| 1. |
136764H1
|
[16] |
|
P
WASHER - flat, 13/32 x 1-3/8 x 1/8 inch (10 x 35 x 3 mm)
|
| 2. |
ZA105236
|
[1] |
SHIELD
|
IH
- end, left
|
| 3. |
488837C1
|
[4] |
SPRING NUT
|
IH
- speed
|
| 4. |
ZA105985
|
[1] |
SHIELD
|
CAS
- threader, front
|
| 5. |
ZA105332
|
[1] |
BOLT
|
IH
U-BOLT - 1/4 inch NC
|
| 6. |
ZA105333
|
[1] |
GUIDE
|
IH
- twine
|
| 7. |
189293
|
[2] |
BOLT,Hex, 1/4" - 20 x 3 1/2", Gr 5
|
IH
- hex, 1/4 NC x 3-1/2 inch Superseded by part number: 280492
|
| 8. |
378531R1
|
[4] |
LOCK NUT,1/4"-20, GA
|
IH
NUT - hex lock, 1/4 inch NC Superseded by part number: 87034810
|
| 9. |
ZA105271
|
[2] |
CLAMP
|
IH
- twine
|
| 10. |
ZA746267
|
[2] |
SPRING
|
IH
- twine clamp
|
| 11. |
9413979
|
[4] |
LOCK NUT,3/8"-16, GC
|
IH
NUT - hex lock, 3/8 inch NC, Grade 8 Superseded by part number: 232-4136
|
| 12. |
ZA105153
|
[1] |
SUPPORT
|
IH
- cutoff, left
|
| 13. |
ZA105273
|
[1] |
ARM
|
IH
- jam, left Superseded by part number: 700120309
|
| 14. |
133135C1
|
[4] |
WASHER
|
IH
WASHER - shim, 17/32 x 1-1/2 x 1/64 inch (13 x 38 x 0.38 mm)
|
| 15. |
25710R1
|
[2] |
WASHER
|
IH
- flat, hardened Superseded by part number: 86624188
|
| 16. |
96313C1
|
[2] |
BOLT
|
IH
- shoulder, 3/8 inch NC
|
| 17. |
ZA105891
|
[2] |
CABLE
|
CAS
ASSEMBLY - threader
|
| 18. |
138082
|
[2] |
CLEVIS PIN,3/16" x .580"
|
IH
PIN - clevis, 3/16 x 37/64 inch Superseded by part number: 86596057
|
| 19. |
103362
|
[2] |
COTTER PIN,1/16" x 3/4"
|
IH
Pin, Split (Cotter), 1/16" x 3/4" Superseded by part number: 86624069
|
| 20. |
20893R1
|
[4] |
WASHER
|
IH
- flat, 11/32 x 1 x 7/64 inch (9 x 25 x 3 mm) Superseded by part number: 86624143
|
| 21. |
ZA105063
|
[2] |
SUPPORT
|
IH
- pulley
|
| 22. |
ZA206636
|
[2] |
PULLEY
|
IH
- twine threader
|
| 23. |
ZA206630
|
[2] |
SPACER
|
IH
- pulley Superseded by part number: 6523799
|
| 24. |
ZA105331
|
[2] |
SPRING
|
IH
- extension Superseded by part number: 700709636
|
| 25. |
ZA105337
|
[2] |
GUIDE
|
CAS
- twine
|
| 26. |
ZA105239
|
[2] |
ANCHOR
|
IH
- spring
|
| 27. |
ZA105157
|
[1] |
SUPPORT
|
IH
TRIGGER - left
|
| 28. |
ZA105197
|
[2] |
SPRING
|
IH
- extension
|
| 29. |
ZA104892
|
[2] |
KNIFE
|
IH
- twine cutoff
|
| 30. |
ZA105964
|
[1] |
TUBE
|
CAS
ASSEMBLY - twine, left
|
| 31. |
ZA105963
|
[1] |
TUBE
|
CAS
ASSEMBLY - twine, right
|
| 33. |
ZA105051
|
[1] |
SUPPORT
|
IH
ASSEMBLY - twine tube
|
| 34. |
20885R1
|
[1] |
WASHER
|
IH
- flat, 1-5/32 x 2 x 1/16 inch (29 x 51 x 2 mm) Superseded by part number: 86624175
|
| 35. |
ZA105336
|
[2] |
BRACKET
|
CAS
- cable pull
|
| 37. |
ZA105065
|
[2] |
GEAR
|
IH
- spur, 6 tooth
|
| 39. |
ZA105886
|
[1] |
BRACKET
|
CAS
ASSEMBLY - anchor
|
| 40. |
ZA105156
|
[1] |
SUPPORT
|
IH
TRIGGER - right
|
| 41. |
ZA105272
|
[1] |
ARM
|
IH
- jam, right Superseded by part number: 700120310
|
| 42. |
ZA105152
|
[1] |
SUPPORT
|
IH
- cutoff, right
|
| 43. |
ZA105235
|
[1] |
SHIELD
|
IH
- end, right
|
| 44. |
ZA104769
|
[1] |
ELECTRICAL WIRE
|
IH
WIRE - twine thread, 41 inch (1 041 mm)
|
| 46. |
87414
|
[2] |
LUBE NIPPLE,1/4" - 28
|
NH
FITTING - grease, thread forming, 1/4 inch
|
| 47. |
180083
|
[1] |
BOLT,Hex, 5/16" - 18 x 1 1/2", Gr 5
|
IH
- hex, 5/16 NC x 1-1/2 inch Superseded by part number: 88275
|
| 48. |
80681
|
[1] |
LOCK NUT,5/16"
|
NH
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 49. |
120376
|
[1] |
NUT,5/16"-18, G5
|
IH
Superseded by part number: 9635082
|
| 50. |
180123
|
[1] |
BOLT,Hex, 3/8" - 16 x 1 1/8", Gr 5, Full Thd
|
IH
- hex, 3/8 NC x 1-1/8 inch Superseded by part number: 113-262
|
| 51. |
120382
|
[1] |
LOCK WASHER,Helical Spring, 3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
