| 1. |
276377A1
|
[1] |
FRAME
|
CAS
order: 313084A1 order also: 2-5 and 25A Superseded by part number: 412123, 313084A1, 86629541, 311389A1, 311391A1
|
| 1. |
313084A1
|
[1] |
FRAME
|
CAS
ASSY., replaces: 276377A1
|
| 2. |
311391A1
|
[1] |
ARM
|
CAS
extension
|
| 3. |
311389A1
|
[2] |
RING
|
CAS
|
| 4. |
614-12040
|
[12] |
BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 86629541
|
| 5. |
892-11012
|
[8] |
LOCK WASHER,M12
|
CAS
Superseded by part number: 412123
|
| 6. |
276928A1
|
[1] |
ARM
|
CAS
plate
|
| 7. |
814-16060
|
[1] |
BOLT,Hex, M16 x 2 x 60mm, Cl 8.8
|
CAS
Superseded by part number: 323866
|
| 8. |
832-10416
|
[5] |
NUT,M16 x 2, Cl 8
|
CAS
Superseded by part number: 412066
|
| 9. |
895-11016
|
[1] |
WASHER,17.5mm ID x 30mm OD x 3mm Thk
|
CAS
Superseded by part number: 80299
|
| 10. |
877-10816
|
[2] |
SET SCREW,Hex Skt, M8 x 16mm, Cup Pt
|
CAS
M8 x 16 Superseded by part number: 300477
|
| 11. |
829-1408
|
[2] |
NUT,Hex, M8 x 1.25, Cl 10.9
|
CAS
Superseded by part number: 87778059, 43362
|
| 12. |
276380A1
|
[1] |
WEAR PAD
|
CAS
|
| 13. |
840-1620
|
[4] |
SCREW,Pan, M6 x 20mm, Cl 4.8
|
CAS
Superseded by part number: 86511830
|
| 14. |
276553A1
|
[2] |
PLUG
|
CAS
1-3/4 in
|
| 15. |
276386A1
|
[1] |
HEADED PIN
|
CAS
|
| 16. |
A30338
|
[1] |
PIN
|
CAS
linch, 1/4 in Superseded by part number: 270184
|
| 17. |
284844A1
|
[2] |
WHEEL
|
CAS
rim
|
| 18. |
297528A1
|
[2] |
TYRE/TIRE
|
CAS
|
| 19. |
284843A1
|
[10] |
WHEEL NUT
|
CAS
|
| 20. |
313130A1
|
[4] |
POST
|
CAS
TUBE ASSY., Replaces: 276388A1
|
| 21. |
282133A1
|
[4] |
SPECIAL WASHER
|
CAS
|
| 22. |
892-11016
|
[4] |
LOCK WASHER,16.4mm ID x 27.4mm OD x 5mm Thk
|
CAS
Superseded by part number: 87016618
|
| 23. |
276554A1
|
[3] |
PLUG
|
CAS
60 mm If Used
|
| 24. |
614-6016
|
[2] |
BOLT,Hex, M6 x 1 x 16mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 86508568
|
| 25. |
276383A1
|
[1] |
PLATE
|
CAS
Used With : 276377A1
|
| 25A. |
313131A1
|
[1] |
PLATE
|
CAS
|
| 26. |
276387A1
|
[3] |
PIN
|
CAS
pivot
|
| 27. |
614-6045
|
[1] |
BOLT,Hex, M6 x 1 x 45mm, Cl 8.8, Full Thd
|
CAS
BOLT, M6 x 45; 8.8 Superseded by part number: 15212821
|
| 28. |
832-10406
|
[9] |
NUT,M6 x 1, Cl 8
|
CAS
|
| 29. |
219-14
|
[1] |
LUBE NIPPLE,1/4" NPTF
|
CAS
|
| 30. |
313092A1
|
[1] |
CLAMP
|
CAS
|
| 31. |
313119A1
|
[1] |
CLAMP
|
CAS
|
| 32. |
614-6030
|
[1] |
BOLT,Hex, M6 x 1 x 30mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 87317695
|
| 33. |
REF
|
[1] |
INSTRUCTION
|
NH
SENSOR, See Figure: 2-52
|
| 35. |
NSS
|
[7] |
NOT SOLD SEPARAT
|
CON
WEIGHT
|
| 36. |
220321A1
|
[1] |
WARNING DECAL
|
CAS
warning, See Figure: 2-90
|
