| 1. |
136764H1
|
[16] |
|
P
WASHER - flat, 13/32 x 1-3/8 x 1/8 inch (10 x 34 x 3 mm)
|
| 2. |
ZA105236
|
[1] |
SHIELD
|
IH
- end left
|
| 3. |
488837C1
|
[4] |
SPRING NUT
|
IH
- speed
|
| 4. |
ZA105167
|
[1] |
SHIELD
|
IH
|
| 5. |
ZA105332
|
[1] |
BOLT
|
IH
U-BOLT
|
| 6. |
ZA105333
|
[1] |
GUIDE
|
IH
- twine
|
| 7. |
189293
|
[2] |
BOLT,Hex, 1/4" - 20 x 3 1/2", Gr 5
|
IH
- hex, 1/4 NC x 3-1/2 inch Superseded by part number: 280492
|
| 8. |
378531R1
|
[4] |
LOCK NUT,1/4"-20, GA
|
IH
NUT - hex lock, 1/4 inch NC Superseded by part number: 87034810
|
| 9. |
ZA105271
|
[2] |
CLAMP
|
IH
- twine
|
| 10. |
ZA746267
|
[2] |
SPRING
|
IH
|
| 11. |
9413979
|
[4] |
LOCK NUT,3/8"-16, GC
|
IH
NUT - hex lock, 3/8 inch NC Type 8 Superseded by part number: 232-4136
|
| 12. |
ZA105153
|
[1] |
SUPPORT
|
IH
- cutoff left
|
| 13. |
ZA105273
|
[1] |
ARM
|
IH
- jam left Superseded by part number: 700120309
|
| 14. |
133135C1
|
[4] |
WASHER
|
IH
WASHER
|
| 15. |
25710R1
|
[8] |
WASHER
|
IH
- flat, 17/32 x 1-1/16 x 1/8 inch (13 x 26 x 3 mm) Superseded by part number: 86624188
|
| 16. |
96313C1
|
[2] |
BOLT
|
IH
|
| 17. |
103362
|
[4] |
COTTER PIN,1/16" x 3/4"
|
IH
Pin, Split (Cotter), 1/16" x 3/4" Superseded by part number: 86624069
|
| 18. |
138082
|
[4] |
CLEVIS PIN,3/16" x .580"
|
IH
PIN - clevis, 3/16 x 37/64 inch Superseded by part number: 86596057
|
| 19. |
ZA105064
|
[2] |
CABLE
|
IH
Superseded by part number: 700709517
|
| 20. |
20893R1
|
[4] |
WASHER
|
IH
- flat, 11/32 x 7/8 x 3/32 inch (8 x 22 x 2 mm) Superseded by part number: 86624143
|
| 21. |
ZA105063
|
[2] |
SUPPORT
|
IH
- pulley
|
| 22. |
ZA206636
|
[1] |
PULLEY
|
IH
|
| 23. |
ZA206630
|
[2] |
SPACER
|
IH
Superseded by part number: 6523799
|
| 24. |
ZA105331
|
[2] |
SPRING
|
IH
Superseded by part number: 700709636
|
| 25. |
ZA105292
|
[2] |
GUIDE
|
IH
- twine Superseded by part number: 700120098
|
| 26. |
ZA105239
|
[1] |
ANCHOR
|
IH
- spring
|
| 27. |
ZA105157
|
[1] |
SUPPORT
|
IH
TRIGGER - left
|
| 28. |
ZA105197
|
[2] |
SPRING
|
IH
|
| 29. |
ZA104892
|
[2] |
KNIFE
|
IH
|
| 30. |
ZA105160
|
[1] |
TUBE
|
IH
TURBE - twine left
|
| 31. |
ZA105161
|
[1] |
TUBE
|
IH
- twine right Superseded by part number: ZA105402
|
| 32. |
ZA105289
|
[1] |
BRACKET
|
IH
Superseded by part number: 700120276
|
| 33. |
ZA105051
|
[1] |
SUPPORT
|
IH
- arm
|
| 34. |
20885R1
|
[1] |
WASHER
|
IH
- flat, 1-5/32 x 2 x 1/16 inch (29 x 50 x 1 mm) Superseded by part number: 86624175
|
| 35. |
ZA105151
|
[2] |
BRACKET
|
IH
|
| 36. |
120393
|
[2] |
BEARING WASHER,5/16", SAE
|
IH
WASHER - flat, 11/32 x 11/16 x 1/16 inch (8 x 17 x 1 mm) Superseded by part number: 28588R1
|
| 37. |
ZA105065
|
[2] |
GEAR
|
IH
- spur, 6 teeth
|
| 38. |
ZA105238
|
[1] |
PLATE
|
IH
MOUNT - switch (Prior to P.I.N. 00075)
|
| 39. |
ZA105290
|
[1] |
BRACKET
|
IH
MOUNT
|
| 40. |
ZA105156
|
[1] |
SUPPORT
|
IH
TRIGGER - right
|
| 41. |
ZA105272
|
[1] |
ARM
|
IH
- jam right Superseded by part number: 700120310
|
| 42. |
ZA105152
|
[1] |
SUPPORT
|
IH
- cutoff right
|
| 43. |
ZA105235
|
[1] |
SHIELD
|
IH
- right
|
| 44. |
ZA104769
|
[1] |
ELECTRICAL WIRE
|
IH
WIRE - twine thread (Replaces ZA104628)
|
| 45. |
ZA104559
|
[1] |
BRACKET
|
IH
MOUNT - switch (P.I.N. 001180 thru 001530) Superseded by part number: 700120872
|
| 46. |
87414
|
[2] |
LUBE NIPPLE,1/4" - 28
|
NH
FITTING - self tapping grease, 1/4-28 PTF
|
| . . |
ZA105804
|
[1] |
CYLINDER
|
CAS
hydraulic tying-need for cross tube
|
| . . |
ZA105808
|
[1] |
SHAFT
|
CAS
ROD, hydraulic tying-need for cross tube
|
| . . |
ZA105811
|
[1] |
SEAL
|
CAS
SEAL, hydraulic tying-need for cross tube
|
| . . |
ZA103959
|
[1] |
CYLINDER
|
CAS
for KMW tube, ref to 3640 illustr. for cyl only Superseded by part number: ZA105804
|
| . . |
ZA104015
|
[1] |
SHAFT
|
CAS
ROD, for KMW tube
|
| . . |
ZA516462
|
[1] |
SEAL KIT
|
CAS
SEAL, for KMW tube
|
