| 1. |
208611C1
|
[1] |
SHIELD
|
IH
cylinder RH
|
| . . |
16897R1
|
[3] |
CARRIAGE BOLT,Short Nk, 5/16" - 18 x 3/4", Gr 2, Full Thd
|
IH
BOLT, 5/16 x 3/4 crg type 1 Superseded by part number: 412-512
|
| . . |
938017R1
|
[3] |
FLANGE NUT,Flg, USR, 5/16"-18
|
IH
5/16 flange lock Superseded by part number: 145458
|
| 2. |
208609C4
|
[1] |
SHIELD
|
IH
inner RH
|
| . . |
18673R1
|
[7] |
CARRIAGE BOLT,Short Sq Nk, 5/16" - 18 x 1/2", Gr 2
|
IH
BOLT, 5/16 x 1/2 crg type 1 Superseded by part number: 411-58
|
| . . |
12872R1
|
[1] |
BOLT,Short NK, 5/16"-18 x 1", G2, Full Thd
|
IH
CARRIAGE, Short NK, 5/16"-18 x 1", G2, Full Thd Superseded by part number: 598803R1
|
| . . |
22859R1
|
[1] |
WASHER
|
IH
11/32 x 3/4 x 7 ga znd Superseded by part number: 495-81113
|
| 3. |
208610C1
|
[1] |
SHIELD
|
IH
cylinder LH
|
| 4. |
208608C4
|
[1] |
SHIELD
|
IH
inner LH
|
| 5. |
549152R1
|
[2] |
COVER
|
IH
reel shaft
|
| . . |
200084C1
|
[8] |
RIVET
|
IH
3/16 x .402 pop type Superseded by part number: 151-558
|
| 6. |
219095C92
|
[1] |
SHIELD
|
IH
ASSY W/PRODUCT GRAPHIC MAIN DRIVE
|
| . . |
164603C1
|
[1] |
THUMB SCREW,3/8" - 16 x 5/8"
|
IH
BOLT, 3/8-16 x 5/8 wing tap.
|
| 7. |
210304C1
|
[1] |
SHIELD
|
IH
stripper end upper
|
| 8. |
219047C91
|
[1] |
TUBE
|
IH
ASSY W/PRODUCT GRAPHIC, PTO shaft safety
|
| . . |
25178R1
|
[1] |
BOLT, 3/8 x 3/4 dld type 1
|
|
| . . |
18778R1
|
[1] |
SCREW,Hex, 3/8"-16 x 3/4", G2
|
IH
BOLT, 3/8 x 3/4 type 1 Superseded by part number: 180120
|
| . . |
120377
|
[2] |
NUT,3/8" - 16, Gr 5
|
IH
Superseded by part number: 280136
|
| . . |
473443R1
|
[1] |
COTTER PIN
|
IH
quick attachable cot.
|
| 9. |
219007C91
|
[1] |
COVER ASSY
|
IH
W/PRODUCT GRAPHIC, clutch
|
| . . |
669637R1
|
[4] |
SELF-TAP SCREW
|
IH
5/16-18 x 1/2 znd self-tap washer type
|
| 10. |
219299C1
|
[1] |
PLATE ASSY.
|
IH
PLATE, LH shield front
|
| . . |
18404R1
|
[6] |
CARRIAGE BOLT,Short Sq Nk, 1/4" - 20 x 5/8", Gr 2
|
IH
BOLT, 1/4-20 x 5/8 znd sq-nk crg Superseded by part number: 412-410
|
| . . |
938016R1
|
[6] |
FLANGE NUT,Flg, USR, 1/4"-20
|
IH
1/4 flange lock Superseded by part number: 523282
|
| 11. |
219006C91
|
[1] |
SHIELD
|
IH
W/PRODUCT GRAPHIC, RH tapered roll
|
| 12. |
218147C1
|
[1] |
SUPPORT ASSY.
|
IH
SUPPORT, mounting
|
| . . |
19570R1
|
[1] |
BOLT,Hex, 1/4" - 20 x 5/8", Gr 2
|
IH
1/4 x 5/8 type 1 Superseded by part number: 280641
|
| 13. |
219298C1
|
[1] |
SUPPORT ASSY.
|
IH
SUPPORT, side shield center RH
|
| . . |
27950R1
|
[2] |
SELF-TAP SCREW,Hex Hd, 5/16" x 3/4"
|
CAS
SCREW, 5/16-18 x 3/4 h/whd tap. type "T" Superseded by part number: 281-34812
|
| 14. |
219294C1
|
[1] |
SHIELD
|
IH
RH side
|
| 15. |
219297C1
|
[1] |
SUPPORT ASSY.
|
IH
SUPPORT, side shield center LH
|
| 16. |
219307C1
|
[1] |
SHIELD
|
IH
ASSY, LH side
|
