| 1. |
276593A1
|
[1] |
GEARBOX ASSY
|
CAS
|
| 2. |
276644A1
|
[1] |
KEY
|
IH
7 x 8 x 30 mm
|
| 3. |
276591A1
|
[1] |
TOOL
|
L
COUPLING, order: 1 x 311385A1, 1 x 311384A1, 2 x 838-5850 round bale #8630, 8640 order: 1 x 319084A1, 1 x 319083A1 round/rectangular bale #8630, 8650 Superseded by part number: 311385A1, 311384A1, 838-5850
|
| 3. |
311385A1
|
[1] |
COUPLING
|
CAS
replaces: 276591A1 round bale #8630, 8640
|
| 4. |
838-3650
|
[2] |
PIN,M6 x 50, Coiled
|
CAS
roll, 6 x 50 mm If Used
|
| 4. |
838-5850
|
[2] |
LOCK PIN,M8 x 50, Slotted
|
CAS
Superseded by part number: 412689
|
| 5. |
276592A1
|
[1] |
SHAFT
|
CAS
drive order: 1 x 311384A1, 1 x 311385A1, 2 x 838-5850 round bale #8630, 8640 Superseded by part number: 311384A1, 311385A1, 838-5850
|
| 5. |
311384A1
|
[1] |
SHAFT
|
CAS
drive, replaces: 276592A1 round bale #8630, 8640
|
| . . |
276684A1
|
[1] |
SHAFT
|
CAS
drive, Not Illustrated order: 1 x 319083A1, 1 x 319084A1 round/rectangular bale #8630, 8650 Superseded by part number: 319084A1, 319083A1
|
| 6. |
319084A1
|
[1] |
COUPLING
|
CAS
replaces: 276591A1, 276684A1 round/rectangular bale #8630, 8650
|
| 7. |
319083A1
|
[1] |
SHAFT
|
CAS
drive replaces: 276684A1 round/rectangular bale #8630, 8650
|
| 8. |
284296A1
|
[1] |
CLUTCH
|
CAS
round/rectangular bale #8630, 8650
|
| 9. |
614-12030
|
[1] |
BOLT,Hex, M12 x 1.75 x 30mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 9706687
|
| 10. |
282132A1
|
[1] |
SPECIAL WASHER
|
CAS
|
| 11. |
814-10120
|
[4] |
BOLT,Hex, M10 x 1.5 x 120mm, Cl 8.8
|
CAS
Superseded by part number: 86508574
|
| 12. |
832-10410
|
[4] |
NUT,M10 x 1.5, Cl 8
|
CAS
Superseded by part number: 190003888452
|
| 14. |
276582A1
|
[1] |
SPROCKET ASSY.
|
CAS
57T
|
| 15. |
614-12040
|
[4] |
BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 86629541
|
| 16. |
832-10412
|
[4] |
NUT,M12 x 1.75, Cl 8
|
CAS
Superseded by part number: 412126, 87780366
|
| 17. |
895-11012
|
[4] |
WASHER,13.5mm ID x 24mm OD x 2.5mm Thk
|
CAS
|
| 18. |
554553R91
|
[1] |
BALL BEARING,45mm ID x 75mm OD x 16mm W
|
IH
ball Superseded by part number: 84356152
|
| 19. |
276581A2
|
[1] |
FRAME
|
CAS
ASSY.
|
| 20. |
877-10816
|
[4] |
SET SCREW,Hex Skt, M8 x 16mm, Cup Pt
|
CAS
M8 x 16 Superseded by part number: 300477
|
| 13. |
895-11010
|
[4] |
WASHER,11mm ID x 20mm OD x 2mm Thk
|
CAS
11 x 21 x 2 mm Superseded by part number: 14496621
|
