凯斯零件查询(8450) - CASE IH ROUND BALER (1/88-12/93) (042) - ELECTRICAL SENSOR AND ACTUATOR ASSEMBLY, SERIAL NUMBER CFH0015275 AND ON Case Agriculture

Pos.	Part No	Qty	Parts name	Comments
1.	751487	[9]	CLAMP	CAS Superseded by part number: 86632595
2.	755744	[1]	CLAMP	CAS Superseded by part number: 86594406
3.	700708971	[1]	HARNESS	CAS- Wiring, Front
4.	700119161	[3]	SWITCH	LAssembly (S.N. CFH0015001 thru 0015766)
5.	700710211	[2]	ACTUATOR	IHSwitch Assembly
6.	700116136	[1]	SUPPORT	HFI- Switch (S.N. CFH0015001 thru 0015766)
7.	700708970	[1]	HARNESS	CAS- Wiring, Rear
8.	700708965	[1]	PLUG	CAS
9.	700708964	[1]	WIRE CONNECTOR	CASConnector - Male Superseded by part number: 87692802
10.	700708963	[1]	WIRE CONNECTOR	CASConnector - Female Superseded by part number: 87692817
11.	700708761	[2]	ELEC CONNECTOR,Female	IHConnector - Female Superseded by part number: 87692855
12.	700708760	[8]	ELEC. TERMINAL PIN,18 - 20 SAE	IH- Sleeve, Female Superseded by part number: 225123C1
13.	700708757	[5]	ELEC. TERMINAL PIN,18 - 16 SAE	CASPin
14.	700708079	[1]	WIRE CONNECTOR	CASReceptacle Superseded by part number: 87702796
15.	158758	[1]	SPACER	HFI(S.N. CFH0015767 and on) Superseded by part number: 568395R1
16.	705657	[6]	WASHER	CAS3/8 Narrow Plain Washer Superseded by part number: 495-11041, 495-11041, NLS
17.	700122574	[1]	SUPPORT	CAS- Actuator
18.	700709996	[1]	SWITCH	IHActuator
19.	700710188	[4]	SCREW	CASNo. 6-32 x 3/4 CRPHMS
20.	700710208	[1]	ROTARY SWITCH	LSwitch Assembly
21.	700122570	[1]	SUPPORT	HFI- Switch
22.	700710189	[4]	LOCK NUT	CASNo. 6-32 LHSN
23.	700710448	[1]	CLAMP	CAS- Line Superseded by part number: 237910
24.	700710187	[4]	WASHER	CASNo. 6 Plain Washer
25.	700710199	[2]	GROMMET	CAS
26.	701953	[2]	SELF-TAP SCREW	CAS5/16-18 x 3/4 HWHTCTS Superseded by part number: 172463
27.	73528	[1]	SELF-TAP SCREW	CAS3/8-16 x 1-1/2 HWHTCTS
. .	7883325	[4]	BOLT,Hex, 5/16" - 18 x 3/4", Gr 120M	CAS5/16-18 x 3/4 HWHMS Superseded by part number: 121-115
. .	7883382	[1]	BOLT,Hex, 3/8" - 16 x 1", Gr 120M	CAS3/8-16 x 1 HWHMS Superseded by part number: 87034804
