| 1. |
413-552
|
[2] |
BOLT,Hex, 5/16" - 18 x 3-1/4", Gr 5
|
CAS
Hex, 5/16"-18 x 1/4", G5 Superseded by part number: 280275
|
| 2. |
231-5145
|
[2] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 3. |
700118879
|
[1] |
NUT
|
CAS
- special
|
| 4. |
425-106
|
[2] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 5. |
496-11041
|
[2] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 6. |
700116206
|
[1] |
SPECIAL BOLT
|
IH
DRAWBOLT
|
| 7. |
51200241
|
[1] |
SPACER
|
CAS
|
| 8. |
700711910
|
[1] |
CYLINDER ASSY.
|
IH
CYLINDER ASSEMBLY - hydraulic
|
| 9. |
700711989
|
[1] |
BOLT,Hex, 5/8" - 11 x 4 1/2", Gr 8
|
CAS
5/8-11 x 4-1/2 C - special
|
| 10. |
396-21066
|
[3] |
WASHER,16.66mm ID x 33.33mm OD x 4.27mm Thk
|
CAS
- 5/8" bolt size 21/32" x 1 5/16" x .150", HDN Superseded by part number: 87613283
|
| 11. |
425-1010
|
[2] |
NUT,5/8"-11, G5
|
CAS
Superseded by part number: 280374
|
| 12. |
218-5135
|
[1] |
ELBOW,45 Degree Elbow, 9/16" - 18 Male JIC x 9/16" - 18 Male ORB
|
CAS
- 45 degrees (Includes item 14) Superseded by part number: 330346
|
| 13. |
413-1044
|
[1] |
BOLT,Hex, 5/8" - 11 x 2-3/4", Gr 5
|
CAS
Superseded by part number: 88693
|
| 14. |
738468
|
[2] |
O-RING
|
IH
|
| 15. |
700707272
|
[2] |
HOSE
|
CAS
- hydraulic
|
| 16. |
218-5105
|
[1] |
ELBOW,90 Degree Elbow, 9/16" - 18 Male JIC x 9/16" - 18 Male ORB
|
CAS
- 90 degrees (Includes item 14) Superseded by part number: 76344, 72186128
|
| 17. |
231-5144
|
[2] |
SERRATED NUT,Flg, USR, 1/4"-20
|
CAS
Superseded by part number: 523282, 72187066
|
| 18. |
515-25127
|
[4] |
CLAMP,1/2", Insul, 1/2" Bolt
|
CAS
Line 1/2", Insul, 1/2" Bolt Superseded by part number: 86632595
|
| 19. |
700707779
|
[1] |
LINE
|
HFI
- hydraulic
|
| 20. |
700707780
|
[1] |
LINE
|
HFI
- hydraulic
|
| 21. |
7072135
|
[2] |
HYDRAULIC HOSE,0.50" ID x 58.00", SAE 100R2
|
IH
HOSE - hydraulic
|
| 22. |
746677
|
[2] |
CAP
|
CAS
1/2-14 NPT CAP
|
| 23. |
7702012
|
[1] |
SELF-TAP SCREW,3/8" - 16 x 1"
|
CAS
3/8-16 x 1 HWHTCTS
|
| 24. |
866061
|
[1] |
EYEBOLT
|
CAS
|
| 25. |
237-6008
|
[2] |
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
|
CAS
8-1, 90 Duro, .644" ID x .087" Thk Superseded by part number: 128825
|
| 26. |
6260244
|
[2] |
SPACER
|
HFI
|
| 27. |
218-5106
|
[2] |
90 ELBOW,90 Degree Elbow, 3/4" - 16 Male JIC x 3/4" - 16 Male ORB
|
CAS
- 90 degrees (Includes item 25) Superseded by part number: 72186176, 128830
|
| 28. |
218-5053
|
[2] |
HYD CONNECTOR,7/16" - 20 JIC x 7/16" - 20 ORB
|
CAS
CONNECTOR, HYD, (Incl. item 29) 7/16"-20, 37º x 7/16"-20, O-Ring Superseded by part number: 265235
|
| 29. |
237-6004
|
[2] |
O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro
|
CAS
4-1, 90 Duro, .351" ID x .072" Thk Superseded by part number: 165202, 72186131
|
| 30. |
700707258
|
[1] |
GOVERNOR
|
IH
REGULATOR ASSEMBLY - flow control
|
