| 1. |
700114118
|
[1] |
FRAME
|
HFI
WA - pickup
|
| 2. |
700114134
|
[1] |
DEFLECTOR
|
HFI
WA - right
|
| 3. |
121-133
|
[17] |
SERRATED BOLT,Hex, 5/16" - 18 x 5/8", Gr 5
|
CAS
Superseded by part number: 271288
|
| 4. |
700122837
|
[1] |
TOOTH
|
IH
WRAPPER - tine, left
|
| 5. |
700114144
|
[15] |
GUARD
|
L
WRAPPER - tine
|
| 6. |
700122840
|
[1] |
TOOTH
|
IH
WRAPPER - tine, right
|
| 7. |
121-115
|
[1] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 8. |
231-5145
|
[19] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 9. |
219-93
|
[2] |
LUBE NIPPLE,90 Degree Elbow, 1/4" - 28 NPTF
|
CAS
Superseded by part number: 87415
|
| 10. |
409-7512
|
[1] |
BOLT,Hex Flg, 5/16" - 18 x 3/4", Spcl
|
CAS
Hex Flg, 5/16-18 x 3/4", Serr Superseded by part number: 145913, 72187186
|
| 11. |
700114172
|
[1] |
TUBE,38.1 mm OD, 102 mm Length
|
CAS
- pickup, pivot
|
| 12. |
700116125
|
[1] |
HOUSING
|
CAS
TRACK - cam
|
| 13. |
413-616
|
[3] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
Superseded by part number: 88206, 72187206
|
| 14. |
492-11038
|
[6] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 15. |
617863R1
|
[2] |
FLANGED BEARING
|
IH
- bearing
|
| 16. |
51292
|
[1] |
SPHERICAL BEARING,1.25" ID x 72 mm OD x 19 mm
|
IH
Superseded by part number: 84330041, 47508357
|
| 17. |
413-1288
|
[1] |
BOLT,Hex, 3/4" - 10 x 5-1/2", Gr 5
|
CAS
.75 X 5.5 UNC GR5 YZD Superseded by part number: 86507002
|
| 18. |
495-21081
|
[1] |
WASHER,3/4"
|
CAS
Superseded by part number: 86511191
|
| 19. |
492-11075
|
[1] |
LOCK WASHER,3/4"
|
CAS
3/4" Superseded by part number: 87340
|
| 20. |
425-1012
|
[1] |
NUT,3/4"-10, G5
|
CAS
Superseded by part number: 280954
|
| 21. |
378521
|
[1] |
SPACER
|
CAS
|
| 22. |
700114170
|
[1] |
STRAP
|
HFI
|
| 23. |
413-1024
|
[1] |
BOLT,Hex, 5/8" - 11 x 1-1/2", Gr 5
|
CAS
Superseded by part number: 88062
|
| 24. |
495-21069
|
[1] |
WASHER,5/8"
|
CAS
5/8 WIDE PLAIN WASHER Superseded by part number: 80299
|
| 25. |
492-11062
|
[1] |
BEARING WASHER,5/8"
|
CAS
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
| 26. |
425-1010
|
[1] |
NUT,5/8"-11, G5
|
CAS
Superseded by part number: 280374
|
| 27. |
413-620
|
[3] |
BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5
|
CAS
C Hex, 3/8"-16 x 1 1/4", G5, Full Thd Superseded by part number: 72187207, 88011
|
| 28. |
425-106
|
[3] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 29. |
433-512
|
[18] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
Superseded by part number: 280327
|
