| 1. |
Q3929
|
[1] |
KEY,Gib, 5/16" Sq x 1 1/2"
|
IH
gib, 5/16" x 1-1/2"
|
| 2. |
6284046
|
[1] |
PINION
|
L
SPROCKET, WA, 50B45
|
| 3. |
413-612
|
[3] |
BOLT,Hex, 3/8" - 16 x 3/4", Gr 5
|
CAS
Superseded by part number: 72187204, 86500692
|
| 4. |
492-11038
|
[7] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 5. |
700708091
|
[2] |
SPHERICAL BEARING,34.93 mm ID x 72 mm OD x 38.89 mm
|
CAS
spherical Superseded by part number: 47577188, 47066
|
| 6. |
617863R1
|
[2] |
FLANGED BEARING
|
IH
bearing
|
| 7. |
700101791
|
[6] |
PIVOT PIN,27.56mm OD x 90mm L
|
L
|
| 8. |
700101784
|
[1] |
ROTOR
|
CAS
WA, Includes: Ref. 18
|
| 9. |
700705612
|
[3] |
CAM FOLLOWER
|
L
cam follower Superseded by part number: 86536275
|
| 10. |
702700045
|
[3] |
LOCK NUT
|
L
spiralock, 1/2"-20
|
| 11. |
700101780
|
[3] |
BAR PLATE
|
L
WA tine
|
| 12. |
413-632
|
[21] |
BOLT,Hex, 3/8" - 16 x 2", Gr 5
|
CAS
Superseded by part number: 88436
|
| 13. |
230-4216
|
[21] |
LOCK NUT,3/8"-16, GA
|
CAS
Center Superseded by part number: 87039402
|
| 14. |
1710102
|
[21] |
TOOTH
|
L
TINE double
|
| 15. |
700101769
|
[3] |
SPACER
|
HFI
|
| 16. |
495-81197
|
[3] |
WASHER,1 3/16" x 1 3/4" x .065"
|
CAS
BUSHING machinery, narrow rim, 1-1/8" x 14 gauge
|
| 17. |
6867824
|
[21] |
SUPPORT
|
L
tine
|
| 18. |
700700822
|
[6] |
NYLON BEARING,28.931 mm ID x 50.8 mm OD x 15 mm
|
L
sleeve Superseded by part number: 700052369
|
| 19. |
700131871
|
[1] |
FRAME
|
HFI
WA pickup
|
| 20. |
434-616
|
[3] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
Superseded by part number: 80280503
|
| 21. |
231-5146
|
[3] |
FLANGE NUT,3/8"-16
|
CAS
Superseded by part number: 72187068, 247780
|
| 22. |
51200755
|
[2] |
FLANGE
|
CAS
bearing
|
| 23. |
433-512
|
[28] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
Superseded by part number: 280327
|
| 24. |
231-5145
|
[28] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
Superseded by part number: 72187067, 145458
|
| 25. |
6467674
|
[1] |
SPACER
|
CAS
|
| 26. |
413-1232
|
[1] |
BOLT,Hex, 3/4" - 10 x 2", Gr 5
|
CAS
Superseded by part number: 88557
|
| 27. |
705566
|
[2] |
WASHER
|
IH
hardened plain, 3/4"
|
| 28. |
492-11075
|
[2] |
LOCK WASHER,3/4"
|
CAS
3/4" Superseded by part number: 87340
|
| 29. |
425-1012
|
[2] |
NUT,3/4"-10, G5
|
CAS
Superseded by part number: 280954
|
| 30. |
413-1280
|
[1] |
BOLT,Hex, 3/4" - 10 x 5", Gr 5
|
CAS
Superseded by part number: 88421
|
| 31. |
6881403
|
[1] |
SPACER
|
HFI
|
| 32. |
6868129
|
[14] |
STRIPPER ASSY.
|
L
WRAPPER pickup
|
| 33. |
700101789
|
[1] |
CAM
|
CAS
cam
|
| 34. |
61-43816
|
[2] |
HEX SOC SCREW,FLAT, 3/8" - 16 x 1"
|
CAS
cap, hex socket flat countersunk head, 3/8"-16 x 1"
|
| 35. |
425-106
|
[4] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 36. |
413-616
|
[2] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
Superseded by part number: 88206, 72187206
|
