| 1. |
700122574
|
[3] |
SUPPORT
|
CAS
- actuator
|
| 2. |
700709996
|
[3] |
SWITCH
|
IH
ACTUATOR
|
| 3. |
700122570
|
[1] |
SUPPORT
|
HFI
- switch
|
| 4. |
700126948
|
[1] |
SUPPORT
|
HFI
|
| 5. |
515-2179
|
[5] |
CLAMP,5/16", Insul, 1/4" Bolt
|
CAS
Superseded by part number: 237910
|
| 6. |
700710199
|
[10] |
GROMMET
|
CAS
|
| 7. |
700710187
|
[9] |
WASHER
|
CAS
#6 WPW STAINLESS STEEL
|
| 8. |
700122476
|
[1] |
SUPPORT
|
HFI
- switch
|
| 9. |
700710208
|
[5] |
ROTARY SWITCH
|
L
SWITCH - assembly
|
| 10. |
413-616
|
[1] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
Superseded by part number: 88206, 72187206
|
| 11. |
496-11041
|
[2] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 12. |
492-11038
|
[1] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 13. |
425-106
|
[1] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 14. |
1713155
|
[1] |
FLAP
|
CAS
- counter
|
| 15. |
700128332
|
[1] |
SUPPORT
|
HFI
- switch
|
| 16. |
700122573
|
[1] |
SUPPORT
|
HFI
- switch
|
| 17. |
700710188
|
[22] |
SCREW
|
CAS
#6-32 X 3/4 CRPHMS GR2
|
| 18. |
700710189
|
[22] |
LOCK NUT
|
CAS
#6-32 LHSN
|
| 19. |
700122568
|
[1] |
SUPPORT
|
HFI
- switch
|
| 20. |
700713345
|
[1] |
CONTROL
|
CAS
BOX COMPLETE
|
| 21. |
700707294
|
[2] |
PUSH-ON NUT
|
CAS
RUBBER WELL NUT Superseded by part number: 694147
|
| 22. |
163-14
|
[3] |
SCREW,Hex Wshr Hd, 1/4" - 20 x 1"
|
CAS
1/4-20 X 1 HWHMS
|
| 23. |
231-5144
|
[3] |
SERRATED NUT,Flg, USR, 1/4"-20
|
CAS
Superseded by part number: 523282, 72187066
|
| 24. |
700114077
|
[1] |
SUPPORT
|
CAS
- control box
|
| 25. |
700707295
|
[2] |
KNOB
|
CAS
|
| 26. |
700710794
|
[1] |
HARNESS
|
CAS
- wire
|
| 27. |
700707598
|
[1] |
WIRE HARNESS
|
IH
CABLE ASSEMBLY
|
| 28. |
700707683
|
[1] |
DECAL
|
CAS
- notice, 12 volt
|
| 29. |
869707C1
|
[1] |
STRAP,368.3mm L
|
IH
TIE - cable Superseded by part number: 529070
|
