| 1. |
480476R1
|
[2] |
PULLEY
|
IH
ASSY, twine arm rope Superseded by part number: 481061R91
|
| 2. |
472695R1
|
[1] |
LINK
|
IH
chain repair
|
| 3. |
13135S
|
[1] |
SPRING
|
IH
|
| 4. |
56456C1
|
[1] |
BRACKET
|
IH
SUPPORT ASSY, bushing
|
| 5. |
55825C1
|
[1] |
BUSHING,8.03mm ID x 12.74mm OD x 9.65mm L
|
IH
motor shaft
|
| 6. |
55826C1
|
[2] |
BUSHING,15.9mm ID x 20.7mm OD x 12.7mm L
|
IH
gear shaft
|
| 7. |
56457C1
|
[1] |
BRACKET
|
IH
ASSY, motor
|
| . . |
180122
|
[2] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
IH
3/8 x 1 type 5 Superseded by part number: 113-207
|
| . . |
482256R1
|
[2] |
BEARING LOCK NUT,Flg, USR, 3/8"-16
|
IH
3/8 flange lock Superseded by part number: 247780
|
| . . |
619856R1
|
[2] |
WASHER
|
IH
.406 x 1.000 x .056 Superseded by part number: 87613182
|
| 8. |
126573C1
|
[1] |
MOTOR, ELECTRIC
|
IH
MOTOR ASSY, electric
|
| . . |
20803R1
|
[3] |
WASHER
|
IH
.406 x 1.000 x .105 Superseded by part number: 87613212
|
| . . |
548645R1
|
[3] |
BOLT,1/4" - 20 x 7/8", Cl 5
|
IH
1/4 x 7/8 pln N/P type 5
|
| 9. |
126569C1
|
[1] |
CABLE
|
IH
motor junction
|
| 10. |
56640C1
|
[1] |
GEAR
|
IH
ASSY, 64 teeth
|
| 11. |
213638C1
|
[1] |
PULLEY
|
IH
pickup motor
|
| . . |
19506R1
|
[1] |
PIN,3/16" x 2", Coiled
|
IH
Superseded by part number: 38-31232
|
| 12. |
204685C1
|
[1] |
CABLE
|
IH
ASSY
|
| 13. |
480473R1
|
[1] |
CUP
|
IH
THIMBLE, 1/8 cable
|
| 14. |
480472R1
|
[1] |
CLIP
|
IH
1/8 cable
|
| . . |
453231R1
|
[1] |
WASHER
|
IH
.406 x 1.750 x .105 pln Superseded by part number: 86637950
|
| 15. |
213637C1
|
[1] |
CHANNEL
|
IH
motor support
|
| . . |
17351R1
|
[2] |
CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1", Gr 2
|
IH
BOLT, 3/8 x 1 crg type 1 Superseded by part number: 88682
|
| 16. |
55854C1
|
[1] |
HARNESS
|
IH
ASSY
|
| 17. |
98959R1
|
[1] |
CLAMP
|
IH
closed Superseded by part number: 86625035
|
| . . |
413-412
|
[1] |
BOLT,Hex, 1/4" - 20 x 3/4", Gr 5
|
CAS
Superseded by part number: 9707580, 72187189
|
| . . |
938016R1
|
[1] |
FLANGE NUT,Flg, USR, 1/4"-20
|
IH
1/4 flange lock Superseded by part number: 523282
|
| . . |
23505R1
|
[1] |
WASHER
|
IH
9/32 x 5/8 x 16 ga C-Z Superseded by part number: 87361
|
| 18. |
299407C1
|
[1] |
CLAMP
|
IH
closed Superseded by part number: 86010402
|
| . . |
113-206
|
[1] |
BOLT,Hex, 3/8" - 16 x 3/4", Gr 5, Full Thd
|
CAS
3/8 x 3/4 type 5 Superseded by part number: 86500692
|
| 19. |
702093C1
|
[2] |
CABLE TIE
|
IH
STRAP, harness
|
| 20. |
55861C1
|
[1] |
HARNESS
|
IH
wiring
|
| 21. |
55863C1
|
[4] |
CLAMP
|
IH
plastic
|
| 22. |
55862C1
|
[1] |
ELECTRICAL WIRE
|
IH
WIRE ASSY
|
| 23. |
529933R91
|
[1] |
SWITCH
|
IH
ASSY
|
| 24. |
55857C1
|
[1] |
BOX
|
IH
switch
|
| 25. |
55858C1
|
[1] |
COVER
|
IH
switch box
|
| . . |
21531R1
|
[4] |
SCREW
|
CAS
1/4 x 1-3/4 znp p/hds mach Superseded by part number: 470-12528
|
| . . |
120375
|
[4] |
NUT,Hex, 1/4" - 20, Gr 5
|
IH
Superseded by part number: 7770
|
| . . |
492-11025
|
[4] |
LOCK WASHER,1/4"
|
CAS
WASHER, LOCK, 1/4" Superseded by part number: 72187247, 80682
|
| 26. |
403069R1
|
[1] |
CIRCUIT-BREAKER,30A
|
IH
BREAKER, 30 AMP circuit
|
| . . |
120614
|
[2] |
NUT,Hex, #10 - 32
|
IH
NUT, #10-32 Superseded by part number: 87825
|
| . . |
120217
|
[2] |
LOCK WASHER,#10
|
IH
WASHER, LOCK, #10 Superseded by part number: 80684
|
| 27. |
55855C1
|
[1] |
ELECTRICAL WIRE
|
IH
WIRE ASSY, battery breaker
|
| 28. |
55856C1
|
[1] |
ELECTRICAL WIRE
|
IH
WIRE ASSY, breaker switch
|
| 29. |
251553R1
|
[1] |
BOOT
|
IH
NIPPLE, circuit breaker
|
| 30. |
55852C1
|
[1] |
SHIELD
|
IH
motor
|
| . . |
12653R1
|
[3] |
BOLT (SPREADER),Short NK, 1/4"-20 x 3/4", G2
|
IH
BOLT, CARRIAGE, Short NK, 1/4"-20 x 3/4", G2 Superseded by part number: 598795R1
|
| 31. |
214492C91
|
[1] |
KNIFE
|
IH
PACKAGE, knife Superseded by part number: 619078R1
|
