| 1. |
84133376
|
[1] |
SPROCKET
|
NH
22T RC 50 & 28T RC 60
|
| 2. |
84133375
|
[1] |
SPROCKET
|
NH
23T & 34T RC60
|
| 3. |
84133373
|
[1] |
SPROCKET
|
NH
19T & 21T RC60
|
| 4. |
84133374
|
[1] |
SPROCKET
|
NH
24T RC60
|
| 5. |
84275634
|
[1] |
CHAIN
|
NH
101 Pitches, Includes: Ref. 42 & 43
|
| 6. |
84133379
|
[1] |
CHAIN
|
NH
90 Pitches, Includes: Ref. 44
|
| 7. |
84232982
|
[1] |
CHAIN
|
NH
184 Pitches, Includes: Ref. 45
|
| 8. |
86609558
|
[1] |
BEARING ASSY,45mm ID
|
NH
|
| 9. |
86604821
|
[1] |
SHAFT ASSY.
|
NH
|
| 10. |
87030996
|
[2] |
IDLER
|
NH
|
| 11. |
86542824
|
[2] |
SET SCREW,Sq Hd, 3/8" - 16 x 1-1/2"
|
NH
|
| 12. |
338263
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, M12 x 1.75 x 70mm, Cl 8.8
|
ZED
|
| 13. |
86050286
|
[1] |
FLANGE BOLT,M10 x 20mm, Cl 8.8
|
NH
|
| 14. |
9670288
|
[5] |
BOLT,Hex, M12 x 35mm, Cl 8.8
|
PA
|
| 15. |
84266904
|
[1] |
PLATE
|
NH
|
| 16. |
58821
|
[7] |
WASHER,45.24mm ID x 56.36mm OD x 1.65mm Thk
|
NH
|
| 17. |
80700
|
[18] |
WASHER,0.56" ID x 1.38" OD x 0.11" Thk
|
NH
|
| 18. |
28691
|
[3] |
WASHER,39mm ID x 60mm OD x 0.89mm Thk
|
NH
|
| 19. |
136443
|
[2] |
WASHER,10.32mm ID x 57.15mm OD x 4.8mm Thk
|
NH
|
| 20. |
694478
|
[1] |
WASHER,13.5mm ID x 57.15mm OD x 4.8mm Thk
|
NH
|
| 21. |
9628503
|
[2] |
NUT,3/8"-16, G5
|
NH
|
| 22. |
80702
|
[1] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
|
| 23. |
9804279
|
[4] |
FLANGE NUT,Hex, M12, Cl 8
|
NH
Superseded by part number: 86512497
|
| 24. |
86509499
|
[2] |
JAM NUT,3/8"-16, G2
|
ZED
|
| 25. |
9706685
|
[2] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 26. |
80710
|
[1] |
LUBE NIPPLE,1/8” – 27 Dryseal PTF
|
DUB
|
| 27. |
87483
|
[1] |
KEY,0.31" x 1.5" L
|
NH
|
| 28. |
87400
|
[1] |
COTTER PIN,3/16" x 2"
|
WIN
|
| 30. |
9804262
|
[1] |
BOLT,M10 x 39.2mm, Cl 8.8
|
NH
Superseded by part number: 9840672
|
| 31. |
87123
|
[1] |
WOODRUFF KEY,#28, 5/16" x 2 1/8"
|
GI
|
| 32. |
84262617
|
[1] |
ARM
|
NH
Superseded by part number: 47748078
|
| 33. |
80299
|
[4] |
WASHER,0.69" ID x 1.75" OD x 0.13" Thk
|
NH
|
| 34. |
87053428
|
[2] |
SPROCKET
|
NH
15T RC60
|
| 35. |
26402
|
[2] |
WASHER,25.8mm ID x 38.1mm OD x 1.7mm Thk
|
NH
|
| 36. |
86514717
|
[2] |
IDLER WHEEL
|
NH
|
| 37. |
43158
|
[2] |
BOLT,Hex, M12 x 80mm, Cl 8.8
|
NH
|
| 38. |
120092
|
[1] |
BOLT,M16 x 70mm, Cl 8.8
|
NH
|
| 39. |
86000441
|
[2] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 40. |
183356
|
[1] |
EYEBOLT,3/8" - 16 x 10" L
|
NH
|
| 41. |
86572215
|
[1] |
SPRING,Extension, 25.58mm OD x 240.18mm L
|
NH
|
| 42. |
84134452
|
[2] |
CONNECTING LINK,RC60, 3/4" Pitch
|
NH
|
| 43. |
84134453
|
[1] |
OFFSET LINK
|
NH
|
| 44. |
179243
|
[1] |
CONNECTING LINK
|
PA
|
| 45. |
84372501
|
[1] |
CONNECTING LINK
|
NH
|
| 46. |
140046
|
[2] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 47. |
86619803
|
[2] |
FLANGE NUT
|
NH
|
| 48. |
87652388
|
[4/AR] |
WASHER,45.24mm ID x 56.36mm OD x 1.52mm Thk
|
NH
|
