HK50596
|
[1] |
MESH WRAP ADAPTER KIT COMPLETE
|
|
| 1. |
700710997
|
[1] |
VALVE
|
CAS
- control Superseded by part number: 700124625
|
| . . |
700124625
|
[1] |
KIT
|
HFI
CONTROL VALVE KIT, service
|
| 2. |
7792500
|
[7] |
ELBOW
|
CAS
90 DEGREE ELBOW (Includes item 5) Superseded by part number: 165202, 216773
|
| 3. |
413-428
|
[2] |
BOLT,Hex, 1/4" - 20 x 1-3/4", Gr 5
|
CAS
.25 X 1.75 UNC GR5 YZD Superseded by part number: 280164
|
| 4. |
231-5144
|
[2] |
SERRATED NUT,Flg, USR, 1/4"-20
|
CAS
Superseded by part number: 523282, 72187066
|
| 5. |
237-6004
|
[12] |
O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro
|
CAS
4-1, 90 Duro, .351" ID x .072" Thk Superseded by part number: 165202, 72186131
|
| 6. |
7046576
|
[1] |
ADAPTER
|
CAS
- straight, male
|
| 7. |
700711345
|
[1] |
VALVE
|
CAS
- needle
|
| 8. |
218-491
|
[1] |
ELBOW,90 Degree Elbow, 7/16" - 20 Male JIC x 1/4" - 18 Male NPTF
|
CAS
90 DEGREE ELBOW Superseded by part number: 259918
|
| 9. |
700711008
|
[1] |
HYDRAULIC HOSE,6.35 mm ID x 6600.00 mm, SAE 100R1
|
CAS
6.35 mm ID x 6600.00 mm, SAE 100R1
|
| 10. |
700711007
|
[1] |
HYDRAULIC HOSE,6.35 mm ID x 5400.00 mm, SAE 100R1
|
CAS
6.35 mm ID x 5400.00 mm, SAE 100R1
|
| 11. |
700128332
|
[1] |
SUPPORT
|
HFI
- switch
|
| 12. |
L18337
|
[5] |
CABLE TIE,9.95"-12.1" lg
|
CAS
STRAP - tie, 15 inch, nylon Superseded by part number: 529070
|
| 13. |
218-5053
|
[4] |
HYD CONNECTOR,7/16" - 20 JIC x 7/16" - 20 ORB
|
CAS
CONNECTOR, HYD, (Incl. item 5) 7/16"-20, 37º x 7/16"-20, O-Ring Superseded by part number: 265235
|
| 14. |
700701796
|
[1] |
FLEXIBLE HOSE
|
CAS
HOSE - hydraulic
|
| 15. |
700711082
|
[3] |
HYDRAULIC HOSE,6.35 mm ID x 270.00 mm, SAE 100R1
|
CAS
6.35 mm ID x 270.00 mm, SAE 100R1
|
| 16. |
121-115
|
[2] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 17. |
231-5145
|
[5] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 18. |
413-516
|
[3] |
BOLT,Hex, 5/16" - 18 x 1", Gr 5
|
CAS
C Hex, 5/16"-18 x 1", G5, Full Thd Superseded by part number: 9635884, 72187198
|
| 19. |
515-23190
|
[6] |
CLAMP,3/4", Insul, 3/8" Bolt
|
CAS
Hose 3/4", Insul, 3/8" Bolt Superseded by part number: 86624005
|
| 20. |
700711009
|
[1] |
HYDRAULIC HOSE,6.35 mm ID x 1850.00 mm, SAE 100R1
|
CAS
6.35 mm ID x 1850.00 mm, SAE 100R1
|
| 21. |
121-226
|
[1] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
| 22. |
231-5146
|
[1] |
FLANGE NUT,3/8"-16
|
CAS
Superseded by part number: 72187068, 247780
|
| 23. |
515-23254
|
[6] |
CLAMP,1", Insul, 3/8" Bolt
|
CAS
Hose 1", Insul, 3/8" Bolt Superseded by part number: 9827902, 72187281
|
| 24. |
700701355
|
[1] |
3 WAY CONNECTION
|
CAS
TEE Superseded by part number: 86513653
|
