凯斯零件查询(3650) - CASE IH ROUND TIE BALER (1/84-12/88) (44) - BELTS & ROLLER ASSEMBLIES 5 - 8, MACHINES WITH 1.378" (35 MM) ID BEARINGS, PRIOR TO P.I.N. 001530 Case Agriculture

作者：广数供应链运营团队
浏览数：
时间：2025-01-21 14:33:04
Parts Contact me WhatsApp

工程机械零件图册查询

专业 覆盖挖掘机、装载机、推土机全系配件
立即查询
Caterpillar 卡特彼勒 Komatsu 小松 SANY 三一重工 XCMG 徐工 Hitachi 日立建机 Volvo 沃尔沃 Liebherr 利勃海尔 John Deere 约翰迪尔 Zoomlion 中联重科 Doosan 斗山 Hyundai 现代 JCB 杰西博 Kobelco 神钢 LiuGong 柳工 Case 凯斯 Kubota 久保田 Terex 特雷克斯 Yanmar 洋马 Bobcat 山猫 Sandvik 山特维克 Metso 美卓 Manitou 曼尼通 Wacker Neuson 威克诺森 Shantui 山推 SDLG 临工 Lonking 龙工 Sunward 山河智能 Lovol 雷沃 XGMA 厦工 Kato 加藤 Tadano 多田野 Sumitomo 住友 Takeuchi 竹内 Bell 贝尔 Hidromek 海德罗梅克 Atlas Copco 阿特拉斯·科普柯 Wirtgen 维特根 Vögele 福格勒 Hamm 悍马 Bomag 宝马格 Ammann 安迈 Dynapac 戴纳派克 Genie 吉尼 JLG 捷尔杰 Skyjack 斯凯杰科 Haulotte 欧历胜 Palfinger 帕尔菲格 Hiab 希尔博 Sennebogen 森尼伯根 Yuchai 玉柴 Caterpillar 卡特彼勒 Komatsu 小松 SANY 三一重工 XCMG 徐工 Hitachi 日立建机 Volvo 沃尔沃 Liebherr 利勃海尔 John Deere 约翰迪尔 Zoomlion 中联重科 Doosan 斗山 Hyundai 现代 JCB 杰西博 Kobelco 神钢 LiuGong 柳工 Case 凯斯 Kubota 久保田 Terex 特雷克斯 Yanmar 洋马 Bobcat 山猫 Sandvik 山特维克 Metso 美卓 Manitou 曼尼通 Wacker Neuson 威克诺森 Shantui 山推 SDLG 临工 Lonking 龙工 Sunward 山河智能 Lovol 雷沃 XGMA 厦工 Kato 加藤 Tadano 多田野 Sumitomo 住友 Takeuchi 竹内 Bell 贝尔 Hidromek 海德罗梅克 Atlas Copco 阿特拉斯·科普柯 Wirtgen 维特根 Vögele 福格勒 Hamm 悍马 Bomag 宝马格 Ammann 安迈 Dynapac 戴纳派克 Genie 吉尼 JLG 捷尔杰 Skyjack 斯凯杰科 Haulotte 欧历胜 Palfinger 帕尔菲格 Hiab 希尔博 Sennebogen 森尼伯根 Yuchai 玉柴
Pos. Part No Qty Parts name Comments
1. 1017954R1 [8]   PLUG,Cap, .485" OD   IH - cap Superseded by part number: 87644289
2. ZA105038 [2]   BLOCK   IH - adjusting left
. . 180081 [4]   BOLT,Hex, 5/16"-18 x 1 1/4", G5   IH hex, 5/16"-18 NC x 1-1/4", grade 5 Superseded by part number: 179820
3. 120378 [4]   NUT,Hex, 1/2" - 13, Gr 5   IH NUT, 1/2"-13, G5 Superseded by part number: 280431
4. 180192 [4]   BOLT (SPREADER),Hex, 1/2" - 13 x 3 1/2", Gr 5   IH BOLT - hex, 1/2 NC x 3-1/2 inch Superseded by part number: 179895
5. ZA105045 [6]   COLLAR   IH - bearing
. . 9635884 [24]   BOLT,Hex, 5/16" - 18 1", Full Thd, Gr 5   NH - hex, 5/16 NC x 1 inch
6. 1415467R91 [6]   BALL BEARING,35 mm ID x 72 mm OD x 17 mm   IH - 1.378 inch ID (35 mm) Superseded by part number: 84002007
7. ZA105010 [2]   ROLLER   IH (No. 5 and 7) Superseded by part number: 228695A1, 228681A1
8. 21448R1 [1]   WASHER   CAS - flat, 11/32 x 7/8 x 3/32 inch (8 x 22 x 2 mm) Superseded by part number: 495-81253
9. ZA105030 [2]   DIVIDER   IH - (For 4-3/4 inch wide belts) (Prior to P.I.N. 001179)
9. ZA105297 [2]   DIVIDER   IH - (For 11 inch wide belts) (P.I.N. 001180 and after)
10. ZA105025 [2]   BRACKET   IH
. . 16897R1 [4]   CARRIAGE BOLT,Short Nk, 5/16" - 18 x 3/4", Gr 2, Full Thd   IH BOLT - round head, square neck, 5/16 NC x 3/4 inch Superseded by part number: 412-512
. . 12872R1 [4]   BOLT,Short NK, 5/16"-18 x 1", G2, Full Thd   IH CARRIAGE, Short NK, 5/16"-18 x 1", G2, Full Thd Superseded by part number: 598803R1
11. ZA105023 [4]   BLADE   IH SCRAPER
12. ZA105026 [2]   BRACKET   IH
13. ZA105012 [2]   ROLLER   IH (No. 6 and 8) Superseded by part number: 228685A1, 228695A1
14. ZA104412 [22]   BELT,4.75" W 73.22" L   IH 4.75" W x 73.22" L, Top endless (Prior to P.I.N. 001179)
14. ZA105005 [10]   BELT   IH - top endless (11 inch wide) (P.I.N. 001180 and after) Superseded by part number: 700709544
15. ZA104107 [22]   BELT   IH - Top (4-3/4 inch wide) (Prior to P.I.N. 001179)
15. ZA105003 [10]   BELT   IH - Top (11 inch wide) (P.I.N. 001180 and after) Superseded by part number: 700724731
16. ZA102971 [22]   PIN   IH - (For 4-3/4 inch belt) (Prior to P.I.N. 001179)
16. ZA102977 [10]   PIN   IH - (For 11 inch belt) (P.I.N. 001180 and after)
17. ZA104841 [2]   HOUSING   IH - bearing
. . 18684R1 [10]   BOLT,Sht Sq Nk, 3/8" - 16 x 1 1/4", Gr 2   IH - round head, square neck, 3/8 NC x 1-1/4 inch Superseded by part number: 550796R1
18. 120394 [10]   WASHER,3/8", SAE   IH WASHER - flat, 13/32 x 13/16 x 1/16 inch (10 x 20 x 1 mm) Superseded by part number: 87016
19. 96328C1 [2]   BALL BEARING,40mm ID x 80mm OD x 22mm W   CAS - 1.5753 inch ID (40 mm)
20. ZA104227 [1]   SPROCKET ASSY.   IH SPROCKET - 30 teeth
. . 180130 [4]   BOLT,Hex, 3/8" - 16 x 2", Gr 5   IH - hex, 3/8 NC x 2 inch Superseded by part number: 113-219
. . 113-257 [4]   BOLT,Hex, 3/8" - 16 x 2-1/2", Gr 5   CAS - hex, 3/8 NC x 2-1/2 inch Superseded by part number: 87936
21. ZA104593 [2]   HUB   IH - splined
22. 357020R1 [2]   WASHER   IH - flat, 17/32 x 1-3/4 x 1/4 inch (13 x 44 x 6 mm)
23. 26316R1 [2]   BOLT,Hex, 1/2" - 13 x 1", Gr 8   IH - hex lock, 1/2 NC x 1 inch Type 8 Superseded by part number: 113-451
24. NSS [1]   NOT SOLD SEPARAT   CON CHAIN (Use 121 links from roll marked 611362R91, 1 offset link 612612R91 and 1 connecting link 574532R91)
. . 611362R91 [1]   CHAIN (AG)   IH CHAIN - 10 foot (3.048 m) roll Superseded by part number: 611362R91X
. . 612612R91 [1]   CHAIN LINK   IH LINK - offset Superseded by part number: 241-1716
. . 574532R91 [1]   CLIP, SPRING   IH LINK - connecting Superseded by part number: 241-1316
25. ZA304776 [1]   SLIDE   IH - chain Superseded by part number: 700709424
. . 27464R1 [1]   CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 4", Gr 5   IH BOLT - round head, square neck, 1/2 NC x 4 inch Type 5 Superseded by part number: 87495288
26. ZA105037 [2]   BLOCK   IH - adjusting right
. . 208790C1 [1]   PACKAGE   IH KIT - belt repair (Box of lacing hooks)
. . 1254050C1 [1]   TOOL   IH LACER - belt (6 inch) Superseded by part number: 828459
