 0.73" OD x 0.07" Thk
|
NH
|
| 74. |
80684
|
[6] |
LOCK WASHER,4.9mm ID x 8.48mm OD x 1.19mm Thk
|
NH
|
| 75. |
322357
|
[4] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 76. |
322358
|
[5] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 77. |
140045
|
[11] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 78. |
140046
|
[14] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 80. |
87304
|
[4] |
NUT,#10-24
|
BEL
|
| 84. |
9804276
|
[6] |
FLANGE NUT,Hex, M6 x 1, Cl 8
|
NH
|
| 85. |
9804277
|
[6] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 86. |
86505868
|
[6] |
SERRATED NUT,Hex, M8 x 1.25, Cl 8
|
ZED
|
| 87. |
9804278
|
[3] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 91. |
353308
|
[8] |
NUT,M6 x 1.0, Cl 8
|
NH
|
| 92. |
86629542
|
[1] |
NUT,M8 x 1.25, Cl 8.8
|
ZED
|
| 93. |
100038
|
[6] |
NUT,M12 x 1.75, Cl 8
|
NH
|
