| 1. |
276860A1
|
[1] |
ARM
|
CAS
|
| 2. |
276859A1
|
[2] |
BOLT
|
CAS
special
|
| 3. |
895-11016
|
[4] |
WASHER,17.5mm ID x 30mm OD x 3mm Thk
|
CAS
Superseded by part number: 80299
|
| 4. |
832-10416
|
[2] |
NUT,M16 x 2, Cl 8
|
CAS
Superseded by part number: 412066
|
| 5. |
219-14
|
[3] |
LUBE NIPPLE,1/4" NPTF
|
CAS
|
| 6. |
276627A1
|
[2] |
COIL SPRING
|
IH
|
| 7. |
814-12050
|
[1] |
BOLT,Hex, M12 x 1.75 x 50mm, Cl 8.8
|
CAS
Superseded by part number: 9706702
|
| 8. |
282135A1
|
[2] |
SPECIAL WASHER
|
CAS
|
| 9. |
832-10412
|
[1] |
NUT,M12 x 1.75, Cl 8
|
CAS
Superseded by part number: 412126, 87780366
|
| 10. |
277007A1
|
[1] |
BUSHING
|
CAS
SPACER
|
| 11. |
276858A1
|
[1] |
ARM
|
CAS
|
| 12. |
276851A1
|
[2] |
ROLLER
|
CAS
|
| 13. |
277061A1
|
[2] |
SPECIAL BOLT
|
CAS
|
| 14. |
276880A1
|
[1] |
HANDLE
|
CAS
|
| 15. |
276856A1
|
[1] |
PLATE
|
CAS
ASSY.
|
| 16. |
276855A1
|
[1] |
SPRING
|
CAS
|
| 17. |
276853A1
|
[1] |
CYLINDER ASSY.
|
CAS
|
| 17A. |
276854A1
|
[1] |
SEAL PACKAGE
|
CAS
KIT repair, Not Illustrated
|
| 18. |
277070A1
|
[4] |
BUSHING
|
CAS
SPACER
|
| 19. |
814-10060
|
[4] |
BOLT,Hex, M10 x 1.5 x 60mm, Cl 8.8
|
CAS
Superseded by part number: 120070
|
| 20. |
282131A1
|
[4] |
SPECIAL WASHER
|
CAS
|
| 21. |
276849A1
|
[1] |
CYLINDER
|
CAS
|
| 21A. |
276850A1
|
[1] |
SEAL PACKAGE
|
CAS
KIT repair, Not Illustrated
|
| 22. |
277071A1
|
[1] |
HOSE
|
CAS
ASSY.
|
| 23. |
277035A1
|
[1] |
SEAL
|
IH
|
| 24. |
814-16090
|
[6] |
BOLT,Hex, M16 x 2 x 90mm, Cl 8.8
|
CAS
Superseded by part number: 350616
|
| 25. |
892-11016
|
[6] |
LOCK WASHER,16.4mm ID x 27.4mm OD x 5mm Thk
|
CAS
Superseded by part number: 87016618
|
| 26. |
276852A1
|
[1] |
PLATE
|
CAS
HOUSING
|
| 27. |
895-11012
|
[2] |
WASHER,13.5mm ID x 24mm OD x 2.5mm Thk
|
CAS
|
| 28. |
814-12090
|
[2] |
BOLT,Hex, M12 x 1.75 x 90mm, Cl 8.8
|
CAS
Superseded by part number: 86508581
|
