| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| . . | 313849A1 | [1] | KIT | CAS consists of: 1 - 9, 21 and 22 Superseded by part number: 313104A1, 313115A1, 277171A1, 277035A1, 313116A1, 313118A1, 313107A1, 313112A1, 313117A1, 832-10406, 313114A1, 313109A1, 313113A1, 313087A1, 313086A1, 313085A1, 277179A1, 314616A1, 15212821, 313111A1 |
| 1. | 313085A1 | [1] | FRAME | CAS ASSY. |
| 2. | 313086A1 | [1] | PIN | CAS 255 mm |
| 3. | 614-6045 | [3] | BOLT,Hex, M6 x 1 x 45mm, Cl 8.8, Full Thd | CAS BOLT, M6 x 45; 8.8 Superseded by part number: 15212821 |
| 4. | 832-10406 | [3] | NUT,M6 x 1, Cl 8 | CAS |
| 5. | 314616A1 | [1] | PIN | CAS pivot 770 mm |
| 6. | 313087A1 | [1] | BAR | CAS 630 mm |
| 8. | 313107A1 | [1] | CYLINDER | CAS |
| 8A. | 313108A1 | [1] | KIT | CAS repair Not Illustrated |
| 9. | 313118A1 | [3] | TEE | CAS |
| 10. | 313109A1 | [1] | RUBBER PAD | CAS HOSE ASSY.,168 mm |
| 11. | 313111A1 | [1] | HOSE | CAS ASSY., 2600 mm |
| 12. | 277179A1 | [2] | SEAL | CAS |
| 13. | 313112A1 | [1] | ADAPTER | CAS |
| 14. | 313113A1 | [1] | VALVE | CAS balance |
| 15. | 277171A1 | [2] | ADAPTER | CAS |
| 16. | 313114A1 | [1] | TEE | CAS |
| 17. | 313115A1 | [1] | VALVE | CAS relief |
| 18. | 277035A1 | [4] | SEAL | IH |
| 19. | 313116A1 | [1] | HOSE | CAS ASSY., 525 mm |
| 20. | 313100A1 | [1] | TEE | CAS |
| 21. | 313117A1 | [1] | HOSE | CAS ASSY., 480 mm |
| 22. | 313104A1 | [1] | VALVE | CAS check |
| 23. | 277624A1 | [1] | HOSE | CAS ASSY., 750 mm |
| 24. | 277034A1 | [1] | ADAPTER | CAS |
| 25. | 277893A1 | [1] | HOSE | CAS ASSY., 350 mm |
| 26. | REF | [1] | INSTRUCTION | NH VALVE control, See Figure: 2-?? |
| 27. | 277620A1 | [1] | MANIFOLD | CAS ASSY., See Figure: 2-?? |
| 28. | 276888A1 | [1] | CYLINDER | CAS tilt, See Figure: 2-?? |
