| 1. |
84385997
|
[1] |
DIA KIT, HARVESTER
|
PLO
Hydraulic Rotor Reverser, Incl 2 - 37 plus Figures 88.100.35 02 and 88.100.35 03.
|
| 2. |
47777414
|
[1] |
INSTRUCTION
|
NH
|
| 3. |
87029395
|
[1] |
CYLINDER ASSY.,Double Acting, 19.05mm Rod, 119.89mm Stroke
|
PA
|
| 4. |
87014413
|
[1] |
TUBE,4.80 mm OD x 1850 mm L
|
PA
|
| 5. |
29046
|
[5] |
WASHER,11.1mm ID x 25.4mm OD x 0.457mm Thk
|
NH
|
| 6. |
263117
|
[8] |
CABLE TIE,292.1mm L, Nylon, Black
|
NH
|
| 7. |
87034173
|
[1] |
CABLE TIE,774.7mm L
|
PA
Superseded by part number: 529070
|
| 8. |
9801618
|
[2] |
QUICK MALE COUPLING,1/2" - 14
|
NH
Superseded by part number: 9412
|
| 9. |
333718A1
|
[2] |
CAP
|
CAS
|
| 10. |
330346
|
[1] |
45 ELBOW,45 Degree, 9/16"-18, 37 Degree x 9/16"-18, O-Ring
|
NH
Incl (2) 31
|
| 11. |
48564
|
[1] |
90 ELBOW,90 Degree, 11/16" x 5/8", 1/8" NPT
|
NH
|
| 12. |
47357699
|
[1] |
SHIELD
|
PLO
|
| 13. |
47449876
|
[1] |
SPACER,15.98mm ID x 19.18mm OD x 57mm L
|
PLO
|
| 14. |
320772
|
[4] |
HEX SOC SCREW,CSS, M10 x 30mm, Cl 8.8
|
ZED
|
| 15. |
322441
|
[1] |
CLEVIS PIN,M16 x 65
|
NH
Superseded by part number: 80322441
|
| 16. |
80755
|
[1] |
COTTER PIN,1/8" OD x 1" L
|
NH
|
| 17. |
87663907
|
[1] |
CHANNEL
|
NH
|
| 18. |
86580291
|
[1] |
ADAPTER,1/8" - 27 x 1/4" - 28
|
NH
|
| 19. |
11787
|
[1] |
FITTING,3/8"-24 Fem x 1/8" NPT
|
NH
Superseded by part number: 84341119, 84341119, 87426476
|
| 20. |
84303
|
[1] |
LUBE NIPPLE,1/8"-27 NPT x 1" lg, Fem
|
GI
Superseded by part number: 86050275
|
| 21. |
NH291525
|
[1] |
EDGE
|
NH
Superseded by part number: 86516805
|
| 22. |
9804258
|
[4] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 23. |
86050286
|
[2] |
FLANGE BOLT,M10 x 20mm, Cl 8.8
|
NH
|
| 24. |
86512446
|
[1] |
CARRIAGE BOLT,M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 25. |
87381
|
[2] |
WASHER,0.81" ID x 1.47" OD x 0.13" Thk
|
NH
|
| 26. |
87365
|
[2] |
WASHER,0.66" ID x 1.31" OD x 0.1" Thk
|
NH
|
| 27. |
87016
|
[2] |
WASHER,0.41" ID x 0.81" OD x 0.07" Thk
|
NH
|
| 28. |
322358
|
[2] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 29. |
9804278
|
[1] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 30. |
86513065
|
[1] |
HYD CONNECTOR,9/16"-18, 37 Degree x 9/16"-18, Pipe
|
PA
Incl 31
|
| 31. |
9617873
|
[3] |
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
|
NH
|
| 32. |
86512959
|
[1] |
45 ELBOW,45 Degree, 9/16"-18, 37 Degree x 9/16"-18, 37 Degree Fem Sw
|
GI
|
| 33. |
86000441
|
[1] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 34. |
84602639
|
[2] |
HYDRAULIC HOSE
|
PLO
|
| 35. |
374889
|
[1] |
BOLT,Hex, M16 x 100mm, Cl 8.8
|
NH
|
| 36. |
86977740
|
[1] |
BOLT,Hex, 5/8" - 11 x 4", Gr 5
|
GI
|
| 37. |
47583841
|
[1] |
SUPPORT
|
PLO
|
