| 1. |
87758679
|
[2] |
FLANGED BEARING
|
PA
Superseded by part number: 87758678
|
| 2. |
617668R92
|
[1] |
BEARING ASSY,1.2505" ID x 62 mm OD x 0.9375"
|
IH
Superseded by part number: 84484181
|
| 3. |
214366C91
|
[7] |
BALL BEARING,25.40mm ID x 52mm OD
|
IH
Superseded by part number: 204807C91
|
| 4. |
T39594
|
[2] |
BALL BEARING,0.7505" ID x 1.7805" OD x 0.61"
|
CAS
Superseded by part number: 87029275
|
| 5. |
86635012
|
[2] |
FLANGE
|
NH
|
| 6. |
571588R92
|
[1] |
BALL BEARING,1.3755" ID x 72 mm OD x 1"
|
IH
Superseded by part number: 47066
|
| 7. |
86637255
|
[1] |
SPROCKET ASSY.
|
NH
Includes: Bushing (8) Superseded by part number: 87047934
|
| 7. |
86624640
|
[1] |
HUB
|
NH
Jaw clutch, Includes: 15T sprocket, (8) Superseded by part number: 87047932
|
| 8. |
46962
|
[1] |
BUSHING,2" ID x 2.13" OD x 1.25" L
|
NH
|
| 9. |
714379
|
[2] |
CLUTCH
|
NH
Jaw Superseded by part number: 87639816
|
| 10. |
86603075
|
[10] |
FLANGE,Bearing, 52.01 mm ID x 95.3 mm OD x 8.7 mm
|
NH
Bearing
|
| 12. |
86636650
|
[2] |
DRIVEN SPROCKET
|
NH
17T
|
| 13. |
86514717
|
[2] |
IDLER WHEEL
|
NH
Nylon
|
| 14. |
165271
|
[1] |
DRIVEN SPROCKET
|
NH
Idler, 15T Superseded by part number: 86627870, 80165271
|
| 15. |
164936
|
[1] |
CHAIN
|
NH
Roller, RC 60, 62 pitches Superseded by part number: 611362R91X
|
| 16. |
86602143
|
[2] |
WEAR PLATE
|
NH
|
| 17. |
86626477
|
[1] |
SPROCKET,29T / 39T
|
NH
Double, 29T & 39T Superseded by part number: 87047645
|
| 18. |
86637156
|
[1] |
DRIVEN SPROCKET
|
NH
22T
|
| 19. |
309046
|
[1] |
CHAIN,#50, 96 Links x 15.88mm = 1524mm
|
NH
Roller, RC 50, 96 pitches, (20, 21)
|
| 20. |
25194
|
[1] |
CONNECTING LINK
|
GI
Roller, RC 50, Spring style Superseded by part number: 86537460
|
| 21. |
25816
|
[1] |
OFFSET LINK
|
GI
RC 50 Superseded by part number: 86595276
|
| 23. |
87346700
|
[1] |
ARM
|
PA
Idler, Start Serial: Y8N038894
|
| 24. |
121202
|
[1] |
CHAIN
|
NH
Roller, RC 50, 5/8"-pitch, ASA standard, Riveted type, 79 pitches, (20) Superseded by part number: 1791DX
|
| 25. |
86634554
|
[2] |
SUPPORT
|
NH
End guard
|
| 26. |
86618417
|
[23] |
GUARD
|
NH
Pick-up
|
| 27. |
412093
|
[105] |
SELF-TAP SCREW
|
NH
M6 x 1 x 12
|
| 28. |
578189
|
[4] |
FLANGE
|
NH
Superseded by part number: 86620026
|
| 29. |
121602
|
[2] |
BALL BEARING,28.6mm Hex x 72mm OD x 37.7mm W
|
NH
|
| 30. |
86637251
|
[2] |
DRIVEN SPROCKET
|
NH
44T
|
