| 1. |
ZA104615
|
[1] |
HARNESS
|
IH
- tractor
|
| 2. |
ZA105277
|
[1] |
BRACKET
|
IH
- control box
|
| 3. |
ZA103773
|
[1] |
PACKAGE
|
IH
- hardware
|
| . . |
9635082
|
[4] |
NUT,5/16" - 18, Gr 5
|
NH
- hex, 5/16 inch NC
|
| 4. |
120392
|
[4] |
WASHER,1/4", SAE
|
IH
- flat, 9/32 x 5/8 x 1/6 inch (7 x 15 x 1 mm) Superseded by part number: 87361
|
| 5. |
ZA734450
|
[1] |
HANDLE
|
IH
|
| 6. |
17175R1
|
[1] |
LOCK PIN,3/16" x 1", Slotted
|
IH
PIN, 3/16" x 1", Slotted Superseded by part number: 118827
|
| 7. |
ZA105892
|
[1] |
CONTROL
|
CAS
BOX - control (new) (replaces ZA105894)
|
| 7. |
ZA105893
|
[1] |
CONTROL
|
CAS
BOX - control (remanufactured) (replaces ZA105895 and 1254051C1) Superseded by part number: ZA105892
|
| . . |
1261437C1
|
[1] |
LAMP
|
CAS
BULB - lamp (no. 37)
|
| 8. |
131181C1
|
[1] |
RELAY
|
IH
Superseded by part number: 3221235R2
|
| 9. |
ZA104616
|
[1] |
HARNESS
|
IH
- control box
|
| 10. |
533959R1
|
[4] |
CABLE TIE,.135" x 11"
|
IH
TIE - hose Superseded by part number: 529070
|
| 11. |
ZA104614
|
[1] |
HARNESS
|
IH
- baler
|
| 12. |
299404C1
|
[8] |
CLAMP
|
IH
CLIP - harness Superseded by part number: 86572009
|
| 13. |
ZA104641
|
[2] |
SWITCH
|
IH
(prior to P.I.N. 001131)
|
| . . |
436668
|
[2] |
|
P
SCREW - slotted pan head, no. 6 x 7/8 inch
|
| . . |
134530
|
[2] |
NUT,Hex, #6 - 32
|
IH
Superseded by part number: 88458
|
| . . |
131044
|
[2] |
LOCK WASHER
|
IH
Lock, #6 Superseded by part number: 492-11006
|
| 14. |
27305R1
|
[2] |
WASHER
|
CAS
- flat, 5/32 x 3/8 x 1/32 inch (3 x 9 x 1 mm)
|
| 15. |
ZA104394
|
[1] |
BUSHING
|
IH
|
| 16. |
169851C1
|
[1] |
GROMMET
|
IH
BUSHING
|
| 17. |
299407C1
|
[4] |
CLAMP
|
IH
CLIP - harness Superseded by part number: 86010402
|
| 18. |
488837C1
|
[1] |
SPRING NUT
|
IH
- U type, 5/16 NC
|
| 19. |
103396
|
[2] |
PIN, SPLIT (COTTER),5/32" x 1"
|
IH
5/32" x 1" Superseded by part number: 120169
|
| 20. |
ZA105658
|
[1] |
ACTUATOR
|
IH
(Replaces ZA105049) (See Pages 5 and 7) Superseded by part number: 700709661
|
| 21. |
ZA103745
|
[1] |
HARNESS
|
IH
- extension
|
| 22. |
179454C1
|
[2] |
RUBBER WASHER
|
IH
- rubber
|
| 23. |
ZA104561
|
[2] |
BRACKET
|
IH
|
| . . |
120221
|
[2] |
NUT,Sl Rnd Hd, #10 - 24 x 1/2"
|
IH
SCREW - slotted round head, No. 10 x 1/2 inch Superseded by part number: 159920
|
| . . |
120217
|
[2] |
LOCK WASHER,#10
|
IH
WASHER, LOCK, #10 Superseded by part number: 80684
|
| . . |
26303R1
|
[2] |
HARDWARE,#10-24
|
IH
NUT - hex, No. 10 Superseded by part number: 3062835R1
|
| . . |
120391
|
[2] |
WASHER,#10
|
IH
- flat, 7/32 x 1/2 x 3/64 inch (5 x 12 x 1 mm) Superseded by part number: 9824326
|
| 24. |
ZA103633
|
[2] |
SWITCH
|
IH
Superseded by part number: 232773A1
|
| 25. |
ZA104562
|
[2] |
COVER
|
IH
Superseded by part number: 230414A1
|
| 26. |
1261522C91
|
[1] |
BRACKET, SUPPORTING
|
IH
BRACKET - cab mounting (Used to mount control box)
|
| . . |
598802R1
|
[4] |
CARRIAGE BOLT,Short NK, 5/16"-18 x 3/4", G5, Full Thd
|
IH
BOLT - round head square neck, 5/16 NC x 3/4 inch Superseded by part number: 280497
|
| . . |
116120
|
[4] |
LOCK WASHER,5/16"
|
IH
WASHER, LOCK, 5/16" Superseded by part number: 83990583, 322358
|
| 27. |
ZA105270
|
[1] |
HARNESS
|
IH
- emergency (Temporarily operators actuator) (Also order Switch 91774C1)
|
| 28. |
91774C1
|
[1] |
ASSEMBLY
|
IH
SWITCH
|
| 29. |
ZA105438
|
[1] |
KIT
|
CAS
- connector
|
| . . |
245430C1
|
[1] |
CONNECTOR, ELEC
|
IH
CONNECTOR - male, 8 terminal Superseded by part number: 87698229
|
| . . |
3195530R1
|
[1] |
CONNECTOR, ELEC
|
CAS
CONNECTOR - female, 8 terminal
|
| . . |
877291R1
|
[1] |
ELEC CONNECTOR,Female
|
IH
CONNECTOR - male, 2 terminal Superseded by part number: 87693325
|
| . . |
739145C1
|
[10] |
ELEC. TERMINAL PIN,Male, 3 - 5 mm2
|
IH
TERMINAL - male, 1/4 inch long blade Superseded by part number: 87697669
|
| . . |
739067C1
|
[10] |
TERMINAL CONNECTOR,Female, 5 mm2
|
CAS
TERMINAL - female, 1/4 inch Superseded by part number: 87703293
|
