Pos.	Part No	Qty	Parts name	Comments
1.	668902R1	[1]	BELT	IH - Speed up (Used with sheave ZA104645) (Interchangeable with ZA104774)
1.	ZA104774	[1]	BELT	IH - Slow speed (Used with sheave ZA104842) (Interchangeable with 668902R1)
2.	27908R1	[3]	BOLT,1/2" x 1 1/4", Gr 8	CAS - hex, 1/2 NC x 1-1/4 inch type 8
3.	351107R1	[3]	WASHER	IH - flat, 17/32 x 2 x 1/4 inch (13 x 50 x 6 mm)
4.	ZA104645	[1]	PULLEY	IH SHEAVE - speed up (Used with belt 668902R1) (Interchangeable with ZA104842)
4.	ZA104842	[1]	PULLEY	IH SHEAVE - slow down (Used with belt ZA104774) (Interchangeable with ZA104645)
5.	22051R1	[1]	WASHER	IH - flat, 1-17/32 x 2-1/4 x 1/16 inch (30 x 57 x 1 mm) Superseded by part number: Q302
6.	663562R1	[4]	FLANGE	IH HOUSING - bearing
7.	96328C1	[3]	BALL BEARING,40mm ID x 80mm OD x 22mm W	CAS - 1.5753 inch ID (40 mm)
8.	ZA104824	[1]	PLATE	IH - left
. .	180077	[6]	BOLT,Hex, 5/16" - 18 x 3/4", Gr 5	IH - hex, 5/16 NC x 3/4 inch Superseded by part number: 87872
9.	ZA104736	[1]	ROLLER	IH - pivot (No. 10)
10.	ZA104823	[1]	PLATE	IH - right
11.	ZA104939	[1]	STRIPPER	IH
12.	432-1216	[1]	COTTER PIN,3/16" x 1"	CAS Pin, Split (Cotter), 3/16" x 1"
13.	27342R1	[1]	WASHER	IH WASHER - flat, 17/32 x 1 x 1/16 inch (13 x 25 x 1 mm) Superseded by part number: 495-81254
14.	ZA104215	[1]	ARM	IH
. .	180183	[1]	BOLT,Hex, 1/2" - 13 x 2 1/4", Gr 5	IH - hex, 1/2 NC x 2-1/4 inch Superseded by part number: 113-441
15.	21993R1	[1]	SPLIT PIN/SAFETY PIN	IH PIN - headed, 1/2 x 3-1/2 inch Superseded by part number: 86624062
1.	ZA103001	[1]	PULLEY	IH ILDER - belt
17.	ZA271276	[1]	SPRING	IH
18.	ZA201085	[1]	INSERT	IH - lift spring
19.	120378	[1]	NUT,Hex, 1/2" - 13, Gr 5	IH NUT, 1/2"-13, G5 Superseded by part number: 280431
20.	445608	[1]	BOLT,Hex, 1/2" - 13 x 5 1/2", Gr 5	IH - hex, 1/2 NC x 5-1/2 inch Superseded by part number: 88576
21.	ZA104976	[2]	DIVIDER	IH (For 4-3/4 inch wide belts) (Prior to P.I.N. 000800)
21.	ZA105548	[2]	DIVIDER	IH (For 11 inch wide belts) (P.I.N. 000801 and after)
. .	17351R1	[8]	CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1", Gr 2	IH BOLT - round head square neck, 3/8 NC x 1 inch Superseded by part number: 88682
. .	21403R1	[4]	WASHER	IH - flat, 13/32 x 1 x 1/8 inch (10 x 24 x 3 mm) Superseded by part number: 87613212
22.	ZA104982	[4]	CLIP	IH - angle
23.	120377	[8]	NUT,3/8" - 16, Gr 5	IH Superseded by part number: 280136
24.	ZA104987	[2]	BRACKET	IH TIGHTENER - left
. .	180124	[6]	BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5	IH - hex, 3/8 NC x 1-1/4 inch Superseded by part number: 88011
. .	189305	[2]	BOLT,Hex, 3/8" - 16 x 3 1/2", Gr 5	IH - hex, 3/8 NC x 3-1/2 inch Superseded by part number: 186283
25.	ZA104600	[5]	COLLAR	IH - bearing
26.	1415467R91	[5]	BALL BEARING,35 mm ID x 72 mm OD x 17 mm	IH - 1.378 inch ID (35 mm) Superseded by part number: 84002007
27.	ZA104555	[2]	ROLLER	IH - idler (No. 7 and 9) Superseded by part number: 228682A1, 228695A1
28.	ZA104735	[1]	ROLLER	IH - drive (No. 8) Superseded by part number: 228695A1, 228687A1, 47442495, ZA105799
29.	ZA104975	[1]	STRIPPER	IH Superseded by part number: ZA106780
30.	ZA104107	[20]	BELT	IH - Top (4-3/4 inch wide) (Prior to P.I.N. 000800)
30.	ZA105003	[10]	BELT	IH - Top (11 inch wide) (P.I.N. 000801 and after) Superseded by part number: 700724731
31.	ZA102971	[20]	PIN	IH (For 4-3/4 inch wide belt) (Prior to P.I.N. 000800)
31.	ZA102977	[10]	PIN	IH (For 11 inch wide belt) (P.I.N. 000801 and after)
