凯斯零件查询(8435) - CASE IH SILAGE SPECIAL ROUND BALER (1/97-12/00) (6-04) - ROLLER AND SUPPORT ASSEMBLIES, SERIAL NUMBER CFH0124401 AND LATER Case Agriculture

作者：广数供应链运营团队

浏览数：

时间：2025-01-21 15:15:53

Parts Contact me WhatsApp

Pos.	Part No	Qty	Parts name	Comments
1.	413-1244	[2]	BOLT,Hex, 3/4" - 10 x 2-3/4", Gr 5	CAS 3/4-10 X 2-3/4 C Superseded by part number: 80280173
2.	492-11075	[12]	LOCK WASHER,3/4"	CAS 3/4" Superseded by part number: 87340
3.	413-1232	[10]	BOLT,Hex, 3/4" - 10 x 2", Gr 5	CAS Superseded by part number: 88557
4.	700711166	[6]	WASHER	CAS 3/4 HARDENED WIDE PLAIN WASHER
5.	700707981	[4]	SCREW,FLAT, 3/4" - 10 x 1-3/4"	L 3/4-10 X 1-3/4 HSFCHCS - special
6.	214817	[6]	SPACER	CAS BUSHING
7.	700135023	[2]	HOUSING	HFI ASSEMBLY - bearing (includes item 11)
8.	413-848	[6]	BOLT,Hex, 1/2" - 13 x 3", Gr 5	IH 1/2-13 X 3 C Superseded by part number: 72187218, 87339
9.	705541	[6]	WASHER,0.53" ID x 1.06" OD x 0.14" Thk	CAS 1/2 HARDENED PLAIN WASHER
10.	700132410	[4]	BEARING ASSY,50.8 mm ID x 100 mm OD x 10, 7 mm	HFI BEARING ASSEMBLY - 100mm (includes item 11) Superseded by part number: 700150032
11.	712158	[6]	SPHERICAL BEARING,2" ID x 100 mm OD	L BEARING - spherical Superseded by part number: 47577203
12.	8050825	[12]	BEARING, ROLLER, CYL,38.1 mm ID x 80 mm OD x 30.163 mm	L - cylindrical Superseded by part number: F82059
13.	700132353	[1]	SHAFT	HFI
14.	F82059	[2]	BEARING ASSY,38.1mm ID x 80mm OD x 22mm W	IH BEARING - cylindrical (includes collar)
15.	433-824	[12]	CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/2", Gr 5	CAS 1/2-13 X 1-1/2 RHSNB Superseded by part number: 280420, 72187237
16.	231-5348	[12]	FLANGE NUT,Flg, 1/2"-13	CAS 1/2-13 HFTLN GR/G Superseded by part number: 86521610
17.	700135117	[2]	RING	HFI - grass
18.	700148218	[2]	ROLLER	HFI ASSEMBLY (includes items 12, 13 and 14)
19.	700135188	[2]	COVER	HFI
20.	700132345	[1]	ROLLER	HFI ASSEMBLY
21.	700135112	[1]	ROLLER	HFI ASSEMBLY - top
22.	700125071	[2]	HUB	CAS
23.	700132350	[1]	ROLLER	HFI ASSEMBLY (includes item 24)
24.	700710914	[2]	BEARING, ROLLER, CYL,55.56mm ID x 100mm OD x 24mm W	L BEARING - cylindrical
25.	700100927	[10]	HUB	L
26.	700116217	[5]	ROLL	IH ER ASSEMBLY (includes item 12)
