| 1. |
ZA104289
|
[1] |
HOUSING
|
IH
- main frame
|
| 2. |
ZA740950
|
[4] |
DECAL
|
CAS
- warning Superseded by part number: ZA211862
|
| 3. |
96319C1
|
[1] |
DECAL
|
IH
- caution
|
| 4. |
96330C1
|
[1] |
PRODUCT GRAPHIC
|
IH
DECAL - caution
|
| 5. |
ZA104475
|
[1] |
SHIELD
|
IH
|
| . . |
16897R1
|
[3] |
CARRIAGE BOLT,Short Nk, 5/16" - 18 x 3/4", Gr 2, Full Thd
|
IH
BOLT - round head, square neck, 5/16 NC x 3/4 inch Superseded by part number: 412-512
|
| 6. |
ZA105141
|
[1] |
SHIELD
|
IH
- left
|
| 7. |
ZA103650
|
[1] |
SHIELD
|
IH
- front left (Replaces 1281040C1)
|
| 8. |
ZA104575
|
[1] |
PRODUCT GRAPHIC
|
IH
DECAL - warning
|
| 9. |
ZA103822
|
[2] |
ROD
|
IH
- retaining
|
| 10. |
ZA104433
|
[1] |
SHIELD
|
IH
- cover front left
|
| 11. |
ZA103138
|
[5] |
FASTENER
|
IH
|
| 12. |
ZA103937
|
[10] |
WASHER
|
IH
- retaining Superseded by part number: 1326407C1
|
| 13. |
96326C1
|
[6] |
SLEEVE
|
IH
|
| 14. |
ZA104429
|
[3] |
CABLE
|
IH
|
| 15. |
16964R91
|
[2] |
FITTING
|
IH
- grease, 1/4 inch 90 degree Superseded by part number: 87414
|
| 16. |
NSS
|
[2] |
NOT SOLD SEPARAT
|
CON
DECAL - grease (50 hours) (Order kit 1265869C93)
|
| 17. |
ZA103651
|
[1] |
SHIELD
|
IH
- front right (Replaces 1281039C1)
|
| 18. |
ZA104576
|
[1] |
PRODUCT GRAPHIC
|
IH
DECAL - warning
|
| 19. |
ZA104432
|
[1] |
SHIELD
|
IH
- cover front right
|
| 20. |
ZA104346
|
[1] |
SHIELD
|
IH
- drive
|
| 22. |
ZA104343
|
[1] |
CHANNEL
|
IH
|
| 23. |
ZA105351
|
[1] |
CHANNEL
|
IH
- axle splice
|
| . . |
180179
|
[8] |
BOLT,Hex, 1/2" - 13 x 1 3/4", Gr 5
|
IH
- hex, 1/2 NC x 1-3/4 inch Superseded by part number: 113-412
|
| . . |
120384
|
[8] |
WASHER,1/2"
|
IH
LOCK, 1/2" Superseded by part number: 116121
|
| . . |
120387
|
[8] |
WASHER,3/8" x 3/4" x .060"
|
IH
NUT - hex, 1/2 inch NC Superseded by part number: 80664
|
| 24. |
25710R1
|
[16] |
WASHER
|
IH
- flat, 17/32 x 1-1/16 x 1/8 inch (13 x 26 x 3 mm) Superseded by part number: 86624188
|
| 26. |
ZA104814
|
[1] |
RETAINER
|
IH
- crop
|
| 27. |
20704R1
|
[6] |
WASHER
|
IH
- flat, 1-1/32 x 1-1/2 x 7/64 inch (26 x 38 x 2 mm) Superseded by part number: 86624170
|
| 28. |
ZA105666
|
[1] |
SHAFT
|
IH
PIN
|
| 29. |
96332C1
|
[1] |
PRODUCT GRAPHIC
|
IH
DECAL - warning
|
