| 1. |
451542
|
[2] |
SPACER
|
HFI
|
| 2. |
73528
|
[2] |
SELF-TAP SCREW
|
CAS
3/8-16 x 1-1/2 HWHTCTS
|
| 3. |
6246995
|
[2] |
CLAMP
|
CAS
- line
|
| 4. |
700118981
|
[2] |
CLAMP
|
HFI
- hose
|
| 5. |
700118982
|
[2] |
CLAMP
|
HFI
- hose
|
| 6. |
700708910
|
[1] |
HOSE
|
CAS
- hydraulic
|
| 7. |
700709350
|
[1] |
LINE
|
CAS
- hydraulic
|
| 8. |
700709349
|
[1] |
LINE
|
CAS
- hydraulic
|
| 9. |
218-735
|
[2] |
UNION,3/4"-16, 37 Degree x 3/4"-16, 37 Degree
|
CAS
Superseded by part number: 72186179, 128822
|
| 10. |
700709348
|
[2] |
LINE
|
CAS
- hydraulic
|
| 11. |
218-5243
|
[2] |
TEE,9/16" - 18 Male JIC x 9/16" - 18 Male JIC x 9/16" - 18 Male ORB
|
CAS
Straight run (Includes item 32) 9/16"-18, 37º x 9/16"-18, O-Ring Run Superseded by part number: 86513020
|
| 12. |
700118985
|
[1] |
MOUNTING PARTS
|
HFI
MOUNTING - valve
|
| 13. |
413-528
|
[2] |
BOLT,Hex, 5/16" - 18 x 1-3/4", Gr 5
|
CAS
Superseded by part number: 9707515, 72187200
|
| 14. |
231-5145
|
[4] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 15. |
409-7516
|
[2] |
BOLT,Hex Flg, 5/16" - 18 x 1", Spcl
|
CAS
Superseded by part number: 86512168
|
| 16. |
700709341
|
[1] |
LINE
|
CAS
- hydraulic
|
| 17. |
700709343
|
[1] |
VALVE
|
IH
ASSEMBLY - hydraulic, shuttle
|
| 18. |
218-5183
|
[2] |
TEE,3/4" - 16 Male JIC x 3/4" - 16 Male JIC x 3/4" - 16 Male ORB
|
CAS
- straight thread branch (Includes item 33) Superseded by part number: 86513024
|
| 19. |
700709342
|
[1] |
LINE
|
CAS
- hydraulic
|
| 20. |
218-5058
|
[1] |
HYD CONNECTOR,9/16" - 18 Male JIC x 3/4" - 18 Male ORB
|
CAS
CONNECTOR - short straight thread (Includes item 33) Superseded by part number: 128817, 72186139
|
| 21. |
700709382
|
[1] |
HOSE
|
CAS
- hydraulic
|
| 22. |
700708906
|
[1] |
LINE
|
CAS
- hydraulic
|
| 23. |
218-5222
|
[1] |
TEE,37 Degree, 9/16"-18, x 9/16"-18, Fem Sw Run
|
CAS
Superseded by part number: 72186135, 129274
|
| 24. |
218-5057
|
[3] |
HYD CONNECTOR,9/16" - 18 JIC x 9/16" - 18 ORB
|
CAS
CONNECTOR - flared (Incl. item 32) Superseded by part number: 76350
|
| 25. |
700708907
|
[1] |
VALVE
|
IH
ASSEMBLY - hydraulic
|
| 26. |
700708912
|
[1] |
HYDRAULIC HOSE,9.65 mm ID x 950.00 mm, SAE 100R2
|
CAS
9.65 mm ID x 950.00 mm, SAE 100R2
|
| 27. |
700708911
|
[1] |
HYDRAULIC HOSE,9.65 mm ID x 721.00 mm, SAE 100R2
|
CAS
(Includes item 32) 9.65 mm ID x 721.00 mm, SAE 100R2
|
| 28. |
700708908
|
[1] |
HOSE
|
CAS
- hydraulic
|
| 29. |
214-1464
|
[4] |
HOSE CLAMP,#64, 3.56" - 4.5", Type F Worm
|
CAS
CLAMP, HOSE, #64, 3.56/4.50 Type F Worm Superseded by part number: 86625034
|
| 30. |
218-5105
|
[2] |
ELBOW,90 Degree Elbow, 9/16" - 18 Male JIC x 9/16" - 18 Male ORB
|
CAS
(Includes item 32) Superseded by part number: 76344, 72186128
|
| 31. |
700712161
|
[2] |
CYLINDER ASSY.,Double Acting, 38.1mm Rod, 304.8mm Stroke
|
IH
CYLINDER ASSEMBLY - hydraulic
|
| 32. |
738468
|
[1] |
O-RING
|
IH
|
| 33. |
237-6008
|
[1] |
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
|
CAS
8-1, 90 Duro, .644" ID x .087" Thk Superseded by part number: 128825
|
