| 1. |
218382C1
|
[1] |
KNIFE SECTION
|
IH
BLADE, twine cutting
|
| . . |
18626R1
|
[2] |
CARRIAGE BOLT,Short Sq Nk, 1/4" - 20 x 1/2", Gr 2
|
IH
BOLT, 1/4 x 1/2 crg type 1 Superseded by part number: 598794R1
|
| . . |
938016R1
|
[2] |
FLANGE NUT,Flg, USR, 1/4"-20
|
IH
1/4 flange lock Superseded by part number: 523282
|
| 2. |
214493C1
|
[1] |
SUPPORT
|
IH
twine knife
|
| . . |
16897R1
|
[2] |
CARRIAGE BOLT,Short Nk, 5/16" - 18 x 3/4", Gr 2, Full Thd
|
IH
BOLT, 5/16 x 3/4 crg type 1 Superseded by part number: 412-512
|
| . . |
938017R1
|
[2] |
FLANGE NUT,Flg, USR, 5/16"-18
|
IH
5/16-18 znd hex. lock Superseded by part number: 145458
|
| 3. |
210318C1
|
[1] |
SPRING
|
IH
twine hook return
|
| 4. |
214432C1
|
[1] |
SUPPORT ASSY.
|
IH
SUPPORT, twine tension
|
| 5. |
208688C1
|
[1] |
SUPPORT
|
IH
ASSY, twine hook
|
| . . |
18494R1
|
[2] |
BOLT,Hex, 3/8" - 16 x 1", Gr 2
|
IH
3/8 x 1 znd hex-hd mach Superseded by part number: 424-616
|
| . . |
482256R1
|
[2] |
BEARING LOCK NUT,Flg, USR, 3/8"-16
|
IH
3/8-16 znd hex. lock Superseded by part number: 247780
|
| 6. |
208692C2
|
[1] |
HOOK
|
IH
ASSY, twine
|
| . . |
603632R1
|
[1] |
HEADED PIN,9.53mm OD x 76.2mm L
|
IH
PIN, 3/8 x 3. pln hd type 5
|
| . . |
103384
|
[1] |
COTTER PIN,1/8" x 3/4"
|
IH
Pin, Split (Cotter), 1/8" x 3/4" Superseded by part number: 80755
|
| 7. |
208698C1
|
[1] |
ROD
|
IH
twine hook control
|
| 8. |
210327C1
|
[1] |
DEFLECTOR
|
IH
hay twine hook
|
| 9. |
87414
|
[1] |
LUBE NIPPLE,1/4" - 28
|
NH
FITTING, 1/4-28 self-tap lub
|
| 10. |
208669C1
|
[3] |
PULLEY
|
IH
twine arm rope
|
| 11. |
512749R1
|
[4] |
HOOK
|
IH
S-HOOK
|
| 12. |
668048R1
|
[2] |
CLIP
|
IH
s-hook spring
|
| . . |
NLS
|
[1] |
NO LONGER SERVICED
|
BAS
.469 x .922 x .051 znd
|
| 13. |
208587C1
|
[1] |
ROPE
|
IH
twine feed arm
|
| . . |
22264R1
|
[1] |
WASHER
|
IH
.406 x 1.000 x .164 znd Superseded by part number: 495-81138
|
| 14. |
208583C2
|
[1] |
ARM
|
IH
ASSY, twine feed
|
| . . |
120376
|
[2] |
NUT,5/16"-18, G5
|
IH
Superseded by part number: 9635082
|
| . . |
103397
|
[1] |
COTTER PIN,5/32" x 1 1/4"
|
IH
Pin, Split (Cotter), 5/32" x 1 1/4" Superseded by part number: 132-341
|
| 15. |
213506C1
|
[1] |
SPRING
|
IH
twine arm return
|
| . . |
1310D
|
[1] |
LINK
|
IH
#50 singe pitch connecting Superseded by part number: 87034815
|
| 17. |
210326C1
|
[1] |
HANDLE
|
IH
twine tube control rope
|
| 18. |
208645C1
|
[1] |
|
P
BRACKET, twine guide mounting
|
| 19. |
208742C1
|
[1] |
PLATE
|
IH
twine arm indicator
|
| . . |
436732
|
[2] |
SCREW,Slotted Pan Hd, #10-24 x 1/2"
|
IH
10-24 x 1/2 znd pan-hd-clt & cross recess mach Superseded by part number: 70-1108
|
| . . |
174097C1
|
[2] |
FLANGE NUT,Flg, USR, #10-24
|
IH
10-24 znd hex. lock Superseded by part number: 523310
|
| 20. |
208330C1
|
[1] |
BRACE
|
IH
twine arm support
|
| . . |
18495R1
|
[1] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 2
|
IH
3/8 x 1-1/4 znd hex-hd. mach Superseded by part number: 180124
|
| 21. |
208580C1
|
[1] |
SUPPORT
|
IH
ASSY, twine feed arm
|
| . . |
18778R1
|
[2] |
SCREW,Hex, 3/8"-16 x 3/4", G2
|
IH
BOLT, 3/8 x 3/4 znd hex-hd mach Superseded by part number: 180120
|
| 22. |
670617R2
|
[2] |
GUIDE
|
IH
twine Superseded by part number: 3102165R2
|
| 23. |
352133R1
|
[2] |
PLATE
|
IH
twine guide mounting
|
| 24. |
208643C1
|
[1] |
STOP
|
IH
twine tube limit
|
| 25. |
208746C1
|
[1] |
ARM
|
IH
ASSY, twine hook actuator
|
| 26. |
208575C2
|
[1] |
HOUSING
|
IH
BOX ASSY, twine
|
| . . |
18764R1
|
[7] |
HARDWARE,Hex, 5/16"-18 x 3/4", G2
|
IH
BOLT, 5/16 x 3/4 type 1 Superseded by part number: 424-512
|
| 27. |
208646C1
|
[1] |
BRACKET
|
IH
twine can twine guide, serial No. 7810 and below
|
| 28. |
669184R1
|
[1] |
CLAMP
|
IH
CLIP, spring Superseded by part number: 1333780C1
|
| 29. |
210452C1
|
[1] |
ELBOW
|
IH
ASSY, twine guide
|
| 30. |
670628R1
|
[2] |
HINGE
|
IH
twine box top
|
| 31. |
208579C1
|
[1] |
COVER ASSY
|
IH
TOP, twine box
|
| 32. |
662380R1
|
[2] |
GUIDE
|
IH
PLATE, twine tension
|
| 33. |
2064A
|
[2] |
SPRING
|
IH
twine tension
|
| . . |
18634R1
|
[2] |
BOLT
|
IH
1/4 x 2-3/4 crg type 1
|
| . . |
86627130
|
[2] |
WING NUT,1/4"-20
|
NH
NUT, 1/4 wing
|
| . . |
120392
|
[2] |
WASHER,1/4", SAE
|
IH
.281 x .625 x .051 Superseded by part number: 87361
|
| . . |
12653R1
|
[2] |
BOLT (SPREADER),Short NK, 1/4"-20 x 3/4", G2
|
IH
BOLT, CARRIAGE, Short NK, 1/4"-20 x 3/4", G2 Superseded by part number: 598795R1
|
