| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 47506043 | [1] | SHIELD | NH |
| 2. | 47506044 | [1] | SHIELD | NH |
| 3. | 86624184 | [2] | WASHER,9mm ID x 16mm OD x 1.6mm Thk | FOR |
| 4. | 86511842 | [1] | BOLT,M8 x 1.25 x 48.1mm OAL, Cl 8.8 | NH |
| 5. | 80664 | [2] | WASHER,0.38" ID x 0.88" OD x 0.08" Thk | NH |
| 6. | 9804279 | [2] | FLANGE NUT,Hex, M12, Cl 8 | NH Superseded by part number: 86512497 |
| 7. | 9804277 | [2] | FLANGE NUT,Hex, M8 x 1.25, Cl 8 | NH Superseded by part number: 86505868 |
| 8. | 80577826 | [1] | WASHER,8.7mm ID x 34.93mm OD x 1.94mm Thk | NH |
